Summary of Contents for Schulthess Spirit 610
- Page 1 Operating instructions Heat pump dryer Spirit 610...
- Page 2 Symbols Please read the instructions. Warnings are marked with a warning triangle. The text gives information how a dangerous situation can be avoided. Signal words indicate the severity of the danger, if not avoided. Warning means that possible personal inju- ries, and potentially life-threatening injuries may occur.
- Page 3 Please read these instructions carefully to enable you to use all the possibilities and advantages of your new dryer. Please note in particular the safety informations. We hope you will be very happy with your new Schulthess dryer. Your Schulthess Maschinen AG...
-
Page 4: Table Of Contents
Contents Safety and safety measures ..........6 Disposal . - Page 5 Emptying for frost protection or transport ........30 Self-cleaning .
-
Page 6: Safety And Safety Measures
Safety and safety measures Do not let children carry out clean- ing and user maintenance without supervision. The enclosed documents contain Safety while handling important information on the instal- and operating lation, use and safety of the dryer. Keep the documents safe for other users or subsequent owners. - Page 7 Always unplug the machine from Components sticking out from the ► the power source before carrying machine (e.g. loading door) may out maintenance work. break off and cause injuries, when If the machine is not needed for used for lifting. ►...
- Page 8 Do not dry textiles in the dryer Children may lock themselves in the ► which have been in contact / cov- machine – this is a life-threatening ered with setting lotion, nail polish situation. remover or similar agents. Ensure that an old appliance can no Do not dry items made of foam longer be used: ►...
- Page 9 Observe when drying The fluff filters must be inserted when operating this machine. ► Never operate the machine with damaged fluff filters. Keep the area surrounding the ► dryer free of dust and fluff. The fluff filters must be cleaned ►...
-
Page 10: Disposal
Disposal Packaging from your new machine The advance recycling fee (vRG) All packaging materials used are environ- The advance recycling fee is already con- mentally friendly and reusable. Return the tained within the price of a new machine. packaging to the retailer or supplier. The current disposal of old machines is Dispose of all packaging materials properly. -
Page 11: Environmentally Compatible Drying
Environmentally Preparing the laundry compatible drying Do up all zips, hooks and eyes. ► Button up duvet covers and pillowcases. ► Tie together loose belts, apron strings Notice etc. Wringing wet laundry: waste of energy! Drying the laundry Remove as much water as possible from ►... -
Page 12: Machine Description
Machine description Control and display area Loading door Cooling grid... - Page 13 Cotton Extra dry Cotton Cabinet dry Easy Care Cabinet dry Display and buttons On / Off Back in the menu Scroll backwards Scroll forwards Start programme Open the door Standard programme Settings Page number programme menu...
-
Page 14: Drying
Drying Preparing the appliance Selecting programme Check whether the fluff filters are ► in place (see Drying / Clean fluff Cotton Extra dry filters). Switch on the power supply. ► Cotton Cabinet dry Turn on machine Easy care Cabinet dry On / Off Press button ►... -
Page 15: Starting The Programme
Skipping to the next Adding laundry programme step Make sure that there is no foreign body ► in the drum and the detergent drawer Cotton (coins, nails, paper clips, etc.). 1:08 h max. 8.0 kg Cabinet dry Distribute the laundry evenly in the ►... -
Page 16: Interrupting The Programme
Interrupting the programme Cotton 0:01 h max. 8.0 kg Cabinet dry On / Off Press button until the ► Gentle following window is displayed: Programme stopped Cancel Forward The programme will end. After cancelling, remove washing imme- ► diately and spread it out so that it can Stop Continue cool down. -
Page 17: Programme End
Cleaning the fluff filters Programme stopped When fabrics are used, the fibres Add laundry and close door. are rubbed (laundry fluff), which are released when the fabrics are dried, collecting in the fluff filters in the door opening. Follow the directions on the display. ►... - Page 18 Rub your hand over the inside of the Rub your hand over the inside of the ► ► filter to remove the fluff. filter to remove the fluff. Replace the fluff filter and make sure it Replace the fluff filter and make sure it ►...
