I N S T A L L A T I O N M A N U A L F O R G D M F R E E Z E R /
R E F R I G E R A T O R ( S W I N G A N D S L I D E D O O R )
GDM-23
GDM-49
F R E E Z E R / R E F R I G E R A T O R
F R E E Z E R / R E F R I G E R A T O R
S W I N G & S L I D E D O O R
S W I N G & S L I D E D O O R
(636)-240-2400 • FAX (636)272-2408 • INT'L FAX (636)272-7546 • (800)325-6152
GDM-69
G D M ( G L A S S D O O R
G D M ( G L A S S D O O R
M E R C H A N D I S E R S )
M E R C H A N D I S E R S )
............ www.truemfg.com ............
............ www.truemfg.com ............
TRUE FOOD SERVICE EQUIPMENT, INC.
2001 East Terra Lane • P.O. Box 970 • O'Fallon, Missouri 63366
Parts Department (800)424-TRUE • Parts Department FAX# (636)272-9471
TABLE OF CONTENTS
Light Cover Install for GDM-10F & GDM-12F 16
Cleaning Condenser Coil
*Spanish, German, French and Arabic versions included.
CONGRATULATIONS!
You have just purchased the finest commercial
freezer / refrigerator available. You can expect many
years of trouble-free operation.
1
2
3
4
4
5
5
5
6
7
8
9
10
11
12
13
14-15
17-18
19
20-21
21
22
11/12/07-50K SB #897005
Advertisement
Table of Contents
Related Manuals for True GDM-10F
Summary of Contents for True GDM-10F
-
Page 1: Table Of Contents
Start-up Shelving Install/Operation & Light Switches Grasslin Defrost Timer (Freezer Units Only) Field Troubleshooting (Freezer Units Only) Light Cover Install for GDM-10F & GDM-12F 16 Maintenance, Care & Cleaning Cleaning Condenser Coil Temperature Control Adjustment Stainless Steel Equipment Care & Cleaning Light Bulb Replacement Warranty (U.S.A. - Page 2 True Food Service Equipment, Inc. True Food Service Equipment, Inc..www.truemfg.com ..www.truemfg.com ...
-
Page 3: Safety Information
You have selected one of the finest commercial refrigeration units made. It is manufactured under strict quality controls with only the best quality materials available. Your TRUE cooler when properly maintained will give you many Use this appliance for its intended purpose as described in this... -
Page 4: Gdm Do's And Don'ts
True Food Service Equipment, Inc. True Food Service Equipment, Inc. SAFETY INFORMA TION SAFETY INFORMA TION ... www.truemfg.com ..www.truemfg.com ... -
Page 5: Proper Disposal
Leave the shelves in place so that children may not easily climb inside. USE OF EXTENSION CORDS NEVER USE AN EXTENSION CORD! TRUE will not warranty any refrigerator that has been connected to an extension cord..www.truemfg.com ..www.truemfg.com ... -
Page 6: Connecting Electricity
If you do not have the right outlet (North America Use Only!) NEMA plugs TRUE uses these types of plugs. have a certified electrician install the correct power source. -
Page 7: Installation / Operation Instructions Ownership
TION / OPERA TION INSTRUCTIONS TION / OPERA TION INSTRUCTIONS Before you start to install your True unit, carefully inspect it for freight damage. If damage is discovered, immediately file a claim with the delivery freight carrier. True is not responsible for damage incurred during shipment. -
Page 8: Leveling Cabinet
(100°F+, 38°C+), you may want to install an exhaust fan. Warning Warranty is void if ventilation is insufficient. B. Proper leveling of your True cooler is critical to operating success (for non-mobile models). Effective condensate removal and door operation will be effected by leveling. -
Page 9: Installation Of Optional Leg/Castors
True Food Service Equipment, Inc. True Food Service Equipment, Inc. INST ALLA INST ALLA INSTALLATION OF OPTIONAL LEGS / CASTORS Important Safeguard for installation of leg/castor (Images 1-5 demonstrate procedure) Step 4 Securing Castors and Legs To obtain maximum strength and stability of the unit, it is important that you make sure each castor is secure. -
Page 10: Installing Optional Castors On Gdm-10
TION INSTRUCTIONS Compressor warranties are void if the unit is more than 6 1/2ft. (1.98m) from plug-in K. Proper leveling of your TRUE cooler is critical to operating success. Effective condensate removal and door operation will be effected by leveling. -
Page 11: Wire Gauge Chart
True Food Service Equipment, Inc. True Food Service Equipment, Inc. INST ALLA INST ALLA CONDUCTORS AND CIRCUITS Wire Gauge for 2% Voltage Drop in Supply Circuits 115 Volt Amps Wire Gauge for 2% Voltage Drop in Supply Circuits 230 Volts Amps ... -
