Maintenance Indicators

■ The warning lights (power indicator, lamp indicator and temperature warning indicator) on the
projector indicate problems inside the projector.
■ If a problem occurs, either the temperature warning indicator or the lamp indicator will illuminate
red, and the projector will enter standby mode. After the projector has entered standby mode,
follow the procedures given below.
About the temperature warning indicator
If the temperature inside the projector increases, due to blockage of the air vents, or the setting location,
" " will illuminate in the lower left corner of the picture. If the temperature keeps on rising, the lamp
will turn off and the temperature warning indicator will blink, the cooling fan will run, and then the projec-
tor will enter standby mode. After "
page 56.
About the lamp indicator
■ When the remaining lamp life becomes 5% or less,
displayed on the screen. When the percentage becomes 0%, it will change to
automatically turn off and then the projector will automatically enter standby mode. At this time, the
lamp indicator will illuminate in red.
■ If you try to turn on the projector a fourth time without replacing the lamp, the projector will
not turn on.
Indicators on the Projector
Power indicator
Lamp indicator
Temperature warning
indicator
Top View
" appears, ensure you perform the measures described on
Red on Normal (Standby)
Green on Normal (Power on)
Red blinks Abnormal (See page 56.)
Green blinks Normal (Cooling)
Green on Normal
Green blinks The lamp is warming up.
Red on The lamp is shut down abnormally or requires to be
changed. (See page 56.)
Off Normal
Red on The internal temperature is abnormally high. (See page 56.)
Temperature warning indicator
Lamp indicator
Power indicator
(yellow) and "Change The Lamp" will be
(red), the lamp will
55
