ASSEMBLY INSTRUCTIONS
STEP 13
The Straight Frame Tubes
should have Foam (8A)
already pre-installed.
Slide into the corner Top
Rails from the upper
opening, and slide the
Top Rail to the arms of the
corners.
NOTE: Just like the
Corners, the openings
of the Top Rails must be
facing upwards for the
springs to be installed
STEP 14
20
17
12
8
GQBrands.com
2
18- Screw
20-
Align all the openings, and
with the Screw (18) facing the
outside, tighten all hardware
shown using the Phillips
Screwdriver from the Allen
Wrench (19)
18
CustomerService@GQBrands.com
8
x2
17-
M8 Spring Washer
Arc Washer
x2
x2
1-866-498-5269
