Hitachi Virtual Storage Platform Gx00 and
Fx00
SVOS 7.3.1
System Administrator Guide
This document provides information and instructions to help you use the maintenance utility and some of
the functions in Device Manager - Storage Navigator as needed to perform system administration tasks
and change settings for VSP Gx00 models or VSP Fx00 models. It explains the GUI features and
provides basic navigation information.
MK-94HM8016-10
December 2017
