KDC-BT630U
KDC-BT530U
CD-RECEIVER
INSTRUCTION MANUAL
© 2018 JVC KENWOOD Corporation
B5A-2598-00 (MN)

Advertisement

Table of Contents
loading

Summary of Contents for Kenwood KDC-BT630U

  • Page 1 KDC-BT630U KDC-BT530U CD-RECEIVER INSTRUCTION MANUAL © 2018 JVC KENWOOD Corporation B5A-2598-00 (MN)
  • Page 2: Table Of Contents

    CONTENTS BEFORE USE BEFORE USE IMPORTANT • To ensure proper use, please read through this manual before using this product. It is especially important that you read and observe Warnings BASICS and Cautions in this manual. GETTING STARTED • Please keep the manual in a safe and accessible place for future reference. 1 Select the display language WARNING and cancel the demonstration...
  • Page 3: Basics

    BASICS Faceplate Remote control (RC-406) (supplied for Display window Remote sensor (Do not expose to bright Volume Loading sunlight.) knob slot Pull out the insulation sheet when Lights up when using for the first time. Bluetooth connection is : Can be remotely controlled with an optionally established.
  • Page 4: Getting Started

    GETTING STARTED Turn the volume knob to make the settings, then press the knob. Hour Minute Turn the volume knob to select [CLOCK FORMAT], then press the knob. Turn the volume knob to select [12H] or [24H], then press the knob. To set the date Turn the volume knob to select [DATE FORMAT], then press the knob.
  • Page 5 • The speakers may damage. • The output sound level may be extremely high or low. [F/W UP xxxx] [YES]: Starts upgrading the firmware. ; [NO]: Cancels (upgrading is not activated). For details on how to update the firmware, visit <www.kenwood.com/cs/ce/>. ENGLISH...
  • Page 6: Radio

    RADIO Other settings Press the volume knob to enter [FUNCTION]. Turn the volume knob to select an item (see the following table), then press the knob. Repeat step 2 until the desired item is selected/activated or follow the instructions stated on the selected item. Press and hold to exit.
  • Page 7 RADIO Preparation: [TI] [ON]: Allows the unit to temporarily switch to Traffic Information if • Select [ON] for [BUILT-IN AUX] in [SOURCE SELECT]. (Page 5) available (“TI” lights up). ; [OFF]: Cancels. [PTY SEARCH] 1 Turn the volume knob to select the available Program Type (see below), Start listening then press the knob.
  • Page 8: Cd/Usb/Ipod/Android

    CD/USB/iPod/ANDROID Start playback Selectable source: : CD/USB/iPod USB/ The source changes automatically and playback starts. ANDROID : CD/USB/ANDROID Eject disc Label side On the faceplate On the remote control Play back/pause Press 6 IW. Press ENT IW. Reverse/Fast-forward*4 Press and hold S / T. Press and hold S / T (+).
  • Page 9 KENWOOD Remote application is connected. (Page 10) Preparation: • Pressing and holding S / T searches at a 10% ratio. • Install the latest version of KENWOOD Remote application on your device before Alphabet search (applicable only for iPod USB source or iPod BT connecting.
  • Page 10: Spotify

    Spotify CD/USB/iPod/ANDROID You can listen to Spotify on the following devices via USB input terminal (see Direct Music Search (using the remote control) the following) or via Bluetooth (page 12). Press DIRECT. : iPhone/iPod (via Bluetooth or via USB input terminal) or Press the number buttons to enter a track/file number.
  • Page 11 Spotify Search for a song or station On the faceplate On the remote control Start radio Press and hold 5. ( Not available ) Press Turn the volume knob to select a list type, then press the knob. Repeat play*5 Press 4 repeatedly.
  • Page 12: Bluetooth

    BLUETOOTH® BLUETOOTH — Connection Depending on the operating system and the firmware version of your mobile phone, Bluetooth features may not work with this unit. Supported Bluetooth profiles – Hands-Free Profile (HFP) – Advanced Audio Distribution Profile (A2DP) Pair and connect a Bluetooth device for the first time –...
  • Page 13 BLUETOOTH® The following operations may differ or be unavailable depending on the Auto Pairing (for connected phone. When you connect iPhone/iPod touch to the USB input terminal, pairing On the faceplate On the remote control request (via Bluetooth) is automatically activated. First incoming call...
  • Page 14 BLUETOOTH® *1 This adjustment will not affect the volume of the other sources. Make a call *2 Press and hold VOL to continuously increase the volume to 15. *3 Operations may vary according to the connected Bluetooth device. You can make a call from the call history, phonebook, or dialing the number. Call by voice is also possible if your mobile phone has the feature.
  • Page 15 BLUETOOTH® Make a call using voice recognition [PHONE BOOK] (Applicable only if the phone supports PBAP.) 1 Turn the volume knob quickly to enter alphabet search mode (if the Press and hold to activate the voice recognition of the connected phonebook contains many contacts).
  • Page 16 BLUETOOTH® Other settings [INITIALIZE] [YES]: Initializes all the Bluetooth settings (including stored pairing, phonebook, and etc.). ; [NO]: Cancels. Press the volume knob to enter [FUNCTION]. Turn the volume knob to select an item (see the following table), then press the knob. Bluetooth test mode Repeat step 2 until the desired item is selected/activated or follow the You can check the connectivity of the supported profile between the...
  • Page 17 BLUETOOTH® BLUETOOTH — Audio On the faceplate On the remote control Repeat play Press 4 repeatedly. ( Not available ) [ALL REPEAT], [FILE REPEAT], [REPEAT OFF] Random play Press and hold 3 to select [ALL RANDOM]. ( Not available ) • Press 3 to select While in BT AUDIO source, you can connect to five Bluetooth audio devices [RANDOM OFF].
  • Page 18 [YES]: Selects Android smartphone to use the application via Bluetooth. ; [NO]: Cancels. Preparation: [ANDROID LIST]* Selects the Android smartphone to use from the list. • Install the latest version of KENWOOD Remote application [STATUS] Shows the status of the selected device.
  • Page 19: Audio Settings

    AUDIO SETTINGS BLUETOOTH® Internet radio via Bluetooth You can listen to internet radio (Spotify) on the following devices via Bluetooth on this unit. • Make sure the USB input terminal is not connected to any device. : iPhone/iPod touch/Android device : Android device Press the volume knob to enter [FUNCTION].
  • Page 20 AUDIO SETTINGS [MANUAL EQ] Adjusts your own sound settings for each source. [SOUND EFFECT] • The settings are stored to [USER] in [PRESET EQ]. [SOUND RECNSTR] (Not applicable for RADIO source and AUX source.) • The settings made may affect the current settings of [EASY EQ]. (Sound [ON]: Creates realistic sound by compensating the high-frequency [62.5HZ]...
  • Page 21 AUDIO SETTINGS 2-way crossover setting items Crossover settings Below are the available setting items for 2-way crossover and 3-way [SPEAKER SIZE] crossover. [FRONT] [SIZE] [8CM]/[10CM]/[12CM]/[13CM]/[16CM]/[17CM]/ [18CM]/[4×6]/[5×7]/[6×8]/[6×9]/[7×10] SPEAKER SIZE Selects according to the connected speaker size for optimum performance. [TWEETER] [SMALL]/[MIDDLE]/[LARGE]/[NONE] (not •...
  • Page 22 AUDIO SETTINGS [SUBWOOFER [SW LPF FRQ] [30HZ]/[40HZ]/[50HZ]/[60HZ]/[70HZ]/[80HZ]/ [MID RANGE] [HPF FRQ] [30HZ]/[40HZ]/[50HZ]/[60HZ]/[70HZ]/[80HZ]/[90HZ]/ LPF]*1*2 [90HZ]/[100HZ]/[120HZ]/[150HZ]/[180HZ]/[220HZ]/ [100HZ]/[120HZ]/[150HZ]/[180HZ]/[220HZ]/[250HZ]/ [250HZ]/[THROUGH] [THROUGH] [SW LPF SLOPE] [–6DB]/[–12DB]/[–18DB]/[–24DB] [HPF SLOPE] [–6DB]/[–12DB] [SW LPF PHASE] [REVERSE] (180°)/[NORMAL] (0°) [LPF FRQ] [1KHZ]/[1.6KHZ]/[2.5KHZ]/[4KHZ]/[5KHZ]/[6.3KHZ]/ [8KHZ]/[10KHZ]/[12.5KHZ]/[THROUGH] [SW LPF GAIN] [–8] to [0] [LPF SLOPE] [–6DB]/[–12DB] [PHASE]...
  • Page 23 AUDIO SETTINGS • Before making an adjustment for [DISTANCE] and [GAIN] of [DTA SETTINGS], Digital Time Alignment settings select the speaker you want to adjust: Digital Time Alignment sets the delay time of the speaker output to create a When 2-way crossover is selected: more suitable environment for your vehicle.
  • Page 24: Display Settings

