- Page 1 LoRa Radio + Alpha plus Quick Guide...
- Page 2 Setup Alpha Mode Configure Alpha before hookup with LoRa Radio. Reference to “Alpha RTK Receiver User Guide” Set Alpha to Base Mode Set Alpha to Rover Mode 1. Press button to USB interface. Ready to hookup with LoRa radio.
- Page 3 LoRa Radio Interface Overview 1. Connect to Alpha RTK Receiver 2. Radio Mode Select 3. Connect to Power Bank (5V Power Input) / Radio Configuration Port 4. Base Mode / Rover Mode Select 5. SMA Connector for Radio Antenna...
- Page 4 LoRa Radio Hook Up 1. Jumper to Transceiver Mode (Connect Right 2 Pins) 2. Connect to Alpha RTK Receiver 3. Connect to Power Bank 4. Connect to Radio Antenna...
- Page 5 LoRa Radio Hook Up 4. Connect to Radio Antenna 5. Select Base Mode or Rover Mode Jumper to Base Transmission Mode (Connect Right 2 Pins) Jumper to Rover Received Mode (Connect Left 2 Pins)
- Page 6 Base Application Connect LoRa radio to 5V power, it ready to broadcast.
- Page 7 Rover Application Connect LoRa radio to 5V power, it ready to receive. Usually, Rover operates with third party apps via Bluetooth, it uses “Mock Locations” feature on Android. See Alpha+ User Guide section 6-4-2 item #6 ~ #16 on page 30 ~35. Notice: #step Set [None] to “Network Protocol“...
- Page 8 Radio Configuration ( Advanced, No Need & Not to Do This on First Time Use !!! ) The shipped base radio and rover radio pair is plug-and-play, no need for any radio configuration. This Advanced radio configuration information is provided only for situation such as if another user has a pair of radio operating nearby causing interference, and needing to change to...
- Page 9 Radio Configuration (Advanced, No Need & Not to Do This on First Time Use !!! ) Download Link: http://www.ashining.com.cn/relatedsoftware/soft_asds.zip Connect Radio to Windows PC then Open the Configuration Tool:...
-
Page 10: Radio Configuration
Radio Configuration... - Page 11 Multiple Rover Application In this case, Only needs One Base to broadcast RTCM data, sending RTCM data to More Rover. 1. Setup all LoRa Radio with same channel ID (see page-6,7,8) 2. Setup Base (see page-2 & & & 6) 3.
-
Page 12: Usage Notice
Usage Notice • When detaching USB cable from the radio, please pull the USB cable connector horizontally, avoid bending/tilting upward at the same time.
