Pure Fun 9307TS Product Manual page 8

ASSEMBLY INSTRUCTIONS
STEP 5
15- Spring Washer
20-
x2
Tighten to the metal rod the
hardware shown to ensure it
doesn't escape.
Insert the Metal Rod (22) from
the larger BOTTOM opening
of he Plastic Vertical Leg
Extension (5B) for the Abacus.
STEP 6
25- 26-
Green Abacus Ball Yellow Abacus Ball
x12
Slide 12x Green Abacus Balls
(25)through the Metal Rod, and
then slide 12x Yellow Abacus
Balls (26)
NOTE: You may choose which
colors go first between all 4
colors provided.
8
21-
M8 Spring Washer
Flat Washer
x1
x2
22
x12
GQBrands.com CustomerService@GQBrands.com
20
15
21
15
20
1-866-498-5269