    DISPLAY SETTINGS : Zone identification for color settings and brightness settings Default: [XX] [DISPLAY] [COLOR SELECT] (For Selects illumination colors for [ALL ZONE], [ZONE 1] and [ZONE 2] separately. 1 Select a zone ([ZONE 1], [ZONE 2], [ALL ZONE]). (See the illustration on the left column.) 2 Select a color for the selected zone.
  • Page 25: References

    • When removing a disc from this unit, pull it out horizontally. • Remove burrs from the center hole and disc edge before inserting a disc. More information For: – Latest firmware updates and latest compatible item list – KENWOOD original application – Any other latest information Visit <www.kenwood.com/cs/ce/>. General •...
  • Page 26 • Playable audio file: • You cannot operate iPod if “KENWOOD” or “ ” is displayed on iPod. For disc: MP3 (.mp3), WMA (.wma), AAC (.aac) • Depending on the version of the operating system of the iPod/iPhone, some functions may not For USB mass storage class device: operate on this unit.
  • Page 27 REFERENCES Change the display information BT AUDIO Song title/Artist Album title/Artist Playing time Date back to the Each time you press DISP, the display information changes. beginning • If the information is unavailable or not recorded, “NO TEXT”, “NO INFO”, or other information Source name Date back to the beginning...
  • Page 28: Troubleshooting

    TROUBLESHOOTING Symptom Remedy Symptom Remedy Sound cannot be heard. • Adjust the volume to the optimum level. Disc cannot be ejected. Press and hold to forcibly eject the disc. Be careful not • Check the cords and connections. to drop the disc when it is ejected. If this does not solve the problem, reset the unit (page 3).
  • Page 29 TROUBLESHOOTING Symptom Remedy Symptom Remedy The iPod/iPhone does not • Check the connection between this unit and iPod/iPhone. Playback is intermittent or Turn off the power saving mode on the Android device. turn on or does not work. • Disconnect and reset the iPod/iPhone using hard reset. sound skips.
  • Page 30: Installation Connection

    INSTALLATION/CONNECTION TROUBLESHOOTING Warning Symptom Remedy • The unit can only be used with a 12 V DC power supply, negative ground. Voice calling method is not • Use voice calling method in a more quiet environment. • Disconnect the battery’s negative terminal before wiring and mounting. successful.
  • Page 31: Removing The Unit

    INSTALLATION/CONNECTION Part list for installation Installing the unit (in-dash mounting) (A) Faceplate (×1) (B) Trim plate (×1) Do the required wiring. (Page 32) (C) Mounting sleeve (×1) (D) Wiring harness (×1) Hook on the top side Orientate the trim Dashboard of plate as illustrated your car before fitting.
  • Page 32: Wiring Connection

    If no connections are made, do not let the wire come out from the tab. White/Black For 3-way crossover: Mid range speaker (left) Gray Brown To front speaker (right)/ To connect the KENWOOD navigation system, refer your Gray/Black For 3-way crossover: Mid range speaker (right) (Mute control wire) navigation manual Green...
  • Page 33: Specifications

