Aiphone RY-IP44 Programming Manual

Input/output
Hide thumbs Also See for RY-IP44:

Advertisement

Quick Links

Download this manual See also: Programming Manual
1214
RY-IP44
Input/Output Network Adaptor
Programming Manual
For use with IX Series, IS-IP Series, and IPW-1A
ATTENTION:
This is the programming manual for the RY-IP44 only. Refer to the Installation and Setting
Manuals for the series being integrated with for complete installation/programming information
on each system (IX, IS-IP, IPW-1A).

Advertisement

loading
Need help?

Need help?

Do you have a question about the RY-IP44 and is the answer not in the manual?

Questions and answers

Related Manuals for Aiphone RY-IP44

Summary of Contents for Aiphone RY-IP44

  • Page 1 For use with IX Series, IS-IP Series, and IPW-1A ATTENTION: This is the programming manual for the RY-IP44 only. Refer to the Installation and Setting Manuals for the series being integrated with for complete installation/programming information on each system (IX, IS-IP, IPW-1A).

  • Page 2: Package Contents

    Unique IP address for each adaptor Overview / Description The RY-IP44 is an IP adaptor with 4 relay outputs and 4 contact inputs. This adaptor is designed to work with Aiphone’s IX Series, IS-IP Series, and IPW-1A network intercom systems.
  • Page 3 Configuring the RY-IP44 (assigning IP address and system use) The RY-IP44 has a default IP address of 192.168.1.45. Open a web browser and point the address bar to http://192.168.1.45 for access to the adaptor. The first screen to appear will be the Device Status screen.
  • Page 4 IX Series: Uploading SIF.ini File The SIF.ini file must be uploaded to each IX station associated with the RY-IP44 adaptor. ! The IX Support Tool or web browser interface can be used to upload the SIF.ini file to each station.
  • Page 5 Door Release Settings under the Function Settings tree in the IX Support Tool. When the relay action is set for the “Door Release” options, the relay on the RY-IP44 will trigger when the associated station is calling or communicating and its door release contact is triggered.
  • Page 6 IX Series: Input Programming The RY-IP44 adaptor has 4 inputs. These inputs can be programmed to trigger a call-in from a specific door station or master station to a specific master station or group of master stations. The RY-IP44 inputs can have different calling rules than the default calling rule set during the IX Series programming.
  • Page 7 H. Click Updating the system from the menu on the left. Click the Update button and the unit will update and restart itself. Repeat this process for each IS-IP door and master station to be associated with the RY-IP44 adaptor.
  • Page 8 IS-IP Series: Relay Output Programming The RY-IP44 has 4 relays. These relays can be programmed to trigger when a specific door station is calling, while in communication, or while calling and communicating. The relays can also be programmed for door release from one or multiple IP master station(s).
  • Page 9 Once all masters have been checked, click Apply Settings at the bottom of this window to save the settings to memory. Reboot to update adaptor settings. Note: The IS-SOFT software masters can NOT be enabled for door release using the RY-IP44.
  • Page 10 Input Programming The RY-IP44 adaptor has 4 inputs. These inputs can be programmed to trigger a call-in from a specific door station to a specific master station or group of master stations (max. 20). The RY-IP44 inputs can have different calling rules than the default calling rule set under Advanced Station Settings in the IS Host Programming.
  • Page 11 Relay triggers when any station calls. No assignment required. * When using the RY-IP44 for door release, the relay on the IPW-1A must be set to door release and the relay must be jumpered to the sensor input as shown below.
  • Page 12 RY-IP44 Dimensions Mounting: The RY-IP44 adaptor mounts to an Aiphone W-DIN11 mounting rail (sold separately). Depth: 1-1/4” 4-1/8” RY-IP44 Wiring = Power Transformer (use proper power for the strike, mag lock, or external signaling device being used). Relay contact rating: 30V DC, 0.5A.