-
Page 19: Switching Off The Machine
Switching off the machine On / Off Press button until ► the display turns off. Unplug the machine, when not used ► for longer periods of time. -
Page 20: Programme Survey
Programme survey Always check the care symbols on the fabrics h:min = Duration / rpm = Spin speeds / kWh = Power consumption (approximate values) Most efficient programme for cotton textiles according to regulation (EU) no. 932 / 2012 The following standard programme (marked with ) is suitable for drying normally wet cotton textiles and is most efficient regarding the combined energy consumption. -
Page 21: Easy Care Laundry
h:min 8,0 kg Cotton Extra dry Towelling bathrobs and bed linen 2:15 1200 (no underwear or socks) 2:03 1400 ► For particularly thick or multilayered fabrics 1:48 1600 Easy care laundry Non-iron synthetic and mixed fibres and cotton with non-iron trim, e.g. viscose, cupro, modal, polyester h:min 4,0 kg Easy care Iron damp... -
Page 22: Time Drying
Time drying h:min Time drying 7,0 kg For extra drying time for multi-layer textlies (e.g. sleeping – – – bags) or for drying single laundry items, such as for example terry towelling ► Time drying warm (10 min – 2 h 30 min) 1,4 kg Reconditioning The laundry is aired without adding additional temperature... -
Page 23: Programme Options
Programme options By also selecting one or more options, ► 1:52 h Programme end 04.09. 13:15h a wash programme can be specifically max. 7 kg tailored to the particular characteristics − Date of the laundry. − Time Programme options are only activated ►... -
Page 24: Drying
Drying + Express With this option the dryness level can For drying reduced laundry loads or be increased temporarily – for the single items made of cotton, synthetic duration of the selected programme. or mixed fabrics. Notice To increase the dryness level in gen- eral (for all programmes), the function Dryness level increased must be... -
Page 25: Settings
Settings Your dryer has basic settings from the Select the desired settings. ► factory. The settings can be adapted to Additional menu pages can be opened arrow buttons the users individual needs either when by pressing the first used or later using the following functions. -
Page 26: Menu Settings
Menu Settings Display programme time Duration * ► * = Default setting The display shows the remaining time of the programme. Language ► English * ► The display shows when the programme ..► will be finished. Additional menu pages can be opened arrow buttons by pressing the Brightness display... - Page 27 Dryness level raised Crease protection Off * ► ► 30 min * ► ► ► ► At the end of the programme a crease ► The dryness level can be adjusted as protection phase (loosening up of a general setting. Then it affects all laundry) for 30 minutes or 6 hours can programmes until the next change in be set.
- Page 28 Waking up machine On / Off Press button ► Automatic door opening Off * ► ► If this function is switched on, the door will open automatically at the end of the programme. Default settings The settings can be reset to default (state as delivered).
-
Page 29: Cleaning And Maintenance
Cleaning and Maintenance Caution Cleaning the fluff filters Drying / Cleaning the fluff Danger of electric shock! filters. Switch off the power supply to the ► machine before cleaning. Cleaning the filter support Under no circumstances spray the ► machine with water. Do not use a steam cleaner. -
Page 30: Cleaning The Moisture Sensor
Cleaning the moisture sensor Self-cleaning After longer operation, small deposits (lime, fabric refiner) can form on the The dryer is equipped with an automatic front inner side of the drum on both self-cleaning function. sides of the longish moisture sensors. At the end of each programme and also With moisture controlled programmes, during the drying process, if necessary,... -
Page 31: Problems
Problems Warning Improper repairs can result in severe accidents, damages and operation malfunctions! Do not make any changes, manipulations or attempt repairs using tools such as screw- drivers, etc. E R RO R ME SSAG E S ON T H E D IS PL AY (is not lit!) and at the Child lock active... - Page 32 M ACH IN E OP ER AT I ON Machine does not Check whether the mains power is switched on (wall / plug). ► start when pressing Check whether all the fuses are intact or the safety switch ► the On / Off has tripped.
- Page 33 The fluff filters are blocked with fluff or scale deposits. Drying / Cleaning the fluff Clean the fluff filters (see ► filters). Drum lighting does The LED is defective. not work For safety reasons the LED must only be replaced by the customer service or a qualified specialist.
-
Page 34: Technical Specifications
Technical specifications Product data sheet for household washing dryer according to EC regulation no. 392 / 2012 Schulthess Model name / label Spirit 610 Nominal capacity kg 8,0 Dryer type Heat pump dryer Energy efficiency class A +++ (highest efficiency) to D (lowest efficiency) -
Page 35: Customer Service
Customer service Schulthess Maschinen AG produces wash- Our service number 0844 888 222 can be ing machines and dryers of outstanding reached from Monday to Friday from 08:00 quality with proverbial durability. Hence, to 12:00 hrs and 13:00 to 17:00 hrs. - Page 36 Headquarters and Production Schulthess Maschinen AG / SA Landstrasse 37, 8633 Wolfhausen ZH Tel. + 41 (0) 55 253 51 11 www.schulthess.ch Österreich Schulthess Maschinen GmbH A-1130 Wien, Hetzendorferstrasse 191 Tel. + 43 (0) 1 803 98 00 www.schulthess.at Brief instruction Follow the safety instructions in this manual! Turn on the power switch and open the water tap.