    SPECIFICATIONS INSTALLATION/CONNECTION Connecting external components FM Frequency Range 87.5 MHz — 108.0 MHz (50 kHz step) Usable Sensitivity 8.2 dBf (0.71 μV/75 Ω) (S/N = 30 dB) Quieting Sensitivity 17.2 dBf (2.0 μV/75 Ω) (DIN S/N = 46 dB) Frequency Response (±3 dB) 30 Hz —...
  • Page 34 SPECIFICATIONS Dynamic Range 92 dB Maximum Output Power 50 W × 4 Channel Separation 90 dB Full Bandwidth Power 22 W × 4 (at less than 1 % THD) MP3 Decode Compliant with MPEG-1/2 Audio Layer-3 Speaker Impedance 4 Ω — 8 Ω WMA Decode Compliant with Windows Media Audio Tone Action...
  • Page 35 • The Bluetooth® word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc. and any use of such marks by JVC KENWOOD Corporation is under license. Other trademarks and trade names are those of their respective owners.
  • Page 36 SOFTWARE LICENSE AGREEMENT Article 4 Right pertaining to the Licensed Software Any and all copyrights and other rights pertaining to the Licensed Software and related documents The software embedded in the Product (hereinafter the "Licensed Software") provided by Licensor is shall belong to the Licensor or the original holder of the right who granted to the Licensor the license or copyrighted to or sublicensable by the Licensor, and this Agreement provides for the terms and conditions sublicense for the Licensed Software (hereinafter the "Original Rightholder"), and the User shall not be...
  • Page 37 Important Notice concerning the Software Article 10 Protection of Copyright -jansson 1. The copyright and all the other intellectual property rights relating to the Licensed Software shall belong to the Licensor Copyright (c) 2009-2012 Petri Lehtinen <petri@digip.org> and the Original Rightholder, and in no event shall they be Permission is hereby granted, free of charge, to any person obtaining a copy of this software and associated documentation files (the "Software"), under the ownership of the User.
