User's Guide
EMG2881-T20A
Dual-Band Wireless AC1300 Gigabit Ethernet Gateway
Default Login Details
LAN IP Address
User Name
Password
Copyright © 2018 Zyxel Communications Corporation
http://192.168.1.1
admin
See the device label
Version 1.00 Edition 1, 01/2018

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EMG2881-T20A and is the answer not in the manual?

Questions and answers

Related Manuals for ZyXEL Communications EMG2881-T20A

Summary of Contents for ZyXEL Communications EMG2881-T20A

  • Page 1 User’s Guide EMG2881-T20A Dual-Band Wireless AC1300 Gigabit Ethernet Gateway Default Login Details Version 1.00 Edition 1, 01/2018 LAN IP Address http://192.168.1.1 User Name admin Password See the device label Copyright © 2018 Zyxel Communications Corporation...
  • Page 2 Related Documentation • Quick Start Guide The Quick Start Guide shows how to connect the EMG2881-T20A and access the Web Configurator. • More Information Go to support.zyxel.com to find other information on the EMG2881-T20A...

  • Page 3: Document Conventions

    Log Setting tab to get to that screen. Icons Used in Figures Figures in this user guide may use the following generic icons. The EMG2881-T20A icon is not an exact representation of your device. EMG2881-T20A...

  • Page 4: Table Of Contents

    Introducing the Web Configurator ..................... 16 Router Mode ............................18 Tutorials ..............................24 Technical Reference ........................34 Monitor ..............................35 WAN ............................... 37 Wireless LAN ............................53 LAN ................................. 70 Applications ............................75 Security ..............................92 Maintenance ............................98 Troubleshooting ..........................106 EMG2881-T20A User’s Guide...

  • Page 5: Table Of Contents

    1.1.2 Wireless Access ........................10 1.2 Applications ............................ 11 1.3 Ways to Manage the EMG2881-T20A ..................11 1.4 Good Habits for Managing the EMG2881-T20A ................11 1.5 Hardware ............................12 1.5.1 Front Panel ..........................12 1.5.2 Front Panel LEDs (Lights) ....................... 12 1.5.3 Rear Panel ..........................
  • Page 6 4.2 Set Up a Wireless Network Using WPS ................... 24 4.2.1 Push Button Configuration (PBC) ..................24 4.2.2 PIN Configuration ........................25 4.3 Connect to the EMG2881-T20A’s WiFi Network Manually (No WPS) ........26 4.3.1 Configuring Wireless Security on the EMG2881-T20A ............27 4.3.2 Configure Your Notebook ....................28 4.4 Using Multiple SSIDs on the EMG2881-T20A ..................
  • Page 7 Chapter 10 Security ...............................92 10.1 Overview ............................. 92 10.1.1 What You Can Do ....................... 92 10.1.2 What You Need To Know ....................92 10.2 IPv4 Firewall Screen ........................93 10.3 IPv6 Firewall Screen ........................95 Chapter 11 Maintenance............................98 EMG2881-T20A User’s Guide...
  • Page 8 12.2 Power, Hardware Connections, and LEDs ................106 12.3 EMG2881-T20A Access and Login .................... 107 12.4 Internet Access ........................... 108 12.5 Resetting the EMG2881-T20A to Its Factory Defaults .............. 109 12.6 Wireless Connections ......................... 110 Appendix A Pop-up Windows, JavaScript and Java Permissions ..........112 Appendix B Setting Up Your Computer’s IP Address..............

  • Page 9: User's Guide

    User’s Guide...

  • Page 10: Introduction

    These devices can connect to the EMG2881-T20A to access network resources and the Internet. Your EMG2881-T20A supports Wi-Fi Protected Setup (WPS), which allows you to quickly set up a wireless network with strong security. You can configure your wireless network using the built-in Web Configurator.

  • Page 11: Applications

    If you forget your password, you will have to reset the EMG2881-T20A to its factory default settings. If you backed up an earlier configuration file, you would not have to totally re-configure the EMG2881-T20A. You could simply restore your last configuration.

  • Page 12: Hardware

    Blinking The EMG2881-T20A is communicating with 2.4 GHz/5 GHz wireless clients. Amber Blinking The EMG2881-T20A is setting up a WPS connection with a 2.4 GHz/5 GHz wireless client. The wireless LAN is not ready or has failed. EMG2881-T20A User’s Guide...