Page 12: Sealing Cabinet To Floor & Electrical Inst
TION / OPERA TION INSTRUCTIONS TION / OPERA TION INSTRUCTIONS True requires that a sole use circuit be dedicated for the unit. Failure to do so voids warranty. WARNING Compressor warranties are void if compressor burns out due to low voltage. -
Page 13: Startup
True dealer or recommended service agent. D. Good air flow in your True unit is critical. Be careful to load product so that it neither presses against the back wall, nor comes within four inches of the evaporator housing. -
Page 14: Shelving Install/Operation & Light Switches
Step 2 Place shelves or organizers on shelf clips making sure all corners are seated properly..www.truemfg.com ..www.truemfg.com ... True Food Service Equipment, Inc. True Food Service Equipment, Inc. TION / OPERA TION INSTRUCTIONS TION / OPERA... -
Page 15: Grasslin Defrost Timer (Freezer Units Only)
TION / OPERA TION INSTRUCTIONS TION / OPERA TION INSTRUCTIONS Your True freezer contains a defrost system that is temperature terminated, however the time clock has been designed with a time termination back-up so that the defrost period will not exceed thirty minutes. -
Page 16: Field Troubleshooting (Freezer Units Only)
Any capacitor found to be bulging, leaking, or damaged should be replaced..www.truemfg.com ..www.truemfg.com ... True Food Service Equipment, Inc. True Food Service Equipment, Inc. TION / OPERA TION INSTRUCTIONS TION / OPERA TION INSTRUCTIONS Make sure capacitors are discharged before checking. - Page 17 This will be true only if liquid refrigerant is in the line at the restricted point, since any temperature change due to...
- Page 18 INST ALLA INST ALLA Light Cover Installation for GDM-10F & GDM-12F REQUIRED TOOLS • none - IMPOR - IMPOR ANT - ANT - - IMPOR - IMPOR ANT - ANT - Before installing lamp cover Before replacing light cover turn cabinet on and wait until it turn cabinet on and allow it to reaches temperature.
-
Page 19: Maintenance, Care & Cleaning
True Food Service Equipment, Inc. True Food Service Equipment, Inc. MAINTENANCE, CARE & CLEANING MAINTENANCE, CARE & CLEANING MAINTENANCE, CARE & CLEANING CLEANING THE CONDENSER COIL When using electrical appliances, basic safety precautions should be followed, including the following: REQUIRED TOOLS: •... -
Page 20: Important Warranty Information
5. When finished be sure to replace the louvered grill. The grill protects the condenser. 6. Reconnect the electrical power to the unit. If you have any questions, please call True Manufacturing at 636-240-2400 or 800-325-6152 and ask for the Service Department. Service Department Availability Monday-Friday 7:30 a.m. to 5:30p.m. -
Page 21: Temperature Control Adjustment
True Food Service Equipment, Inc. True Food Service Equipment, Inc. MAINTENANCE, CARE & CLEANING MAINTENANCE, CARE & CLEANING TEMPERATURE CONTROL ADJUSTMENT FOR HIGH ALTITUDE ONLY! TERMS: Cut-out - Temperature sensed by the controller that shuts the compressor off. Cut-in - Temperature sensed by the controller that turns the compressor on. -
Page 22: Stainless Steel Equipment Care & Cleaning
Oxygen helps maintain the passivity film on stainless steel. 7. Hydrochloric acid (muriatic acid) should never be used on stainless steel 8. Regularly restore/passivate stainless steel ... www.truemfg.com ..www.truemfg.com ... True Food Service Equipment, Inc. True Food Service Equipment, Inc. -
Page 23: Light Bulb Replacement
True Food Service Equipment, Inc. True Food Service Equipment, Inc. MAINTENANCE, CARE & CLEANING MAINTENANCE, CARE & CLEANING Stainless Steel Equipment Care and Cleaning Recommended cleaners for certain situations / environments of stainless steel A) Soap, ammonia and detergent medallion applied with a cloth or sponge can be used for routine cleaning. -
Page 24: Warranty (U.s.a. & Canada Only!)
TRUE and upon proper installation and start-up in accordance with the instruction packet supplied with each TRUE unit. TRUE’s obligation under this warranty is limited to a period of one (1) year from the date of original installation or 15 months after shipment date from TRUE, whichever occurs first.