  • Page 38 • The Bluetooth® word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc. and any use of such marks by JVC KENWOOD Corporation is under license. Other trademarks and trade names are those of their respective owners.
  • Page 39 ‫ﺍﻟﻤﻮﺍﺻﻔﺎﺕ‬ 4 × ‫05 ﻭﺍﻁ‬ ‫ﻗﺪﺭﺓ ﺍﻟﺨﺮﺝ ﺍﻟﻘﺼﻮﻯ‬ ‫29 ﺩﻳﺴﻴﺒﻞ‬ ‫ﺍﻟﻤﺠﺎﻝ ﺍﻟﺪﻳﻨﺎﻣﻴﻜﻲ‬ 4 × ‫22 ﻭﺍﻁ‬ ‫ﻗﺪﺭﺓ ﺳﻌﺔ ﻧﻄﺎﻕ ﺍﻟﺒﺚ ﺍﻟﻜﺎﻣﻞ‬ ‫09 ﺩﻳﺴﻴﺒﻞ‬ ‫ﻓﺼﻞ ﺍﻟﻘﻨﻮﺍﺕ‬ ‫)ﻋﻨﺪ ﺃﻗﻞ ﻣﻦ 1% ﺇﺟﻤﺎﻟﻲ ﺗﺸﺘﺖ‬ MPEG-1/2 Audio Layer-3 ‫ﻣﺘﻮﺍﻓﻖ ﻣﻊ‬ MP3 ‫ﻓﻚ ﺷﻔﺮﺓ‬ (‫ﺍﻟﺼﻮﺕ‬ Windows Media Audio ‫ﻣﺘﻮﺍﻓﻖ...
  • Page 40 ‫ﺍﻟﻤﻮﺍﺻﻔﺎﺕ‬ ‫ﺍﻟﺘﺮﻛﻴﺐ/ﺍﻟﺘﻮﺻﻴﻞ‬ ‫ﺗﻮﺻﻴﻞ ﻣﻜﻮﻧﺎﺕ ﺧﺎﺭﺟﻴﺔ‬ (‫5.78 ﻣﻴﺠﺎﻫﺮﺗﺰ — 0.801 ﻣﻴﺠﺎﻫﺮﺗﺰ )05 ﻛﻴﻠﻮ ﻫﺮﺗﺰ ﻟﻠﺨﻄﻮﺓ‬ ‫ﻧﻄﺎﻕ ﺍﻟﺘﺮﺩﺩ‬ (‫ 2.8 )17.0 ﻣﻴﻜﺮﻭ ﻓﻮﻟﺖ/57 ﺍﻭﻡ‬dBf ‫ﺍﻟﺤﺴﺎﺳﻴﺔ ﺍﻟﻘﺎﺑﻠﺔ ﻟﻼﺳﺘﺨﺪﺍﻡ‬ (‫ = 03 ﺩﻳﺴﻴﺒﻞ‬S/N) (‫ 2.71 )0.2 ﻣﻴﻜﺮﻭ ﻓﻮﻟﺖ/57 ﺍﻭﻡ‬dBf ‫ﺗﻬﺪﺋﺔ ﺍﻟﺤﺴﺎﺳﻴﺔ‬ (‫ = 64 ﺩﻳﺴﻴﺒﻞ‬DIN S/N) ‫03 ﻫﺮﺗﺰ...
  • Page 41 .‫ﺇﺫﺍ ﻟﻢ ﻳﺘﻢ ﻋﻤﻞ ﺃﻳﺔ ﺗﻮﺻﻴﻼﺕ، ﻓﻼ ﺗﺠﻌﻞ ﺍﻟﺴﻠﻚ ﻳﺒﺮﺯ ﻣﻦ ﺍﻟﺸﺮﻳﻂ‬ ‫ﻟﻠﺘﻌﺪﻳﺔ 3 ﻗﻨﻮﺍﺕ: ﺳﻤﺎﻋﺔ ﻣﺘﻮﺳﻄﺔ ﺍﻟﻨﻄﺎﻕ‬ ‫ﺃﺑﻴﺾ/ﺃﺳﻮﺩ‬ (‫)ﺍﻟﻴﺴﺮﻯ‬ ‫ﺭﻣﺎﺩﻱ‬ /(‫ﺇﻟﻰ ﺍﻟﺴﻤﺎﻋﺔ ﺍﻷﻣﺎﻣﻴﺔ )ﺍﻟﻴﻤﻨﻰ‬ ‫ﺑﻨﻲ‬ ،KENWOOD ‫ﻟﺘﻮﺻﻴﻞ ﻧﻈﺎﻡ ﺍﻟﻤﻼﺣﺔ ﻣﻦ‬ ‫ﺭﻣﺎﺩﻱ/ﺃﺳﻮﺩ‬ ‫ﻟﻠﺘﻌﺪﻳﺔ 3 ﻗﻨﻮﺍﺕ: ﺳﻤﺎﻋﺔ ﻣﺘﻮﺳﻄﺔ ﺍﻟﻨﻄﺎﻕ‬ ‫)ﺳﻠﻚ ﺍﻟﺘﺤﻜﻢ ﻓﻲ ﻛﺘﻢ‬ ‫ﻋﻠﻴﻚ ﺑﺎﻟﺮﺟﻮﻉ ﺇﻟﻰ ﺩﻟﻴﻞ ﺍﻟﻤﻼﺣﺔ‬ (‫)ﺍﻟﻴﻤﻨﻰ‬ ‫ﺃﺧﻀﺮ‬...
  • Page 42 ‫ﺍﻟﺘﺮﻛﻴﺐ/ﺍﻟﺘﻮﺻﻴﻞ‬ ‫ﻗﺎﺋﻤﺔ ﻗﻄﻊ ﺍﻟﻐﻴﺎﺭ ﺍﻟﻤﺴﺘﺨﺪﻣﺔ ﻓﻲ ﺍﻟﺘﺮﻛﻴﺐ‬ (‫ﺗﺮﻛﻴﺐ ﺍﻟﻮﺣﺪﺓ )ﺩﺍﺧﻞ ﺗﺎﺑﻠﻮ ﺍﻟﺴﻴﺎﺭﺓ‬ (1×) ‫ﻭﺣﺔ ﺍﻟﺰﻳﻨﺔ‬ (1×) ‫ﻭﺍﺟﻬﺔ ﺍﻟﺠﻬﺎﺯ‬ ‫ﻗﻢ ﺑﺘﻮﺻﻴﻞ ﺍﻷﺳﻼﻙ‬ (32 ‫ﺍﻟﻤﻄﻠﻮﺑﺔ. )ﺻﻔﺤﺔ‬ ‫ﺍﻟﺨﻄﺎﻑ ﻓﻲ‬ (1×) ‫ﺿﻔﻴﺮﺓ ﺍﻷﺳﻼﻙ‬ (1×) ‫ﺇﻃﺎﺭ ﺍﻟﺘﺮﻛﻴﺐ‬ ‫ﺍﻟﺠﺎﻧﺐ ﺍﻟﻌﻠﻮﻱ‬ ‫ﻳﺘﻢ ﺗﻮﺟﻴﻪ ﻟﻮﺣﺔ‬ ‫ﺗﺎﺑﻠﻮﻩ ﺍﻟﺴﻴﺎﺭﺓ‬ ‫ﺍﻟﺰﻳﻨﺔ ﺍﻷﻣﺎﻣﻴﺔ ﻛﻤﺎ ﻫﻮ‬ .‫ﻣﻮﺿﺢ...
  • Page 43 ‫ﺍﻟﺘﺮﻛﻴﺐ/ﺍﻟﺘﻮﺻﻴﻞ‬ ‫ﺍﻟﺒﺤﺚ ﻋﻦ ﺍﻻﻋﻄﺎﻝ ﻭﺍﻻﺻﻼﺡ‬ ‫ﺗﺤﺬﻳﺮ‬ ‫ﻣﻌﺎﻟﺠﺔ ﺍﻷﻋﻄﺎﻝ‬ ‫ﺍﻻﻋﺮﺍﺽ‬ .‫• ﻳﻤﻜﻦ ﺍﺳﺘﺨﺪﺍﻡ ﺍﻟﻮﺣﺪﺓ ﻓﻘﻂ ﻓﻲ ﺳﻴﺎﺭﺓ ﺑﻬﺎ ﻣﺼﺪﺭ ﺗﻴﺎﺭ ﻣﺒﺎﺷﺮ 21 ﻓﻮﻟﺖ، ﻭﺗﺄﺭﻳﺾ ﺳﻠﺒﻲ‬ .‫• ﺍﺳﺘﺨﺪﻡ ﻃﺮﻳﻘﺔ ﺍﻻﺗﺼﺎﻝ ﺍﻟﺼﻮﺗﻲ ﻓﻲ ﺑﻴﺌﺔ ﺃﻛﺜﺮ ﻫﺪﻭﺀ ﹰ ﺍ‬ ‫ﻃﺮﻳﻘﺔ ﺍﻻﺗﺼﺎﻝ ﺍﻟﺼﻮﺗﻲ‬ .‫• ﻗﻢ ﺑﻔﺼﻞ ﺍﻟﻄﺮﻑ ﺍﻟﺴﻠﺒﻲ ﻟﻠﺒﻄﺎﺭﻳﺔ ﻗﺒﻞ ﺗﻮﺻﻴﻞ ﺍﻷﺳﻼﻙ ﻭﺍﻟﺘﺮﻛﻴﺐ‬ ‫•...
  • Page 44 ‫ﺍﻟﺒﺤﺚ ﻋﻦ ﺍﻻﻋﻄﺎﻝ ﻭﺍﻻﺻﻼﺡ‬ ‫ﻣﻌﺎﻟﺠﺔ ﺍﻷﻋﻄﺎﻝ‬ ‫ﺍﻻﻋﺮﺍﺽ‬ ‫ﻣﻌﺎﻟﺠﺔ ﺍﻷﻋﻄﺎﻝ‬ ‫ﺍﻻﻋﺮﺍﺽ‬ .iPhone/iPod ‫• ﺍﻓﺤﺺ ﺍﻟﻮﺻﻠﺔ ﺑﻴﻦ ﻫﺬﻩ ﺍﻟﻮﺣﺪﺓ ﻭ‬ ‫ ﻻ ﺗﺼﻞ‬iPhone/iPod ‫ﺟﻬﺎﺯ‬ .Android ‫ﺍﻃﻔﺊ ﻭﺿﻊ ﺗﻮﻓﻴﺮ ﺍﻟﻄﺎﻗﺔ ﻋﻠﻰ ﺟﻬﺎﺯ‬ ‫ﻳﺘﻘﻄﻊ ﺍﻟﺘﺸﻐﻴﻞ ﺃﻭ ﻳﺘﻢ‬ ‫ ﻭﺃﻋﺪ ﺿﺒﻄﻪ ﺑﺎﺳﺘﺨﺪﺍﻡ ﺍﻹﻏﻼﻕ‬iPhone/iPod ‫• ﺍﻓﺼﻞ‬ .‫ﺇﻟﻴﻪ...