  • Page 13: Rear Panel

    Press the WPS button for more than one second to quickly set up a secure wireless connection between the EMG2881-T20A and a WPS-compatible client. Reset Press the button to return the EMG2881-T20A to the factory defaults. LAN1 ~ LAN4 Connect computers or other Ethernet devices to Ethernet ports for Internet access.

  • Page 14: Rear Panel Leds (Lights)

    Press the WPS button for more than one second and release it. Press the WPS button on another WPS-enabled device within range of the EMG2881-T20A. The WLAN 2.4G and WLAN 5G LEDs flash amber while the EMG2881-T20A sets up a WPS connection with the other wireless device.
  • Page 15 Chapter 1 Introduction Press the RESET button for longer than five seconds to set the EMG2881-T20A back to its factory-default configurations. EMG2881-T20A User’s Guide...

  • Page 16: Introducing The Web Configurator

    Introducing the Web Configurator 2.1 Overview This chapter describes how to access the EMG2881-T20A Web Configurator and provides an overview of its screens. The Web Configurator is an HTML-based management interface that allows easy setup and management of the EMG2881-T20A via Internet browser. Use Internet Explorer 9.0 and later versions, Mozilla Firefox 21 and later versions, Safari 6.0 and later versions or Google Chrome 26.0 and later...

  • Page 17: Chapter 2 Introducing The Web Configurator

    Figure 5 Login screen The following table describes the labels in this screen. Table 4 Login screen LABEL DESCRIPTION Username Type "admin" (default) as the user name. Password Type the default password (on the device label). Click Login. EMG2881-T20A User’s Guide...

  • Page 18: Router Mode

    Router Mode 3.1 Overview The EMG2881-T20A is set to router mode by default. Routers are used to connect the local network to another network (for example, the Internet). In the figure below, the EMG2881-T20A connects the local network (LAN1 ~ LAN4) to the Internet.
  • Page 19 Model Number This is the model name of your device. Firmware Version This is the firmware version and the date created. Sys OP Mode This is the device mode to which the EMG2881-T20A is set - Router Mode. EMG2881-T20A User’s Guide...
  • Page 20 This shows the IPv6 address of the EMG2881-T20A on the LAN. WLAN 2.4G Information WLAN OP Mode This is the device mode to which the EMG2881-T20A’s wireless LAN is set - Access Point Mode. MAC Address This shows the 2.4GHz wireless adapter MAC Address of your device.

  • Page 21: Navigation Panel

    For the 2.4GHz/5GHz WLAN, it displays the maximum transmission rate when the 2.4GHz/5GHz WLAN is enabled and N/A when the WLAN is disabled. 3.2.1 Navigation Panel Use the sub-menus on the navigation panel to configure EMG2881-T20A features. Figure 8 Navigation Panel: Router Mode The following table describes the sub-menus.
  • Page 22 This screen allows you to assign IP addresses on the LAN to specific individual computers based on their MAC addresses. IPv6 LAN Use this screen to configure the IPv6 address for the EMG2881-T20A on the LAN. Application Bandwidth QoS General Use this screen to enable or disable QoS and set the upstream bandwidth.
  • Page 23 Table 7 Navigation Panel: Router Mode (continued) LINK FUNCTION Restart System Restart This screen allows you to reboot the EMG2881-T20A without turning the power off. Use this screen to view the list of activities recorded by your EMG2881-T20A. ROMD ROMD Use this screen to save and/or clean the configuration to/from the ROMD file which can store customized default settings.

  • Page 24: Tutorials

    4.2.1 Push Button Configuration (PBC) Make sure that your EMG2881-T20A is turned on and that the device is placed within range of your Android 4.42 smartphone. WPS is enabled by default on the EMG2881-T20A. If not, log into EMG2881-T20A’s Web Configurator and turn it on in the Configuration >...

  • Page 25: Pin Configuration

    Enter the client’s PIN number to the PIN field in the Configuration > Wireless > WPS screen on the EMG2881-T20A. Click the Start button (or button next to the PIN field) on the EMG2881-T20A’s WPS screen within two minutes. The EMG2881-T20A authenticates the wireless client and sends the proper configuration settings to the wireless client.

