IN S TA L L AT I O N M AN U AL F O R G DM F R E E Z E R /
RE F R IG E R AT O R ( S WING A N D S L ID E D O OR )
GDM-23
GDM-49
F R EE ZER / REFRI G ERATOR
SW ING & S LI DE DOOR
GDM-69
GDM ( G LAS S DOOR
MERCHA NDIS ERS)
............ www.truemfg.com ............
TRUE FOOD SERVICE EQUIPMENT, INC.

TABLE OF CONTENTS

Installing GDM-10 & GDM-12
*Spanish, German, French, Dutch and Arabic versions included.
CONGRATULATIONS!
You have just purchased the finest commercial
refrigerator available. You can expect many years of
trouble-free operation.
1
2
3
4
4
5
5
5
6
7
8
9
10
11
13
14
15-16
17
17
18-19
20
21-22
23
24
8/29/08-50K SB #897005

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GDM-49 and is the answer not in the manual?

Questions and answers

Summary of Contents for True GDM-49

  • Page 1: Table Of Contents

    TRUE FOOD SERVICE EQUIPMENT, INC. IN S TA L L AT I O N M AN U AL F O R G DM F R E E Z E R / RE F R IG E R AT O R ( S WING A N D S L ID E D O OR )
  • Page 2 True Food Service Equipment, Inc..... www.truemfg.com ....
  • Page 3: Safety Information

    You have selected one of the finest commercial refrigeration units made. It is manufactured under strict quality controls with only the best quality materials available. Your TRUE cooler when properly maintained will give you many years of trouble-free service. WARNING! Use this appliance for its intended purpose as described in this Owner Manual.
  • Page 4: Gdm Do's And Don'ts

    True Food Service Equipment, Inc. SAFETY INFORMATION .... www.truemfg.com ....
  • Page 5: Proper Disposal

    True Food Service Equipment, Inc. SAFETY INFORMATION SAFETY INFORMATION DANGER! RISK OF CHILD ENTRAPMENT PROPER DISPOSAL OF THE REFRIGERATOR Refrigerant Disposal Before You Throw Away Your Old Refrigerator or Freezer: Take off the doors. Leave the shelves in place so that children may not easily climb inside.
  • Page 6: Connecting Electricity

    True Food Service Equipment, Inc. SAFETY INFORMATION SAFETY INFORMATION WARNING! HOW TO CONNECT ELECTRICITY Do not, under any circumstances, cut or remove the third (ground) prong from the power cord. For personal safety, this appliance must be properly grounded. USE OF ADAPTER PLUGS NEVER USE AN ADAPTER PLUG! Because of potential safety hazards under certain conditions, we strongly recommend against the use of an adapter plug.
  • Page 7: Installation / Operation Instructions Ownership

    True Food Service Equipment, Inc. INSTALLATION / OPERATION INSTRUCTIONS INSTALLATION / OPERATION INSTRUCTIONS OWNERSHIP True is not responsible for damage incurred during shipment. REQUIRED TOOLS UNCRATING Step 1 Note: .... www.truemfg.com ....
  • Page 8: Leveling Cabinet

    True Food Service Equipment, Inc. INSTALLATION / OPERATION INSTRUCTIONS LOCATING Step 2 Removing skid from bottom of cabinet. Some units have a poly- ester strap that secures the cabinet to the ship- ping skid. Cut this polyes- ter strap and remove the LEVELING wood skid.
  • Page 9: Installation Of Optional Leg/Castors

    True Food Service Equipment, Inc. INSTALLATION / OPERATION INSTRUCTIONS INSTALLATION OF OPTIONAL LEGS / CASTORS Important Safeguard for installation of leg/castor (Images 1-5 demonstrate procedure) Step 4 Securing Castors and Legs Unit leveling Four leveling shims have been provided for leveling CAUTION castored units positioned on uneven floors.
  • Page 10 True Food Service Equipment, Inc. INSTALLATION / OPERATION INSTRUCTIONS INSTALLING OPTIONAL CASTORS ON GDM-10 AND GDM-12 MODELS Final Location WARNING: Compressor warranties are void if the unit is more than 6 1/2ft. (1.98m) from plug-in connection. NOTE: Two out of the four castors are designated with an “F”...
  • Page 11: Wire Gauge Chart

    True Food Service Equipment, Inc. INSTALLATION / OPERATION INSTRUCTIONS CONDUCTORS AND CIRCUITS Wire Gauge for 2% Voltage Drop in Supply Circuits. 115 Volt Distance In Feet To Center of Load Amps 100 120 140 160 Wire Gauge for 2% Voltage Drop in Supply Circuits.
  • Page 12: Sealing Cabinet To Floor & Electrical Inst

    True Food Service Equipment, Inc. INSTALLATION / OPERATION INSTRUCTIONS ELECTRICAL INSTRUCTIONS Step 5 True WARNING Compressor warranties are void if compressor burns out due to low voltage. WARNING Power supply cord ground should not be removed! NOTE To reference wiring diagram - Remove front louvered grill, wiring diagram is positioned on the inside cabinet wall.
  • Page 13: Startup