  • Page 45 ‫ﺍﻟﺒﺤﺚ ﻋﻦ ﺍﻻﻋﻄﺎﻝ ﻭﺍﻻﺻﻼﺡ‬ ‫ﻣﻌﺎﻟﺠﺔ ﺍﻷﻋﻄﺎﻝ‬ ‫ﺍﻻﻋﺮﺍﺽ‬ ‫ﻣﻌﺎﻟﺠﺔ ﺍﻷﻋﻄﺎﻝ‬ ‫ﺍﻻﻋﺮﺍﺽ‬ ‫ﻹﺧﺮﺍﺝ ﺍﻷﺳﻄﻮﺍﻧﺔ‬ ‫ﺍﺿﻐﻂ ﻣﻊ ﺍﻻﺳﺘﻤﺮﺍﺭ ﻋﻠﻰ‬ .‫ﺗﻌﺬﺭ ﺇﺧﺮﺍﺝ ﺍﻷﺳﻄﻮﺍﻧﺔ‬ ‫• ﺍﺿﺒﻂ ﻣﺴﺘﻮﻯ ﻗﻮﺓ ﺍﻟﺼﻮﺕ ﻋﻠﻰ ﺍﻓﻀﻞ ﻣﺴﺘﻮﻯ‬ .‫ﻻ ﻳﻤﻜﻦ ﺳﻤﺎﻉ ﺍﻟﺼﻮﺕ‬ ‫ﺑﺎﻟﻘﻮﺓ. ﻛﻦ ﺣﺮﻳﺼ ﹰ ﺎ ﻋﻠﻰ ﺃﻥ ﻻ ﺗﺴﻘﻂ ﺍﻷﺳﻄﻮﺍﻧﺔ ﻋﻨﺪ‬ .‫ﻣﻤﻜﻦ‬...
  • Page 46 ‫ﻣﺮﺍﺟﻊ‬ ‫ﺗﻐﻴﻴﺮ ﻣﻌﻠﻮﻣﺎﺕ ﺍﻟﺸﺎﺷﺔ‬ ‫ﻭﻗﺖ ﺍﻟﺘﺸﻐﻴﻞ‬ ‫ﺍﺳﻢ ﺍﻻﻟﺒﻮﻡ/ﺍﻟﻔﻨﺎﻥ‬ ‫ﻋﻨﻮﺍﻥ ﺍﻻﻏﻨﻴﺔ/ﺍﻟﻔﻨﺎﻥ‬ BT AUDIO .‫، ﺗﺘﻐﻴﺮ ﻣﻌﻠﻮﻣﺎﺕ ﺍﻟﺸﺎﺷﺔ‬DISP ‫ﻛﻠﻤﺎ ﺿﻐﻄﺖ ﻋﻠﻰ‬ ‫ﻋﻮﺩﺓ ﻟﻠﺒﺪﺍﻳﺔ‬ ‫ﺍﻟﺘﺎﺭﻳﺦ‬ ‫“ ﺃﻭ‬NO INFO” ‫“ ﺃﻭ‬NO TEXT” ‫• ﺍﺫﺍ ﻟﻢ ﺗﻜﻦ ﺍﻟﻤﻌﻠﻮﻣﺎﺕ ﻣﺘﻮﻓﺮﺓ ﺃﻭ ﺍﻧﻬﺎ ﻏﻴﺮ ﻣﺴﺠﻠﺔ، ﻳﻈﻬﺮ‬ ‫ﻋﻮﺩﺓ ﻟﻠﺒﺪﺍﻳﺔ‬ ‫ﺍﻟﺘﺎﺭﻳﺦ‬...
  • Page 47 .iPhone/iPod ‫ﺟﻬﺎﺯ‬ :‫• ﻣﻠﻒ ﺍﻟﺼﻮﺗﻴﺎﺕ ﺃﻭﺩﻳﻮ ﺍﻟﻘﺎﺑﻞ ﻟﻠﺘﺸﻐﻴﻞ‬ .iPod ‫“ ﺃﻭ ” “ ﻓﻲ ﺟﻬﺎﺯ‬KENWOOD” ‫ ﻓﻲ ﺣﺎﻟﺔ ﻇﻬﻮﺭ‬iPod ‫• ﻟﻦ ﻳﻤﻜﻨﻚ ﺗﺸﻐﻴﻞ ﺟﻬﺎﺯ‬ (.aac) AAC ،(.wma) WMA ،(.mp3) MP3 :‫ﻟﻠﻘﺮﺹ‬ ‫، ﻗﺪ ﻻ ﺗﻌﻤﻞ ﺑﻌﺾ ﺍﻟﻮﻇﺎﺋﻒ‬iPhone/iPod ‫• ﺍﻋﺘﻤﺎﺩﺍ ﻋﻠﻰ ﻧﺴﺨﺔ ﻧﻈﺎﻡ ﺍﻟﺘﺸﻐﻴﻞ ﺍﻟﺨﺎﺹ ﺑﺠﻬﺎﺯ‬...
  • Page 48 .‫• ﻋﻨﺪ ﺇﺯﺍﻟﺔ ﺃﺳﻄﻮﺍﻧﺔ ﻣﻦ ﻫﺬﺍ ﺍﻟﺠﻬﺎﺯ، ﺍﺳﺤﺒﻬﺎ ﻧﺤﻮ ﺍﻟﺨﺎﺭﺝ ﺃﻓﻘﻴ ﹰ ﺎ‬ .‫• ﻗﻢ ﺑﺈﺯﺍﻟﺔ ﺍﻟﻨﺘﺆﺍﺕ ﻣﻦ ﻓﺘﺤﺔ ﺍﻟﻤﻨﺘﺼﻒ ﻭﺣﺎﻓﺔ ﺍﻷﺳﻄﻮﺍﻧﺔ ﻗﺒﻞ ﻭﺿﻊ ﺃﺳﻄﻮﺍﻧﺔ‬ ‫ﻣﺰﻳﺪ ﻣﻦ ﺍﻟﻤﻌﻠﻮﻣﺎﺕ‬ ‫ﻟـ: – ﺁﺧﺮ ﺗﺤﺪﻳﺜﺎﺕ ﺍﻟﺒﺮﺍﻣﺞ ﺍﻟﺜﺎﺑﺘﺔ ﻭﺍﺣﺪﺙ ﻗﺎﺋﻤﺔ ﺑﻨﻮﺩ ﻣﺘﻮﺍﻓﻘﺔ‬ ‫ ﺍﻻﺻﻠﻲ‬KENWOOD ‫– ﺍﻟﺘﻄﺒﻴﻖ‬ ‫– ﺃﻱ ﻣﻦ ﺍﺣﺪﺙ ﺍﻟﻤﻌﻠﻮﻣﺎﺕ ﺍﻻﺧﺮﻯ‬ .<www.kenwood.com/cs/ce/> ‫ﻗﻢ ﺑﺰﻳﺎﺭﺓ‬ ‫ﻋﺎﻡ‬...
  • Page 49 ‫ﺇﻋﺪﺍﺩﺍﺕ ﺍﻟﺸﺎﺷﺔ‬ [XX] :‫ﺍﻓﺘﺮﺍﺿﻲ‬ ‫: ﺗﺤﺪﻳﺪ ﻣﻨﻄﻘﺔ ﻹﻋﺪﺍﺩﺍﺕ ﺍﻟﻠﻮﻥ ﻭﺇﻋﺪﺍﺩﺍﺕ ﺍﻟﺴﻄﻮﻉ‬ [DISPLAY] ‫)ﻟﻤﻮﺩﻳﻠﻲ‬ [COLOR SELECT] ‫[ ﺷﻜﻞ‬ZONE 2] ‫[ ﻭ‬ZONE 1] ‫[ ﻭ‬ALL ZONE] ‫ﻳﺨﺘﺎﺭ ﺍﻟﻮﺍﻥ ﺍﻻﺿﺎﺀﺓ ﻟﻜﻞ ﻣﻦ‬ .‫ﻣﻨﻔﺼﻞ‬ ‫[(. )ﺭﺍﺟﻊ ﺍﻻﺿﺎﺀﺓ ﻋﻠﻰ‬ALL ZONE] ،[ZONE 2] ،[ZONE 1]) ‫1 ﺍﺧﺘﺮ ﻣﻨﻄﻘﺔ‬ (.‫ﺍﻟﻌﻤﻮﺩ...
  • Page 50 ‫ﺇﻋﺪﺍﺩﺍﺕ ﺍﻟﺼﻮﺕ‬ ‫[، ﺍﺧﺘﺮ ﺍﻟﺴﻤﺎﻋﺔ ﺍﻟﺘﻲ‬DTA SETTINGS] ‫[ ﻓﻲ‬GAIN] ‫[ ﻭ‬DISTANCE] ‫• ﻗﺒﻞ ﻋﻤﻞ ﺍﻟﻀﺒﻂ ﻟﻠﺒﻨﺪ‬ ‫ﺇﻋﺪﺍﺩﺍﺕ ﻣﺤﺎﺫﺍﺓ ﺍﻟﻮﻗﺖ ﺍﻟﺮﻗﻤﻲ‬ :‫ﺗﺮﻳﺪ ﺿﺒﻄﻬﺎ‬ ‫ﻭﻇﻴﻔﺔ ﻣﺤﺎﺫﺍﺓ ﺍﻟﻮﻗﺖ ﺍﻟﺮﻗﻤﻲ ﺗﻀﺒﻂ ﻭﻗﺖ ﺍﻟﺘﺄﺧﻴﺮ ﻻﺧﺮﺍﺝ ﺍﻟﺴﻤﺎﻋﺔ ﻣﻦ ﺍﺟﻞ ﺧﻠﻖ ﺑﻴﺌﺔ ﺍﻛﺜﺮ‬ :‫ﻋﻨﺪﻣﺎ ﺗﻜﻮﻥ ﺗﻌﺪﻳﺔ ﻗﻨﺎﺗﻴﻦ ﻣﺨﺘﺎﺭﺓ‬ .‫ﻣﻼﺋﻤﺔ...
  • Page 51 ‫ﺇﻋﺪﺍﺩﺍﺕ ﺍﻟﺼﻮﺕ‬ /[80HZ]/[70HZ]/[60HZ]/[50HZ]/[40HZ]/[30HZ] /[80HZ]/[70HZ]/[60HZ]/[50HZ]/[40HZ]/[30HZ] [HPF FRQ] [MID RANGE] [SW LPF FRQ] SUBWOOFER] /[220HZ]/[180HZ]/[150HZ]/[120HZ]/[100HZ]/[90HZ] /[180HZ]/[150HZ]/[120HZ]/[100HZ]/[90HZ] 2*1*[LPF [THROUGH]/[250HZ] [THROUGH]/ [250HZ]/[220HZ] [HPF SLOPE] [SW LPF SLOPE] [–12DB]/[–6DB] [–24DB]/[–18DB]/[–12DB]/[–6DB] /[6.3KHZ]/[5KHZ]/[4KHZ]/[2.5KHZ]/[1.6KHZ]/[1KHZ] (0°) [NORMAL]/(180°) [REVERSE] [LPF FRQ] [SW LPF PHASE] [THROUGH]/[12.5KHZ]/[10KHZ]/[8KHZ] [0] ‫]8–[ ﺇﻟﻰ‬ [SW LPF GAIN] [LPF SLOPE] [–12DB]/[–6DB] ‫ﺑﻨﻮﺩ...
