C
DCN-981
B
DCN-969
O
EDN-018
№
EDN/DCN
106-03-003
取 扱 説 明 書
INSTRUCTION MANUAL
6274
0.5mm Pitch FPC/FFC Connector
2017/10/12
A. Murata
2017/10/05
A. Murata
2003/12/26
G. Kajiwara
DATE
PREPARED by
Series
F. Ikegami
T. Satoh
CHECKED by
DIV.03
No. : 205-03-200
Y. Fujii
Y. Fujii
N. Hayashi
APPROVED by
