ASSEMBLY INSTRUCTIONS
STEP 11
STEP 12
Spring holes must
be facing upward
3
MODEL# 9307TS
Slide the completed Abacus into the
Vertical Leg Extensions with the bottom
portion closest to the Horizontal Leg Base
The emboss indent at he bottom of the legs
will align to the openings of the Horizontal
Leg Base.
Slide 2x Corner Top Rail with Socket (Part
3) and align to the upper opening of the
Vertical Leg Extensions.
NOTE: Make sure that you locate the upper
openings of the corner arms and they are
facing upwards.
3
11