  • Page 52 ‫ﺇﻋﺪﺍﺩﺍﺕ ﺍﻟﺼﻮﺕ‬ ‫ﺑﻨﻮﺩ ﺇﻋﺪﺍﺩ ﺗﻌﺪﻳﺔ 2 ﻗﻨﻮﺍﺕ‬ ‫ﺇﻋﺪﺍﺩﺍﺕ ﺍﻟﺘﻌﺪﻳﺔ‬ .‫ﻓﻴﻤﺎ ﻳﻠﻲ ﺑﻨﻮﺩ ﺍﻹﻋﺪﺍﺩ ﺍﻟﻤﺘﺎﺣﺔ ﻟﻠﺘﻌﺪﻳﺔ ﺑﻘﺎﺗﻴﻦ ﺃﻭ ﺑﻌﺪﻳﺔ 3 ﻗﻨﻮﺍﺕ‬ [SPEAKER SIZE] /[17CM]/[16CM]/[13CM]/[12CM]/[10CM]/[8CM] [SIZE] [FRONT] SPEAKER SIZE [7×10]/[6×9]/[6×8]/[5×7]/[4×6]/[18CM] .‫ﻳﺨﺘﺎﺭ ﻭﻓﻘﺎ ﻟﺤﺠﻢ ﺍﻟﺴﻤﺎﻋﺔ ﺍﻟﻤﻮﺻﻮﻟﺔ ﻟﻀﻤﺎﻥ ﺍﻻﺩﺍﺀ ﺍﻻﻓﻀﻞ‬ ‫[ )ﻏﻴﺮ‬NONE]/[LARGE]/[MIDDLE]/[SMALL] .‫• ﻳﺘﻢ ﺿﺒﻂ ﺇﻋﺪﺍﺩﺍﺕ ﺍﻟﺘﺮﺩﺩ ﻭﺍﻻﻧﺤﺪﺍﺭ ﺗﻠﻘﺎﺋﻴﺎ ﻟﺘﻌﺪﻳﺔ ﺍﻟﺴﻤﺎﻋﺔ ﺍﻟﻤﺨﺘﺎﺭﺓ‬ [TWEETER] [X ‘...
  • Page 53 ‫ﺇﻋﺪﺍﺩﺍﺕ ﺍﻟﺼﻮﺕ‬ .‫ﻳﻀﺒﻂ ﺍﻋﺪﺍﺩﺍﺕ ﺍﻟﺼﻮﺕ ﺍﻟﺨﺎﺻﺔ ﺑﻚ ﻟﻜﻞ ﻣﺼﺪﺭ‬ [MANUAL EQ] [SOUND EFFECT] .[PRESET EQ] ‫[ ﻓﻲ ﺍﻟﻮﺿﻊ‬USER] ‫• ﺗﻢ ﺗﺨﺰﻳﻦ ﺍﻹﻋﺪﺍﺩ ﻟﻠﺒﻨﺪ‬ (.AUX ‫ ﻭﻣﺼﺪﺭ ﺻﻮﺕ‬RADIO ‫)ﻏﻴﺮ ﻗﺎﺑﻞ ﻟﻠﺘﻄﺒﻴﻖ ﻟﻤﺼﺪﺭ ﺻﻮﺕ‬ [SOUND RECNSTR] .[EASY EQ] ‫• ﺍﻹﻋﺪﺍﺩﺍﺕ ﺍﻟﺘﻲ ﺗﻢ ﺗﻨﻔﻴﺬﻫﺎ ﻗﺪ ﺗﺆﺛﺮ ﻋﻠﻰ ﺇﻋﺪﺍﺩﺍﺕ‬ ‫)ﺇﻋﺎﺩﺓ...
  • Page 54 ‫ﺇﻋﺪﺍﺩﺍﺕ ﺍﻟﺼﻮﺕ‬ BLUETOOTH® Bluetooth ‫ﺭﺍﺩﻳﻮ ﺍﻹﻧﺘﺮﻧﺖ ﻋﻦ ﻃﺮﻳﻖ‬ Bluetooth ‫( ﻋﻠﻰ ﺍﻻﺟﻬﺰﺓ ﺍﻟﺘﺎﻟﻴﺔ ﻋﻦ ﻃﺮﻳﻖ‬Spotify) ‫ﻳﻤﻜﻨﻚ ﺍﻻﺳﺘﻤﺎﻉ ﺇﻟﻰ ﺭﺍﺩﻳﻮ ﺍﻻﻧﺘﺮﻧﺖ‬ .‫ﻋﻠﻰ ﻫﺬﻩ ﺍﻟﻮﺣﺪﺓ‬ .‫ ﻣﻮﺻﻮﻻ ﺍﻟﻰ ﺍﻱ ﺟﻬﺎﺯ‬USB ‫• ﺗﺄﻛﺪ ﻣﻦ ﺍﻥ ﻻ ﻳﻜﻮﻥ ﻃﺮﻑ ﺍﻻﺩﺧﺎﻝ‬ Android ‫/ﺟﻬﺎﺯ‬iPod touch/iPhone : Android ‫: ﺟﻬﺎﺯ‬...
  • Page 55 .iPod BT ‫ ﺍﻟﻰ ﻣﺼﺪﺭ‬iPod USB ‫– ﻗﻤﺖ ﺑﺎﻟﺘﻐﻴﻴﺮ ﻣﻦ ﻣﺼﺪﺭ‬ :‫ﺍﻟﺘﺤﻀﻴﺮ‬ .‫[: ﺍﻟﻐﺎﺀ‬NO] ‫. ؛‬Bluetooth ‫ ﻻﺳﺘﺨﺪﺍﻡ ﺍﻟﺘﻄﺒﻴﻖ ﻋﺒﺮ‬Android ‫[: ﻳﺨﺘﺎﺭ ﺍﻟﻬﺎﺗﻒ ﺍﻟﺬﻛﻲ‬YES] ‫ ﻋﻠﻰ‬KENWOOD Remote ‫• ﻗﻢ ﺑﺘﺜﺒﻴﺖ ﺍﺣﺪﺙ ﺍﺻﺪﺍﺭ ﻣﻦ ﺍﻟﺘﻄﺒﻴﻖ‬ [ANDROID] .‫ﺟﻬﺎﺯﻙ ﻗﺒﻞ ﺍﻟﺘﻮﺻﻴﻞ‬ .‫ ﻟﻼﺳﺘﺨﺪﺍﻡ ﻣﻦ ﺍﻟﻘﺎﺋﻤﺔ‬Android ‫ﻳﺨﺘﺎﺭ ﺍﻟﻬﺎﺗﻒ ﺍﻟﺬﻛﻲ‬...
  • Page 56 BLUETOOTH® ‫ — ﺻﻮﺕ‬BLUETOOTH ‫ﻋﻠﻰ ﻭﺣﺪﺓ ﺍﻟﺘﺤﻜﻢ‬ ‫ﻋﻠﻰ ﻏﻄﺎﺀ ﺍﻟﺤﻤﺎﻳﺔ‬ ‫ﺇﻟﻰ‬ ‫ﻋﻦ ﺑﻌﺪ‬ .‫4 ﺑﺘﻜﺮﺍﺭ‬ ‫ﺍﺿﻐﻂ‬ ‫ﺗﻜﺮﺍﺭ ﺍﻟﺘﺸﻐﻴﻞ‬ ( ‫) ﻏﻴﺮ ﻣﺘﺎﺡ‬ ،[FILE REPEAT] ،[ALL REPEAT] [REPEAT OFF] ‫3 ﻟﺘﺤﺪﻳﺪ‬ ‫ﺍﺿﻐﻂ ﺑﺎﺳﺘﻤﺮﺍﺭ ﻋﻠﻰ‬ ‫ﺍﻟﺘﺸﻐﻴﻞ ﺑﺘﺮﺗﻴﺐ‬ .[ALL RANDOM] ‫ﻋﺸﻮﺍﺋﻲ‬ ( ‫) ﻏﻴﺮ ﻣﺘﺎﺡ‬ Bluetooth ‫،...
  • Page 57 BLUETOOTH® ‫ﺇﻋﺪﺍﺩﺍﺕ ﺃﺧﺮﻯ‬ ‫ )ﺑﻤﺎ ﻓﻲ ﺫﻟﻚ ﺍﻹﻗﺮﺍﻥ ﺍﻟﻤﺨﺰﻥ‬Bluetooth ‫[: ﺗﻬﻴﺌﺔ ﺟﻤﻴﻊ ﺇﻋﺪﺍﺩﺍﺕ‬YES] [INITIALIZE] .‫[: ﺍﻟﻐﺎﺀ‬NO] ‫ﻭﺩﻟﻴﻞ ﺍﻟﻬﺎﺗﻒ، ﺇﻟﺦ(. ؛‬ .[FUNCTION] ‫ﺍﺿﻐﻂ ﻋﻠﻰ ﻗﺮﺹ ﻣﺴﺘﻮﻯ ﺍﻟﺼﻮﺕ ﻟﻠﺪﺧﻮﻝ ﺇﻟﻰ‬ ‫ﺃﺩﺭ ﻗﺮﺹ ﻣﺴﺘﻮﻯ ﺍﻟﺼﻮﺕ ﻟﺘﺤﺪﻳﺪ ﺑﻨﺪ )ﺭﺍﺟﻊ ﺍﻟﺠﺪﻭﻝ ﺍﻟﺘﺎﻟﻲ(، ﺛﻢ ﺍﺿﻐﻂ‬ .‫ﺍﻟﻘﺮﺹ‬ Bluetooth ‫ﻭﺿﻊ...
