Preface
This manual describes the communication command list of the pH/Water Quality Meters with serial
communication function, LAQUA-PH1100/PH1200/PH1300/PC1100/EC1100.
The contents of this manual are subject to change without notice.
Caution
Use the optional USB cable (part number: 3200373941) or serial cable (part number:
3014030151) to connect the instrument to a personal computer (referred to as PC in the rest
of this document).
Make sure that the transfer format used in the instrument and a PC are the same.
When different transfer format is used, a communication error occurs and the online mode
does not start up, and as a result RS-232C communication cannot be performed. Also, when
the transfer format is changed, turn OFF the power of the instrument and PC and then reboot
them.
The transfer format of the instrument is as follows.
・ Baud rate: 2400 bps
・ Character length: 8 bits
・ Parity: None
・ Stop bit: 1 bit
If you write the program for serial communication, at first, write the command to change the
instrument to the online mode. By changing the instrument to the online mode, its operation
keys except for
If the instrument's power is turned OFF, reset the online mode.
If the instrument does not receive the command or occurs any errors after it requested the
data, add the waiting time of a few seconds before request the data again.
If the instrument received the data continuously, the instrument does not response.
The instrument cannot be controlled by using the DCD, CTS, and DSR.
It is necessary to switch RTS to ON to perform communication. Set it 2.4 V above.
Pin assignment of the instrument and the external instrument are follows.
Instrument side (A connector MINI DIN 8 PIN)
2 TX
3 RX
4 CTS
5 COM
External instrument side (B connector DSUB 9 PIN)
2 TX (RX at an external instrument side)
3 RX (TX at an external instrument side)
5 COM
7 CTS (RTS at an external instrument side)
2 Miyanohigashi, Kisshoin Minami-ku, Kyoto 601-8510 Japan
http://www.horiba.com
pH/Water Quality Meter F-7X BW
Low-spec Command Reference
key are locked and it changes to serial communication mode.
CODE:GZ0000438938
For any questions regarding this product, please contact your local
agency, or inquire from the HORIBA website.
(http://global.horiba.com/contact_e/index.htm)
February, 2016
© 2016 HORIBA, Ltd.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for horiba F-7X BW
Summary of Contents for horiba F-7X BW
- Page 1 3 RX (TX at an external instrument side) 5 COM 7 CTS (RTS at an external instrument side) For any questions regarding this product, please contact your local agency, or inquire from the HORIBA website. 2 Miyanohigashi, Kisshoin Minami-ku, Kyoto 601-8510 Japan (http://global.horiba.com/contact_e/index.htm) http://www.horiba.com...
- Page 2 ・Command function list (control) Command Item Function Header Name Online/Offline Changes between the online mode and the offline mode. Releases the hold state and returns to instantaneous Potential follow-up stop value display state. pH measurement mode Waits for the pH measurement. mV measurement mode Waits for the ORP measurement mode result.
- Page 3 ●Online/Offline command C, OL, x [CR][LF] 0 or 1 0: Offline １: Online Name (Online/Offline operation) Header When the instrument accepts the online command, it enters the online mode and the keys cannot be operated. ●Potential follow-up stop command C, BR, x [CR][LF] Channel （１...
- Page 4 ●mV measurement mode command C, MV, x [CR][LF] Channel (1 or 2) Name (mV measurement mode) Header When the instrument is in the online mode, this is valid for modes other than the calibration mode. Waits for the ORP measurement mode result. ●Ion measurement mode command C, IO, x [CR][LF] Channel (1 or 2)
- Page 5 ●Salinity measurement mode command C, SA [CR][LF] Name (Salinity measurement mode) Header When the instrument is in the online mode, this is valid for modes other than the calibration mode. Waits for the salinity measurement. ●Resistivity measurement mode command C, OH [CR][LF] Name (Ion measurement mode) Header When the instrument is in the online mode, this is valid for modes other than the calibration mode.
- Page 6 ●Calibration mode command C, CM, x, y [CR][LF] 0: Calibration mode end, 1: Calibration mode start Channel (1 or 2) Name Header Waits for the calibration at specified mode. ※ To return to the measurement mode without calibrating after entering the calibration mode, enter "0: Calibration mode end".
- Page 7 ●Ion calibration start command C, CI, x, ｙｙｙｙ, z [CR][LF] Auxiliary unit of calibration value unit to be set. 0：- 1：μ 2：m Follows the unit setting for mol/L or g/L. Calibration value to be set Channel (1 or 2) Name Header Starts the ion calibration when waiting for ion calibration.
- Page 8 ●Conductivity cell constant calibration start command C, CD, ｙｙｙｙｙ, z [CR][LF] Auxiliary unit of calibration value unit to be set. 0: - 1: μ 2: m Follows the unit setting for S/m or S/cm. No limit for input value when automatic calibration is ON. Calibration solution concentration to be set Even if the automatic calibration is set to ON, it is necessary to enter the calibration value (It will not be used).
- Page 9 ●Calibration clear command C, CC, x [CR][LF] Channel (1 or 2) Name (Calibration clear) Header Clears the calibration data in the measurement mode. ●Data IN command C, IN [CR][LF] Name (Data IN) Header Stores the measurement data.
