Aiphone RY-IP44 Programming Manual

Input/output network adaptor

Hide thumbs Also See for RY-IP44:

Table of Contents

Download this manual

ATTENTION:

This manual is for programming the RY-IP44 with the IPW-1A only. Refer to the IPW-1A

Installation and Operation Manuals for complete installation/programming information.

For instructions featuring the RY-IP44 with the IX2 Series, visit www.aiphone.com/IX2-RYIP44

For instructions featuring the RY-IP44 with the IS IP Series, visit www.aiphone.com/ISIP-RYIP44

RY-IP44

Input/Output Network Adaptor

Programming Manual

For use with the IPW-1A

1218

Table of Contents

Need help?

Do you have a question about the RY-IP44 and is the answer not in the manual?

Page 1 For use with the IPW-1A ATTENTION: This manual is for programming the RY-IP44 with the IPW-1A only. Refer to the IPW-1A Installation and Operation Manuals for complete installation/programming information. For instructions featuring the RY-IP44 with the IX2 Series, visit www.aiphone.com/IX2-RYIP44...
Page 2: Package Contents
Configuring the RY-IP44 (assigning IP address and system use) The RY-IP44 has a default IP address of 192.168.1.45. Open a web browser and point the address bar to 192.168.1.45 for access to the adaptor. The first screen to appear will be the Device Status screen.
Page 3 Relay triggers when any station calls. No assignment required. * When using the RY-IP44 for door release, the relay on the IPW-1A must be set to door release and the relay must be jumpered to the sensor input as shown below.
Page 4 Relay Output Programming (continued) Enter the Station ID for the IPW-1A to be associated with each relay on the RY-IP44. Select the relay condition from the Relay Action drop down menu. When done, click on Apply Settings. Click Reboot on the next screen to restart the adaptor with the applied settings.