  • Page 26: Connect To The Emg2881-T20A's Wifi Network Manually (No Wps)

    4.3 Connect to the EMG2881-T20A’s WiFi Network Manually (No WPS) In this example, we change the EMG2881-T20A’s wireless settings, and then manually select the EMG2881-T20A’s new SSID and enter the Wi-Fi key to connect a wireless client to the EMG2881-T20A. EMG2881-T20A User’s Guide...

  • Page 27: Configuring Wireless Security On The Emg2881-T20A

    16). Go to the Configuration > Wireless > Wireless screen to enable the 2.4 GHz wireless network. Enter SSID_Example as the SSID and select Auto Channel Selection to have the EMG2881-T20A scans for and select an available channel automatically. Set security mode to WPA2-PSK and enter ThisismyWPA-PSKpre-sharedkey in the Pre-Shared Key field.

  • Page 28: Configure Your Notebook

    Note: In this example, we use a Windows 7 laptop that has a built-in wireless adapter as the wireless client. The EMG2881-T20A supports IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11a, IEEE 802.11an, and IEEE 802.11ac wireless clients. Make sure that your notebook or computer’s wireless adapter supports one of these standards.
  • Page 29 Chapter 4 Tutorials Select SSID_Example and click Connect. The following screen displays if WPS is enabled on the EMG2881-T20A but you didn’t press the WPS button. Click Connect using as security key instead. Type the security key in the following screen. Click OK.

  • Page 30: Using Multiple Ssids On The Emg2881-T20A

    Chapter 4 Tutorials Check the status of your wireless connection in the screen below. If the wireless client keeps trying to connect to or acquiring an IP address from the EMG2881-T20A, make sure you entered the correct security key. If the connection has limited or no connectivity, make sure the EMG2881-T20A is connected to a router with the DHCP server enabled.

  • Page 31: Configuring Security Settings Of Multiple Ssids

    Connect your computer to the LAN port of the EMG2881-T20A using an Ethernet cable. The default IP address of the EMG2881-T20A in router mode is “192.168.1.1”. In this case, your computer must have an IP address in the range between “192.168.1.2” and “192.168.1.254”.
  • Page 32 Click the Edit icon of the second entry to configure wireless and security settings for SSID_VoIP. 10 Configure the screen as follows. You enable Intra-BSS Traffic for SSID_VoIP to allow wireless clients in the same wireless network to communicate with each other. Click Apply. EMG2881-T20A User’s Guide...
  • Page 33 Chapter 4 Tutorials 11 Click the Edit icon of the third entry to configure wireless and security settings for SSID_Guest. 12 Configure the screen as follows. In this example, you disable Intra-BSS Traffic for SSID_Guest. Click Apply. EMG2881-T20A User’s Guide...

  • Page 34: Technical Reference

    Technical Reference...

  • Page 35: Monitor

    DHCP (Dynamic Host Configuration Protocol, RFC 2131 and RFC 2132) allows individual clients to obtain TCP/IP configuration at start-up from a server. You can configure the EMG2881-T20A’s LAN as a DHCP server or disable it. When configured as a server, the EMG2881-T20A provides the TCP/IP configuration for the clients.
  • Page 36 Reserve Select this if you want to reserve the IP address for this specific MAC address. Apply Click Apply to save your changes back to the EMG2881-T20A. Cancel Click Cancel to reload the previous configuration for this screen. EMG2881-T20A User’s Guide...

  • Page 37: Chapter 6 Wan

    • Use the Management WAN screen to enter your ISP information and set how the computer acquires its IP, DNS and WAN MAC addresses (Section 6.4 on page 39). • Use the NAT > General screen to enable NAT, set a default server and change your EMG2881-T20A’s port forwarding settings (Section 6.5.1 on page 47).

  • Page 38: Configuring Your Internet Connection

    (and service name) for user authentication. WAN IP Address The WAN IP address is an IP address for the EMG2881-T20A, which makes it accessible from an outside network. It is used by the EMG2881-T20A to communicate with other devices in other networks. It can be static (fixed) or dynamically assigned by the ISP each time the EMG2881-T20A tries to access the Internet.

  • Page 39: Management Wan

    A and D. IGMP (Internet Group Multicast Protocol) is a network-layer protocol used to establish membership in a multicast group - it is not used to carry user data. The EMG2881-T20A supports both IGMP version 1 (IGMP-v1) and IGMP version 2 (IGMP-v2).

