Summary of Contents for Pure Fun 9308TS
- Page 1 DURA-BOUNCE 8FT TRAMPOLINE SET MODEL# 9308TS PRODUCT MANUAL - VERSION 06.17.01 FOR AGES: WEIGHT LIMIT: TO BUILD: TOOLS NEEDED: 113 Kgs CUSTOMER SERVICE GQBrands.com CustomerService@GQBrands.com 1-866-498-5269 4401 Samuell Blvd, Ste 150, Mesquite, TX 75149...
-
Page 2: Customer Service Information
CUSTOMER SERVICE INFORMATION Thank you for purchasing: DURA-BOUNCE 8FT TRAMPOLINE SET MODEL# 9308TS - TRAMPOLINE At GQBrands®, we want all of our customers to be completely To order these parts, or if you have any other questions or concerns satisfied with their purchase. Take time to review the contents of the... - Page 3 – an existing condition dramatically increases the risk • ALWAYS secure the trampoline against of serious injury or death. unauthorized and unsupervised use. MODEL# 9308TS...
-
Page 4: Trampoline - Parts List
TRAMPOLINE - PARTS LIST Trampoline Mat Frame Pad Curved Frame with T-Section “U” Shaped Leg Leg Extension Spring Screw Spring Tool GQBrands.com CustomerService@GQBrands.com 1-866-498-5269... -
Page 5: Enclosure - Parts List
ENCLOSURE - PARTS LIST Lower Pole Upper Pole with Cap Pole Cover M8 Bolt Enclosure Net M8 Nut Plastic Washer Washer MODEL# 9308TS... -
Page 6: Assembly Instructions
ASSEMBLY INSTRUCTIONS STEP 1: Parts: Part 3 (x6) - Curved Frame with T-Section Lay out the Curved Frames (3) in the ground as shown in the picture with the spring openings facing the floor. Slide all six Curved Frames onto each other to complete a full circled frame. - Page 7 Frame and slide until all have 3 assembled legs are secure. STEP 5: Parts: Part 1 (x1) - Trampoline Mat Place the Trampoline Mat (1) in the middle of the frame, with the logo facing upwards and the stitching facing the floor. MODEL# 9308TS...
- Page 8 ASSEMBLY INSTRUCTIONS LEARNING TO INSTALL SPRINGS Install the Spring (6) by placing the “R” “R” “C” Hook on the V-Ring of the Trampoline Mat. Hook Hook Using the Spring Tool (8), pull the “C” Hook until it reaches the opening in the frame. Spring ends facing down “R”...
- Page 9 Top Rail and springs. The Frame Pad must cover the Top Rails completely to avoid injury. STEP 8: Tighten the Elastic Straps at the bottom of the Frame to the top rail to secure to the trampoline. Tighten straps to the top rail MODEL# 9308TS...
- Page 10 ASSEMBLY INSTRUCTIONS STEP 9: Parts: Part 9 (x6) - Lower Pole Align the opening Lowe Poles (9) to the horizontal opening of the T-Section and the middle opening of the Leg extension. STEP 10: Following the instructions on Page 11, Lower Pole install all Lower Poles to all t-Section from Locations...
- Page 11 ASSEMBLY INSTRUCTIONS M8 Bolt M8 Nut Plastic Washer Washer MODEL# 9308TS...
- Page 12 ASSEMBLY INSTRUCTIONS STEP 11: Parts: Part 11 (x6) - Pole Cover Slide x6 Pole Covers (11) once all Lower Poles have been installed. STEP 12: Parts: Part 10 (x6) - Upper Pole with Cap Part 11 (x6) - Pole Cover Slide x6 Pole Covers (11) to an Upper Pole with Cap (10) to have x6 completed pieces NOTE:...
- Page 13 STEP 13: Parts: Part 12 (x1) - Enclosure Net Slide all x6 completed upper poles into the enclosure pole covers in the Enclosure Netting. NOTE: Leaving the zipper open will make it easier to install the enclosure netting. MODEL# 9308TS...
- Page 14 ASSEMBLY INSTRUCTIONS STEP 14: Insert each Upper Pole and slide down to the Lower Pole attached to the trampoline, one at a time to distribute the tension of the enclosure netting evenly. Once placed, slide the net and the covers until they complete cover the lower poles, GQBrands.com CustomerService@GQBrands.com...
- Page 15 Frame Pad. STEP 16: At the bottom of the Enclosure netting there are hooks that need to be attached to the V-Rings of the trampoline. Secure all Hooks to tighten the Enclosure netting to the trampoline as shown. MODEL# 9308TS...
-
Page 16: Customer Service
NOTES CUSTOMER SERVICE GQBrands® 1-866-498-5269 CustomerService@GQBrands.com 4401 Samuell Blvd, Ste 150, Mesquite, TX 75149 GQBrands.com CustomerService@GQBrands.com 1-866-498-5269...