    True Food Service Equipment, Inc. INSTALLATION / OPERATION INSTRUCTIONS FREEZERS ONLY! (COMPRESSOR BAND REMOVAL) Please check your compressor. If there is a shipping band, please remove. WARNING: COMPRESSOR BAND MUST BE REMOVED BEFORE UNIT IS CONNECTED TO POWER SUPPLY. Cutting band around compressor...
  • Page 14: Shelving Installation/Operation & Light Switches

    Altering shelf clips in any way can instances the switch is located next to the lead to shelving instability. temperature control. GDM-49’s and 72’s have the switch located on the right side of the evaporator housing along the interior ceiling. GDM-9’s, 5’s, and GDM-5PT’s have the switch located on the left side of the ceiling.
  • Page 15: Installing Trueflex Bottle Organizers

    True Food Service Equipment, Inc. SAFETY INFORMATION INSTALLING BOTTLE ORGANIZERS (20 OZ.) NOTE: Shelf retainer clip installation, both sides. When installing shelves, be sure to plan (retainer clip position adequate space between shelves for varies depending on product to be stocked and removed.
  • Page 16: Grasslin Defrost Timer (Freezer Units Only)

    True Food Service Equipment, Inc. INSTALLATION / OPERATION INSTRUCTIONS FREEZER DEFROST TIME CLOCK OPERATION (Grasslin Timer) ___________ STEP 1 ____________ RECOMMENDED DEFROST SETTINGS: ___________ STEP 2 ____________ Notice: REQUIRED TOOLS ___________ STEP 3 ____________ Locating The Defrost Timer: The following procedure may be fol- lowed to customize your needs.
  • Page 17: Field Troubleshooting (Freezer Units Only)

    True Food Service Equipment, Inc. INSTALLATION / OPERATION INSTRUCTIONS IF THE COMPRESSOR WILL NOT IF THE MOTOR COMPRESSOR STARTS BUT TRIPS REPEATEDLY ON THE OVERLOAD PROTECTOR .... www.truemfg.com ....
  • Page 18 True Food Service Equipment, Inc. INSTALLATION / OPERATION INSTRUCTIONS 3. Coil Defrost Heater 4. Drain Tube Heater IF THE COMPRESSOR RUNS BUT WILL NOT REFRIGERATE IF THE MOTOR COMPRESSOR STARTS BUT TRIPS REPEATEDLY ON THE OVERLOAD PROTECTOR 1. Defrost Time Clock 5.
  • Page 19: Light Cover Install For Gdm-10F & Gdm-12F

    True Food Service Equipment, Inc. INSTALLATION / OPERATION INSTRUCTIONS Light Cover Installation for GDM-10F & GDM-12F - IMPORTANT - ___________ STEP 3 ____________ Before installing lamp cover turn cabinet on and allow it to reach temperature. - NOTE - ___________ STEP 1 ____________...
  • Page 20: Maintenance, Care & Cleaning

    True Food Service Equipment, Inc. MAINTENANCE, CARE & CLEANING MAINTENANCE, CARE & CLEANING CLEANING THE CONDENSER COIL When using electrical appliances, basic safety precautions should be followed, including the following: REQUIRED TOOLS: ___________ STEP 8 ____________ • Phillips Screwdriver • Stiff Bristle Brush •...
  • Page 21 5. When finished be sure to replace the louvered grill. The grill protects the condenser. 6. Reconnect the electrical power to the unit. If you have any questions, please call True Manufacturing at 636-240-2400 or 800-325-6152 and ask for the Service Department. Service Department Availability Monday-Friday 7:30 a.m. to 5:30 p.m. and Saturday 7:45 a.m.
  • Page 22: Temperature Control Adjustment

    True Food Service Equipment, Inc. MAINTENANCE, CARE & CLEANING TEMPERATURE CONTROL ADJUSTMENT FOR HIGH ALTITUDE ONLY! TERMS: __________ STEP 4 ___________ REQUIRED TOOLS __________ STEP 5 ___________ __________ STEP 1 ___________ __________ STEP 2 ___________ Danfoss Temperature Control (High Altitude Adjustment Only!)
  • Page 23: Stainless Steel Equipment Care & Cleaning

    True Food Service Equipment, Inc. MAINTENANCE, CARE & CLEANING STAINLESS STEEL EQUIPMENT CARE AND CLEANING CAUTION: Do not use any steel wool, abrasive or chlorine based products to clean stainless steel surfaces. Stainless Steel Opponents 8 steps that can help prevent rust on stainless steel: 1.
  • Page 24: Light Bulb Replacement

    True Food Service Equipment, Inc. MAINTENANCE, CARE & CLEANING STAINLESS STEEL EQUIPMENT CARE AND CLEANING Recommended cleaners for certain situations / environments of stainless steel NOTE: The use of stainless steel cleaners or other such solvents is not recommended on plastic parts. Warm soap and water will suffice.
  • Page 25: Warranty (U.s.a. & Canada Only!)

    ONE YEAR PARTS & LABOR WARRANTY TRUE warrants to the original purchaser of every new TRUE refrigerated unit, the cabinet and all parts thereof, to be free from defects in material or work- manship, under normal and proper use and maintenance service as specified by TRUE and upon proper installation and start-up in accordance with the instruction packet supplied with each TRUE unit.