  • Page 40: Edit Wan Connection

    This shows the status of the connection. Modify Click the Edit icon to configure the connection. Click the Delete icon to delete this connection from the EMG2881-T20A. A window displays asking you to confirm that you want to delete the connection. 6.4.1 Edit WAN Connection Click the Edit icon next to the connection you want to configure.
  • Page 41 Select IPv4 Only if you want the EMG2881-T20A to run IPv4 only. Select Dual Stack to allow the EMG2881-T20A to run IPv4 and IPv6 at the same time. Select IPv6 Only if you want the EMG2881-T20A to run IPv6 only.
  • Page 42 First DNS Server Select Obtained From ISP if your ISP dynamically assigns DNS server information (and the EMG2881-T20A's WAN IP address). The field to the right displays the (read-only) DNS server IP Second DNS Server address that the ISP assigns.
  • Page 43 LABEL DESCRIPTION First DNS Server Select Obtained From ISP to have the EMG2881-T20A get the IPv6 DNS server addresses from the ISP automatically. Second DNS Server Select User-Defined and enter the IPv6 DNS server address assigned by the ISP to have the Third DNS Server EMG2881-T20A use the IPv6 DNS server addresses you configure manually.
  • Page 44 Select IPv4 Only if you want the EMG2881-T20A to run IPv4 only. Select Dual Stack to allow the EMG2881-T20A to run IPv4 and IPv6 at the same time. Select IPv6 Only if you want the EMG2881-T20A to run IPv6 only.
  • Page 45 First DNS Server Select Obtained From ISP if your ISP dynamically assigns DNS server information (and the EMG2881-T20A's WAN IP address). The field to the right displays the (read-only) DNS server IP Second DNS Server address that the ISP assigns.
  • Page 46 LABEL DESCRIPTION First DNS Server Select Obtained From ISP to have the EMG2881-T20A get the IPv6 DNS server addresses from the ISP automatically. Second DNS Server Select User-Defined and enter the IPv6 DNS server address assigned by the ISP to have the Third DNS Server EMG2881-T20A use the IPv6 DNS server addresses you configure manually.

  • Page 47: Nat

    Select IPv4 Only if you want the EMG2881-T20A to run IPv4 only. Select Dual Stack to allow the EMG2881-T20A to run IPv4 and IPv6 at the same time. Select IPv6 Only if you want the EMG2881-T20A to run IPv6 only.
  • Page 48 User define in the Name field, enter an internal port number manually or leave the field blank for port range forwarding. Click to add the rule in the port forwarding summary table. Delete Click to remove a rule. EMG2881-T20A User’s Guide...

  • Page 49: Port Trigger Screen

    Type a port number or the ending port number in a range of port numbers. Trigger Port The trigger port is a port (or a range of ports) that causes (or triggers) the EMG2881-T20A to record the IP address of the LAN computer that sent the traffic to a server on the WAN.

  • Page 50: Dynamic Dns Screen

    PPTP VPN account. If PPTP is disabled, then when a client sends a request to a VPN server, the server will reply to the EMG2881-T20A and the EMG2881-T20A will drop the request. When PPTP is enabled, the EMG2881-T20A will forward the reply from the VPN server to the client that initiated the request, and the connection will establish successfully.

  • Page 51: Interface Group Screen

    Enter your user name. Password Enter the password assigned to you. Apply Click Apply to save your changes back to the EMG2881-T20A. Cancel Click Cancel to begin configuring this screen afresh. 6.7 Interface Group Screen You can manually add a LAN and/or WLAN interface to a new group. Click Configuration > WAN >...
  • Page 52 To remove a LAN or wireless LAN interface from the Grouped LAN Interfaces, use the righ-facing arrow. Apply Click this button to save your settings back to the EMG2881-T20A. Cancel Click Cancel to begin configuring this screen afresh. EMG2881-T20A User’s Guide...

  • Page 53: Chapter 7 Wireless Lan

    This chapter discusses how to configure the wireless network settings in your EMG2881-T20A. The EMG2881-T20A is able to function both 2.4GHz and 5GHz network at the same time. You can have different wireless and wireless security settings for 2.4GHz and 5GHz wireless LANs. Click Configuration >...