- Page 10 ・Command function list (Request data) Command Item Function Header Name Request of the calibration Gets the latest calibration history of pH. history of pH Request of the calibration Gets the latest calibration history of ion. history of ion Request of the calibration Gets the latest calibration history of conductivity.
- Page 11 ●Request command and response of the calibration history of pH Request command R, PC, x [CR][LF] Channel Name (Request of calibration history of pH) Header...
- Page 12 Response from pH meter RPC, x, x, x, x, Xxxxx.x, x, （⇒） Inspection before use 0: No 1: Yes Asymmetry potential (7 digits including symbol) ±XXXX.X Temperature setting 1 digit 0: ATC 1: MTC Calibration result 0: good Calibration points 1 digit 1 to 5 Channel 1 digit 1: CH1 2: CH2 Header Slope (sensitivity) (5 digits including decimal point and symbol)
- Page 13 Response from the instrument if it does not have the calibration data RPC,************,x,0,3 Channel 1 digit 1:CH1 2:CH2 Display format is fixed. If no data exist, [SP] is displayed. The number of transmitted calibration data is the number of calibration points. Displayed calibration date and time is the latest calibration date and time.
- Page 14 ●Request command and response of the calibration history of ion Request command R, IC, x [CR][LF] Channel Name (Request of the calibration history of ion) Header Collects the ion data under selection.
- Page 15 Response from pH meter RIC, x, x, x, x, Xxxxx.x, X, X, （⇒） Unit 0: g/L 1: mol/L Ion type 0: -2 1: -1 2: +1 3: +2 Asymmetry potential (7 digits including symbol) [SP][SP][SP][SP][SP][SP][SP] is output as the asymmetry potential of ion. Temperature setting 1 digit 0: ATC 1: MTC Calibration result 0: good Calibration points 1 digit 1 to 5...
- Page 16 Response from the instrument if it does not have the calibration data RIC,************,x,0,3 Channel 1 digit 1:CH1 2:CH2...
- Page 17 ●Request command and response of the calibration history of conductivity Request command R, CC [CR][LF] Name (Request of the calibration history of conductivity) Header...
- Page 18 Response from pH meter RCC, x, x, x, （⇒） Temperature setting 1 digit 0: ATC 1: MTC Calibration result 0: good Channel 1 digit 1: CH1 2: CH2 Header （⇒） Range 5 xxxx, xx, xx, xx, xx, xx, xxx.x xxx.x, X, Xxxx.x, Xxxxx.x, X.XXX calibration data Range 4...
- Page 19 ●Request command and response of the measurement value Request command R, MD, x [CR][LF] Channel Name (Request of the measurement value) Requests the measurement value of the specified channel. Header...
- Page 20 Response from pH meter RMD, xxxx, xx, x, x, x, x, xxxx, xx, xx, xx, xx, xx, （⇒） Second 2 digits 00 to 59 Minute 2 digits 00 to 59 Hour 2 digits 00 to 23 Day 2 digits 01 to 31 Month 2 digits 01 to 12 Year 4 digits A.D.
- Page 21 ※Matches the displayed digit of each component to the display specifications. -2.000 to 16.000 -2000.0 to 2000.0 0.000 to 9999 Conductivity 0.000 to 1999 Resistivity 0.000 to 200.0 Salinity (%) 0.000 to 10.000 Salinity (PPT) 0.00 to 100.00 0.00 to When the measurement value is Or (Ur), the character string Or or Ur is displayed instead of upper and lower limit values.
- Page 22 ●Request command and response of the clock data Request command R, OT [CR][LF] Name (Request of clock data) Requests the clock data. Header Response from pH meter ROT, xxxx, xx, xx, xx, xx, xx [CR][LF Second 2 digits 00 to 59 Minute 2 digits 00 to 59 Hour 2 digits 00 to 23 Day 2 digits 01 to 31...
- Page 23 ●Request command and response of memory data Request command R, MS, xxx, x [CR][LF] Channel (1 or 2) Memory number Name (Request of the measurement value) Requests the memory data to be specified. Header...
- Page 24 Response from pH meter RMS, xxxx, xxxx,（⇒） Sample ID Memory number Header （⇒） xx, x, x, x, x, xxxx, xx, xx, xx, xx, xx, Xxxxxxx, （⇒） Measurement value max. 7 digits ※Matches the displayed digit of each component to the display specifications. -2.000 to 16.000 -2000.0 to 2000.0 0.000 to...
- Page 25 （⇒） x, x, x, Xxxxxx, Xxxxxxx, x [CR][LF] Error state 2: Upper limit alarm 1: Lower limit alarm 0: No alarm Potential 7 digits （Leading zero suppression） Temperature (6 digits including decimal point) -30.0 to 130.0 Right-justified When the temperature value is Or (Ur), the character string Or or Ur is displayed instead of an upper or lower limit value.
- Page 26 ●Alarm inquiry command and response Request command R, AL, x, y [CR][LF] Request mode 0: Instrument alarm 1: pH 2: mV 3: Ion 4: Conductivity, salinity, resistivity Channel Name (Alarm inquiry) Header Requests the alarm code in the instrument. Response from pH meter RAL, x, ｙ, zzzzzzzz [CR][LF] Error code Request mode...
- Page 27 ●Alarm clear command and response Request command R, AR [CR][LF] Name (Alarm clear) Header OK [CR][LF]...