  • Page 58 BLUETOOTH® ‫ﺍﺟﺮﺍﺀ ﻣﻜﺎﻟﻤﺔ ﺑﻮﺍﺳﻄﺔ ﻣﻴﺰﺓ ﺍﻟﺘﻌﺮﻑ ﻋﻠﻰ ﺍﻟﺼﻮﺕ‬ (.PBAP ‫)ﻗﺎﺑﻞ ﻟﻠﺘﻄﺒﻴﻖ ﻓﻘﻂ ﺍﺫﺍ ﻛﺎﻥ ﺍﻟﻬﺎﺗﻒ ﻳﺪﻋﻢ‬ [PHONE BOOK] ‫1 ﺃﺩﺭ ﻗﺮﺹ ﻣﺴﺘﻮﻯ ﺍﻟﺼﻮﺕ ﺑﺴﺮﻋﺔ ﻟﻠﺪﺧﻮﻝ ﻓﻲ ﻭﺿﻊ ﺍﻟﺒﺤﺚ ﺣﺴﺐ ﺍﻟﺤﺮﻭﻑ‬ ‫ﻟﺘﻨﺸﻴﻂ ﻣﻴﺰﺓ ﺍﻟﺘﻌﺮﻑ ﻋﻠﻰ‬ ‫ﺍﺿﻐﻂ ﻣﻊ ﺍﻻﺳﺘﻤﺮﺍﺭ ﺑﺎﻟﻀﻐﻂ ﻋﻠﻰ‬ .(‫ﺍﻻﺑﺠﺪﻳﺔ )ﺍﺫﺍ ﻛﺎﻥ ﺩﻟﻴﻞ ﺍﻟﻬﺎﺗﻒ ﻳﺤﺘﻮﻱ ﻋﻠﻰ ﺍﻟﻌﺪﻳﺪ ﻣﻦ ﺟﻬﺎﺕ ﺍﻻﺗﺼﺎﻝ‬ .‫ﺍﻟﺼﻮﺕ...
  • Page 59 BLUETOOTH® ‫ﺍﺟﺮﺍﺀ ﻣﻜﺎﻟﻤﺔ‬ .‫*1 ﻟﻦ ﺗﺆﺛﺮ ﻋﻤﻠﻴﺔ ﺍﻟﻀﺒﻂ ﻫﺬﻩ ﻋﻠﻰ ﻣﺴﺘﻮﻯ ﺻﻮﺕ ﺍﻟﻤﺼﺎﺩﺭ ﺍﻷﺧﺮﻯ‬ ‫ ﻟﺰﻳﺎﺩﺓ ﻣﺴﺘﻮﻯ ﺍﻟﺼﻮﺕ ﺑﻤﻘﺪﺍﺭ 51 ﻣﺮﺣﻠﺔ‬VOL ‫*2 ﺍﺿﻐﻂ ﻣﻊ ﺍﻻﺳﺘﻤﺮﺍﺭ ﺑﺎﻟﻀﻐﻂ ﻋﻠﻰ‬ .‫ﺑﺸﻜﻞ ﻣﺴﺘﻤﺮ‬ ‫ﻳﻤﻜﻦ ﺍﺟﺮﺍﺀ ﻣﻜﺎﻟﻤﺔ ﻣﻦ ﺳﺠﻞ ﺍﻟﻤﻜﺎﻟﻤﺎﺕ ﺃﻭ ﻣﻦ ﺩﻟﻴﻞ ﺍﻟﻬﺎﺗﻒ ﺃﻭ ﺍﻻﺗﺼﺎﻝ ﺑﺎﻟﺮﻗﻢ. ﻛﻤﺎ ﺗﺘﻮﻓﺮ‬ .‫...
  • Page 60 BLUETOOTH® .‫ﻗﺪ ﺗﺨﺘﻠﻒ ﻋﻤﻠﻴﺎﺕ ﺍﻟﺘﺸﻐﻴﻞ ﺍﻟﺘﺎﻟﻴﺔ ﺍﻭ ﺗﻜﻮﻥ ﻏﻴﺮ ﻣﺘﺎﺣﺔ ﻭﻓﻘﺎ ﻟﻠﻬﺎﺗﻒ ﺍﻟﻤﺤﻤﻮﻝ‬ ‫)ﻟﻤﻮﺩﻳﻠﻲ‬ Auto Pairing ‫ﻋﻠﻰ ﻭﺣﺪﺓ ﺍﻟﺘﺤﻜﻢ‬ ‫ﻋﻠﻰ ﻏﻄﺎﺀ ﺍﻟﺤﻤﺎﻳﺔ‬ ‫ﺇﻟﻰ‬ ‫، ﻳﺘﻢ ﺗﻔﻌﻴﻞ ﻃﻠﺐ ﺍﻹﻗﺮﺍﻥ‬USB ‫ ﺍﻟﻰ ﻃﺮﻑ ﺍﻻﺩﺧﺎﻝ‬iPod touch/iPhone ‫ﻋﻨﺪ ﺗﻮﺻﻴﻞ ﺟﻬﺎﺯ‬ ‫ﻋﻦ ﺑﻌﺪ‬ . ‫( ﺗﻠﻘﺎﺋﻴ ﺎ ﹰ‬Bluetooth ‫)ﻋﺒﺮ‬ ...‫ﺍﻭﻝ...
  • Page 61 BLUETOOTH® ‫ — ﺍﻟﺘﻮﺻﻴﻞ‬BLUETOOTH .‫ ﻣﻊ ﻫﺬﻩ ﺍﻟﻮﺣﺪﺓ‬Bluetooth ‫ﻭﻓﻘﺎ ﻟﻨﻈﺎﻡ ﺍﻟﺘﺸﻐﻴﻞ ﻭﺍﺻﺪﺍﺭ ﺍﻟﺒﺮﺍﻣﺞ ﺍﻟﺜﺎﺑﺘﺔ ﻟﻬﺎﺗﻔﻚ ﺍﻟﻤﺤﻤﻮﻝ، ﻗﺪ ﻻ ﺗﻌﻤﻞ ﻣﻴﺰﺍﺕ‬ ‫ ﺍﻟﻤﺪﻋﻮﻣﺔ‬Bluetooth ‫ﺃﻭﺿﺎﻉ‬ ‫ ﻻﻭﻝ ﻣﺮﺓ‬Bluetooth ‫ﺍﻗﺘﺮﺍﻥ ﻭﺗﻮﺻﻴﻞ ﺟﻬﺎﺯ ﺑﻠﻮﺗﻮﺙ‬ (HFP) ‫– ﻭﺿﻊ ﻋﺪﻡ ﺍﺳﺘﺨﺪﺍﻡ ﺍﻟﻴﺪﻳﻦ‬ (A2DP) ‫– ﻭﺿﻊ ﺗﻮﺯﻳﻊ ﺍﻟﺼﻮﺕ ﺍﻟﻤﺘﻘﺪﻡ‬ .‫...
  • Page 62 Spotify ‫ﺍﻟﺒﺤﺚ ﻋﻦ ﺍﻏﻨﻴﺔ ﺍﻭ ﻣﺤﻄﺔ‬ ‫ﻋﻠﻰ ﻭﺣﺪﺓ ﺍﻟﺘﺤﻜﻢ‬ ‫ﻋﻠﻰ ﻏﻄﺎﺀ ﺍﻟﺤﻤﺎﻳﺔ‬ ‫ﺇﻟﻰ‬ ‫ﻋﻦ ﺑﻌﺪ‬ ‫ﺍﺿﻐﻂ‬ .‫ﺃﺩﺭ ﻗﺮﺹ ﻣﺴﺘﻮﻯ ﺍﻟﺼﻮﺕ ﻟﺘﺤﺪﻳﺪ ﻧﻮﻉ ﺍﻟﻘﺎﺋﻤﺔ، ﺛﻢ ﺍﺿﻐﻂ ﻋﻠﻰ ﺍﻟﻘﺮﺹ‬ ( ‫) ﻏﻴﺮ ﻣﺘﺎﺡ‬ .5 ‫ﺍﺿﻐﻂ ﻣﻊ ﺍﻻﺳﺘﻤﺮﺍﺭ ﻋﻠﻰ‬ ‫ﺑﺪﺀ ﺗﺸﻐﻴﻞ ﺍﻟﺮﺍﺩﻳﻮ‬ .Spotify ‫ﺗﺨﺘﻠﻒ ﺍﻧﻮﺍﻉ ﺍﻟﻘﻮﺍﺋﻢ ﺍﻟﻤﻌﺮﻭﺿﺔ ﺑﻨﺎﺀﺍ ﻋﻠﻰ ﺍﻟﻤﻌﻠﻮﻣﺎﺕ ﺍﻟﻤﺮﺳﻠﺔ ﻣﻦ‬ .‫4 ﺑﺘﻜﺮﺍﺭ‬...
  • Page 63 Spotify ANDROID/iPod/USB/CD USB ‫ ﻋﻠﻰ ﺍﻻﺟﻬﺰﺓ ﺍﻟﺘﺎﻟﻴﺔ ﻋﺒﺮ ﻃﺮﻑ ﺍﻻﺩﺧﺎﻝ‬Spotify ‫ﻳﻤﻜﻦ ﺍﻻﺳﺘﻤﺎﻉ ﺍﻟﻰ‬ ‫ﺑﺤﺚ ﺍﻟﻤﻮﺳﻴﻘﻰ ﺍﻟﻤﺒﺎﺷﺮ‬ (‫)ﺍﺳﺘﺨﺪﺍﻡ ﻭﺣﺪﺓ ﺍﻟﺘﺤﻜﻢ ﻋﻦ ﺑﻌﺪ‬ .(12 ‫ )ﺻﻔﺤﺔ‬Bluetooth ‫)ﺭﺍﺟﻊ ﻣﺎ ﻳﻠﻲ( ﺍﻭ ﻋﺒﺮ‬ .DIRECT ‫ﺍﺿﻐﻂ‬ ‫( ﺍﻭ‬USB ‫ ﺍﻭ ﻋﺒﺮ ﻃﺮﻑ ﺍﻻﺩﺧﺎﻝ‬Bluetooth ‫ )ﻋﺒﺮ‬iPod/iPhone ‫: ﺟﻬﺎﺯ‬ .‫ﺍﺿﻐﻂ...
  • Page 64 ‫ ﻳﺆﺩﻱ ﺍﻟﻰ ﺍﻟﺒﺤﺚ‬S / T ‫• ﺍﻟﻀﻐﻂ ﻣﻊ ﺍﺳﺘﻤﺮﺍﺭ ﺍﻟﻀﻐﻂ ﻋﻠﻰ ﺍﻟﺰﺭ‬ :‫ﺍﻟﺘﺤﻀﻴﺮ‬ .%10 ‫ﺑﻤﻌﺪﻝ‬ .‫ ﻋﻠﻰ ﺟﻬﺎﺯﻙ ﻗﺒﻞ ﺍﻟﺘﻮﺻﻴﻞ‬KENWOOD Remote ‫• ﻗﻢ ﺑﺘﺜﺒﻴﺖ ﺍﺣﺪﺙ ﺍﺻﺪﺍﺭ ﻣﻦ ﺍﻟﺘﻄﺒﻴﻖ‬ ‫ﺑﺤﺚ ﺣﺴﺐ ﺍﻟﺤﺮﻭﻑ ﺍﻻﺑﺠﺪﻳﺔ‬ ‫)ﻗﺎﺑﻞ ﻟﻠﺘﻄﺒﻴﻖ ﻓﻘﻂ ﻟﻤﺼﺪﺭ‬ .<www.kenwood.com/cs/ce/> ‫• ﻟﻤﺰﻳﺪ ﻣﻦ ﺍﻟﻤﻌﻠﻮﻣﺎﺕ، ﻗﻢ ﺑﺰﻳﺎﺭﺓ‬...