  • Page 54: What You Can Do

    EMG2881-T20A and the wireless clients, and make other basic configuration changes (Section 7.2 on page 57). • Use the More AP screen to set up multiple wireless networks on your EMG2881-T20A (Section 7.4 on page 61). • Use the MAC Filter screen to allow or deny wireless stations based on their MAC addresses from connecting to the EMG2881-T20A (Section 7.5 on page...
  • Page 55 For example, if the wireless network has a RADIUS server, you can choose WPA or WPA2. If users do not log in to the wireless network, you can choose no encryption, Static WEP, WPA-PSK, or WPA2-PSK. Hexadecimal characters are 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, A, B, C, D, E, and F. EMG2881-T20A User’s Guide...
  • Page 56 Guest WLAN allows you to set up a wireless network where users can access to Internet via the EMG2881-T20A (Z), but not other networks connected to the Z. In the following figure, a guest user can access the Internet from the guest wireless network A via Z but not the home or company network N.

  • Page 57: Wireless Lan Screen

    Use this screen to configure the SSID and wireless security of the wireless LAN. Note: If you are configuring the EMG2881-T20A from a computer connected to the wireless LAN and you change the EMG2881-T20A’s SSID, channel or security settings, you will lose your wireless connection when you press Apply to confirm.
  • Page 58 Select Enable to activate the 2.4GHz and/or 5GHz wireless LAN. Select Disable to turn it off. Note: You can enable or disable both 2.4GHz and 5GHz wireless LANs by using the WIFI button located on the side panel of the EMG2881-T20A. Name (SSID) The SSID (Service Set IDentity) identifies the Service Set with which a wireless client is associated.

  • Page 59: Wireless Security

    If you are in the Wireless LAN 2.4G > General screen, you can select from the following: • 802.11b: allows either IEEE 802.11b or IEEE 802.11g compliant WLAN devices to associate with the EMG2881-T20A. In this mode, all wireless devices can only transmit at the data rates supported by IEEE 802.11b. •...

  • Page 60: No Security

    Select No Security to allow wireless clients to communicate with the access points without any data encryption. Note: If you do not enable any wireless security on your EMG2881-T20A, your network is accessible to any wireless networking device that is within range.

  • Page 61: More Ap Screen

    Timer clients. The default is 3600 seconds (60 minutes). Apply Click Apply to save your changes back to the EMG2881-T20A. Cancel Click Cancel to reload the previous configuration for this screen. 7.4 More AP Screen This screen allows you to enable and configure multiple wireless networks and guest wireless network settings on the EMG2881-T20A.

  • Page 62: More Ap Edit

    Chapter 7 Wireless LAN You can configure up to four SSIDs to enable multiple BSSs (Basic Service Sets) on the EMG2881-T20A. This allows you to use one access point to provide several BSSs simultaneously. You can then assign varying security types to different SSIDs. Wireless clients can use different SSIDs to associate with the same access point.
  • Page 63 WMM QoS Check this to have the EMG2881-T20A automatically give a service a priority level according to the ToS value in the IP header of packets it sends. WMM QoS (Wifi MultiMedia Quality of Service) gives high priority to voice and video, which makes them run more smoothly.

  • Page 64: Mac Filter Screen

    Click Cancel to reload the previous configuration for this screen. 7.5 MAC Filter Screen The MAC filter screen allows you to configure the EMG2881-T20A to give exclusive access to devices (Allow) or exclude devices from accessing the EMG2881-T20A (Deny). Every Ethernet device has a unique MAC (Media Access Control) address.

  • Page 65: Advanced Screen

    Data with its frame size larger than this value will perform the RTS (Request To Send)/CTS (Clear To Send) handshake. This field is not configurable and the EMG2881-T20A automatically changes to use the maximum value if you select 802.11a/an, 802.11a/an/ac, 802.11n, 802.11gn or 802.11bgn in the Wireless LAN 2.4G/5G >...

  • Page 66: Wps Screen

    Tx Power Set the output power of the EMG2881-T20A in this field. If there is a high density of APs in an area, decrease the output power of the EMG2881-T20A to reduce interference with other APs. Select one of the following 100%, 90%, 75%, 50%, 25% or 10%.
  • Page 67 PIN number. PIN Number This is the WPS PIN (Personal Identification Number) of the EMG2881-T20A. Enter this PIN in the configuration utility of the device you want to connect to the EMG2881-T20A using WPS. The PIN is not necessary when you use WPS push-button method.

