4. Application Scenarios

4-1 Special Short Baseline Experimental Setup

. . .
RTK
Setup for Special Short Baseline Experiment
RTK
antenna
antenna
Base Rover
Micro-USB Micro-USB
cable cable
Alpha RTK Alpha RTK
TTL mode / switch on B
TTL mode / switch on A
6-pin 3 wire for Base-to-Rover (sec. 3-4-1)
Figure 4-1
For users setting up a local RTK base for use with RTK rover, this experimental setup allows quickly
becoming acquainted with all aspects of Alpha RTK receiver operation. Using our RTK Viewer
Windows-PC software, users can configure Alpha to be base or rover; see section 6 for details.
10