  • Page 65 ANDROID/iPod/USB/ CD ‫ﺑﺪﺀ ﺍﻟﺘﺸﻐﻴﻞ‬ :‫ﺍﻟﻤﺼﺪﺭ ﺍﻟﻘﺎﺑﻞ ﻟﻼﺧﺘﻴﺎﺭ‬ /iPod USB/USB/CD : .‫ﻳﺘﻐﻴﺮ ﺍﻟﻤﺼﺪﺭ ﺗﻠﻘﺎﺋﻴ ﹰ ﺎ ﻭﻳﺒﺪﺃ ﺍﻟﺘﺸﻐﻴﻞ‬ ANDROID ANDROID/USB/CD : ‫ﺇﺧﺮﺍﺝ ﺍﻷﺳﻄﻮﺍﻧﺔ‬ ‫ﺟﺎﻧﺐ ﺍﻟﻤﻠﺼﻖ‬ ‫ﻋﻠﻰ ﻭﺣﺪﺓ ﺍﻟﺘﺤﻜﻢ ﻋﻦ ﺑﻌﺪ‬ ‫ﻋﻠﻰ ﻏﻄﺎﺀ ﺍﻟﺤﻤﺎﻳﺔ‬ ‫ﺇﻟﻰ‬ .ENT IW ‫ﺍﺿﻐﻂ‬ .6 IW ‫ﺍﺿﻐﻂ‬ ‫ﺍﻟﺘﺸﻐﻴﻞ/ﺍﻹﻳﻘﺎﻑ ﺍﻟﻤﺆﻗﺖ‬ ‫ﺍﺿﻐﻂ...
  • Page 66 ‫ﺭﺍﺩﻳﻮ‬ :‫ﺍﻟﺘﺤﻀﻴﺮ‬ ‫[: ﻳﺴﻤﺢ ﻟﻠﻮﺣﺪﺓ ﺑﺎﻟﺘﺤﻮﻝ ﻣﺆﻗﺘ ﺎ ﹰ ﺍﻟﻰ ﻣﻌﻠﻮﻣﺎﺕ ﺍﻟﻤﺮﻭﺭ ﺇﺫﺍ ﻛﺎﻧﺖ‬ON] [TI] (5 ‫[. )ﺻﻔﺤﺔ‬SOURCE SELECT] ‫[ ﻓﻲ‬BUILT-IN AUX] ‫[ ﻟـ‬ON] ‫• ﺣﺪﺩ‬ .‫[: ﺍﻟﻐﺎﺀ‬OFF] ‫“(. ؛‬TI” ‫ﻣﺘﻮﻓﺮﺓ )ﻳﻀﺎﺀ ﺍﻟﻤﺆﺷﺮ‬ ‫1 ﺃﺩﺭ ﻗﺮﺹ ﻣﺴﺘﻮﻯ ﺍﻟﺼﻮﺕ ﻟﺘﺤﺪﻳﺪ ﻧﻮﻉ ﺍﻟﺒﺮﻧﺎﻣﺞ ﺍﻟﻤﺘﺎﺡ )ﺭﺍﺟﻊ ﺍﺩﻧﺎﻩ(، ﺛﻢ‬ ‫ﺑﺪﺀ...
  • Page 67 ‫ﺭﺍﺩﻳﻮ‬ ‫ﺇﻋﺪﺍﺩﺍﺕ ﺃﺧﺮﻯ‬ .[FUNCTION] ‫ﺍﺿﻐﻂ ﻋﻠﻰ ﻗﺮﺹ ﻣﺴﺘﻮﻯ ﺍﻟﺼﻮﺕ ﻟﻠﺪﺧﻮﻝ ﺇﻟﻰ‬ ‫ﺃﺩﺭ ﻗﺮﺹ ﻣﺴﺘﻮﻯ ﺍﻟﺼﻮﺕ ﻟﺘﺤﺪﻳﺪ ﺑﻨﺪ )ﺭﺍﺟﻊ ﺍﻟﺠﺪﻭﻝ ﺍﻟﺘﺎﻟﻲ(، ﺛﻢ ﺍﺿﻐﻂ‬ .‫ﺍﻟﻘﺮﺹ‬ ‫ﻛﺮﺭ ﺍﻟﺨﻄﻮﺓ 2 ﺍﻟﻰ ﺍﻥ ﻳﺘﻢ ﺍﺧﺘﻴﺎﺭ ﺍﻟﺒﻨﺪ ﺍﻟﻤﺮﻏﻮﺏ ﺍﻭ ﺍﺗﺒﻊ ﺍﻟﺘﻌﻠﻴﻤﺎﺕ‬ .‫ﺍﻟﻤﺘﻌﻠﻘﺔ ﺑﺎﻟﺒﻨﺪ ﺍﻟﻤﺨﺘﺎﺭ‬ .‫ﻣﻦ ﺃﺟﻞ ﺍﻹﻧﻬﺎﺀ‬ ‫ﺍﺿﻐﻂ...
  • Page 68 .‫• ﻗﺪ ﺗﺘﻌﺮﺽ ﺍﻟﺴﻤﺎﻋﺎﺕ ﻟﻠﺘﻠﻒ‬ [UPDATE SYSTEM] .‫• ﻗﺪ ﻳﻜﻮﻥ ﻣﺴﺘﻮﻯ ﺍﻟﺼﻮﺕ ﺍﻟﺼﺎﺩﺭ ﻋﺎﻟﻴﺎ ﺍﻭ ﻣﻨﺨﻔﻀﺎ ﻻﻗﺼﻰ ﺣﺪ‬ .(‫[: ﻳﻠﻐﻲ )ﺍﻟﺘﺮﻗﻴﺔ ﻏﻴﺮ ﻣﻨﺸﻄﺔ‬NO] ‫[: ﻳﺒﺪﺃ ﺗﺮﻗﻴﺔ ﺍﻟﺒﺮﻧﺎﻣﺞ ﺍﻟﺜﺎﺑﺖ. ؛‬YES] [F/W UP xxxx] ‫ﻟﻠﺤﺼﻮﻝ ﻋﻠﻰ ﺗﻔﺎﺻﻴﻞ ﺣﻮﻝ ﻛﻴﻔﻴﺔ ﺗﺤﺪﻳﺚ ﺍﻟﺒﺮﻧﺎﻣﺞ ﺍﻟﺜﺎﺑﺖ، ﻗﻢ ﺑﺰﻳﺎﺭﺓ‬ .<www.kenwood.com/cs/ce/> ‫ﻋﺮﺑﻲ‬...
  • Page 69 ‫ﺍﻟﺸﺮﻭﻉ ﻓﻲ ﺍﻟﻌﻤﻞ‬ .‫ﺃﺩﺭ ﻗﺮﺹ ﻣﺴﺘﻮﻯ ﺍﻟﺼﻮﺕ ﻟﺘﺤﺪﻳﺪ ﺍﻹﻋﺪﺍﺩﺍﺕ، ﺛﻢ ﺍﺿﻐﻂ ﻋﻠﻰ ﺍﻟﻘﺮﺹ‬ ‫ﺩﻗﻴﻘﺔ‬ ‫ﺳﺎﻋﺔ‬ ‫[، ﺛﻢ ﺍﺿﻐﻂ ﻋﻠﻰ‬CLOCK FORMAT] ‫ﺃﺩﺭ ﻗﺮﺹ ﻣﺴﺘﻮﻯ ﺍﻟﺼﻮﺕ ﻟﺘﺤﺪﻳﺪ‬ .‫ﺍﻟﻘﺮﺹ‬ .‫42[، ﺛﻢ ﺍﺿﻐﻂ ﻋﻠﻰ ﺍﻟﻘﺮﺹ‬H] ‫21[ ﺃﻭ‬H] ‫ﺃﺩﺭ ﻗﺮﺹ ﻣﺴﺘﻮﻯ ﺍﻟﺼﻮﺕ ﻟﺘﺤﺪﻳﺪ‬ ‫ﻟﻀﺒﻂ ﺍﻟﺘﺎﺭﻳﺦ‬ .‫[،...
  • Page 70 ‫ﺃ ﹶ ﺳﺎﺳ ﹺ ﻴ ﹼ ﺎﺕ‬ ‫( )ﻣﺘﻮﻓﺮ ﻟﻠﻤﻮﺩﻳﻞ‬RC-406) ‫ﺭﻳﻤﻮﺕ ﺍﻟﺘﺤﻜﻢ‬ ‫ﻭﺍﺟﻬﺔ ﺍﻟﺠﻬﺎﺯ‬ ‫ﺣﺴﺎﺱ ﺍﻟﺘﺤﻜﻢ ﻋﻦ ﺑﻌﺪ‬ ‫ﻧﺎﻓﺬﺓ ﺍﻟﻌﺮﺽ‬ ‫)ﺗﺠﻨﺐ ﺍﻟﺘﻌﺮﻳﺾ ﻟﻀﻮﺀ ﺍﻟﺸﻤﺲ‬ (.‫ﺍﻟﺴﺎﻃﻊ‬ ‫ﻗﺮﺹ ﻣﺴﺘﻮﻯ‬ ‫ﻓﺘﺤﺔ‬ ‫ﺍﻟﺼﻮﺕ‬ ‫ﺍﻟﺘﺤﻤﻴﻞ‬ ‫ﻗﻢ ﺑﺴﺤﺐ ﻏﻄﺎﺀ ﻋﺎﺯﻝ‬ ‫ﺍﻟﻜﻬﺮﺑﺎﺀ ﻋﻨﺪ ﺍﻻﺳﺘﺨﺪﺍﻡ‬ .‫ﻷﻭﻝ ﻣﺮﺓ‬ ‫ﻳﻀﻲﺀ ﺍﻟﺮﻣﺰ ﻋﻨﺪ‬ ‫ﺇﻧﺸﺎﺀ...
  • Page 71 ‫ﺍﻟﻤﺤﺘﻮﻳﺎﺕ‬ ‫ﻗﺒﻞ ﺍﻻﺳﺘﺨﺪﺍﻡ‬ ‫ﻗﺒﻞ ﺍﻻﺳﺘﺨﺪﺍﻡ‬ ‫ﻫﺎﻡ‬ ‫ﺃ ﹶ ﺳﺎﺳ ﹺ ﻴ ﹼ ﺎﺕ‬ ‫• ﻟﻀﻤﺎﻥ ﺍﻻﺳﺘﺨﺪﻟﻢ ﺍﻟﻤﻨﺎﺳﺐ، ﻳﺮﺟﻰ ﻗﺮﺍﺀﺓ ﻫﺬﺍ ﺍﻟﺪﻟﻴﻞ ﺑﺘﻤﻌﻦ ﻗﺒﻞ ﺍﺳﺘﺨﺪﺍﻡ ﻫﺬﺍ ﺍﻟﻤﻨﺘﺞ. ﻣﻦ ﺍﻟﻤﻬﻢ ﺟﺪﺍ ﺍﻥ ﺗﻘﺮﺃ ﻭﺗﺮﺍﻗﺐ ﺍﻟﺘﺤﺬﻳﺮﺍﺕ‬ .‫ﻭﺍﻟﺘﻨﺒﻴﻬﺎﺕ ﺍﻻﺣﺘﻴﺎﻃﻴﺔ ﻓﻲ ﻫﺬﺍ ﺍﻟﺪﻟﻴﻞ‬ ‫ﺍﻟﺸﺮﻭﻉ ﻓﻲ ﺍﻟﻌﻤﻞ‬ .‫•...
  • Page 72 KDC-BT630U KDC-BT530U...