  • Page 68: Scheduling Screen

    DESCRIPTION Status This displays Configured when the EMG2881-T20A has connected to a wireless network using WPS or when WPS Enable is selected and wireless or wireless security settings have been changed. The current wireless and wireless security settings also appear in the screen.
  • Page 69 If you click Select All you can not select any specific days and times. Click Clean All to remove all the wireless LAN scheduling. Apply Click Apply to save your changes back to the EMG2881-T20A. Cancel Click Cancel to reload the previous configuration for this screen.

  • Page 70: Chapter 8 Lan

    The LAN screens can help you configure a manage IP address, and partition your physical network into logical networks. 8.2 What You Can Do • Use the LAN IP screen to configure the IPv4 and IPv6 addresses for your EMG2881-T20A on the LAN (Section 8.4 on page 71).

  • Page 71: Lan Ip Screen

    These parameters should work for the majority of installations. 8.4 LAN IP Screen Use this screen to change the IP address for your EMG2881-T20A. Click Configuration > LAN > LAN IP. Figure 38 Configuration > LAN > LAN IP The following table describes the labels in this screen.

  • Page 72: Static Dhcp Screen

    Enable the DHCP server unless your ISP instructs you to do otherwise. Select Disable to stop the EMG2881-T20A acting as a DHCP server. When configured as a server, the EMG2881-T20A provides TCP/IP configuration for the clients. If not, DHCP service is disabled and you must have another DHCP server on your LAN, or else the computers must be manually configured.

  • Page 73: Ipv6 Lan Screen

    DESCRIPTION LAN IPv6 Address Assignment Enable_DHCPv6-PD Select this option to use DHCPv6 prefix delegation. The EMG2881-T20A will obtain an IPv6 prefix from the ISP or a connected uplink router for the LAN. Autoconfiguration Select SLAAC + RDNSS to enable IPv6 stateless auto-configuration on this interface. The...
  • Page 74 Enter the valid lifetime for the prefix. Link Local Only Select this option to only use the link local address on the EMG2881-T20A interfaces in the LAN. Select this option to identify a unique local address of the EMG2881-T20A in the LAN.

  • Page 75: Chapter 9 Applications

    This can cause a reduction in network performance and make the network inadequate for time-critical application such as video-on-demand. Configure QoS on the EMG2881-T20A to group and prioritize application traffic and fine-tune network performance. Setting up QoS involves these steps: Configure classifiers to sort traffic into different flows.

  • Page 76: What You Need To Know

    Bursty traffic may cause network congestion. Traffic shaping regulates packets to be transmitted with a pre-configured data transmission rate using buffers (or queues). Your EMG2881-T20A uses the Token Bucket algorithm to allow a certain amount of large bursts while keeping a limit at the average rate.

  • Page 77: Security

    (Before Traffic Policing) (After Traffic Policing) The EMG2881-T20A supports three incoming traffic metering algorithms: Token Bucket Filter (TBF), Single Rate Two Color Maker (srTCM), and Two Rate Two Color Marker (trTCM). You can specify actions which are performed on the colored packets. See Section 9.7 on page 83...

  • Page 78: The Qos General Screen

    You can also set this number lower than the interfaces’ actual transmission speed. This will cause the EMG2881-T20A to not use some of the interfaces’ available bandwidth. If you leave this field blank, the EMG2881-T20A automatically sets this number to be 95% of the WAN interfaces’ actual upstream transmission speed.

  • Page 79: The Queue Setup Screen

    A gray bulb signifies that this queue is not active. Name This shows the descriptive name of this queue. Interface This shows the name of the EMG2881-T20A’s interface through which traffic in this queue passes. Priority This shows the priority of this queue. Modify Click the Edit icon to edit the queue.

  • Page 80: The Class Setup Screen

    (such as Telnet) to form a flow. You can give different priorities to traffic that the EMG2881-T20A forwards out through the WAN interface. Give high priority to voice and video to make them run more smoothly. Similarly, give low priority to many large file downloads so that they do not reduce the quality of other applications.

  • Page 81: Add/Edit A Classifier

    9.5.1 Add/Edit a Classifier Click Add New Classifier in the Class Setup screen or the Edit icon next to a classifier to open the following screen. Figure 45 Configuration > Applications > Bandwidth Management > Class Setup: Add/Edit new class EMG2881-T20A User’s Guide...

  • Page 82: Index

    You should have configured a queue in the Queue Setup screen already. Back Click this to return to the previous screen. Apply Click this to save your changes. Cancel Click this to exit this screen without saving. EMG2881-T20A User’s Guide...
