SALTWATER SYSTEM/FILTER PUMP
Saltwater System/Filter Pump
1. Remove the Saltwater System/Filter Pump and hoses from the packaging.
2. Place the Saltwater System/Filter Pump in a location for hose (8) connections to
the plunger valve assemblies.
NOTE: Some regional regulations may require the filter pump to be
mounted on a stationary platform. There are two mounting holes located in
the pump base for this reason. Consult your local authorities for filter
pump mounting requirements.
3. Grasp the two pump hoses (8) and connect the hose nuts to the Saltwater
System/Filter Pump.
4. In a counter-clockwise motion unscrew the threaded filter housing collar (3) from
the filter housing. Place it in a safe place.
5. The Saltwater System/Filter Pump is an airtight system. In a counter-clockwise
motion turn both air release valves (1 & 7) 1 - 2 turns to open. DO NOT remove
air release valves as water will expel with force if the motor is turned on
and injury may occur.
6. Grasp and remove the filter housing cover (4). Check to see if a cartridge is
inside the housing. If yes, replace the cover, finger tighten the housing collar (3)
back onto the filter housing.
7. Gently finger tighten the sediment release valve located at the bottom of the
housing to be sure that water does not leak out.
8. When the pool is filled connect the hose from the electrolytic cell outlet to the
highest strainer assembly. You will find the hose connection at the bottom of the
plunger valve assembly. Use the hose nut to attach the hose.
9. Connect the second hose to the middle of the motor housing and to the
remaining liner connection.
To prevent air lock, open the lower plunger valve (connected inlet hose)
first and then the upper plunger valve (connected outlet hose). Open air
release valves, lift and lower the inlet hose until water starts to flow out of
the air release valves, close air release valves.
SAVE THESE INSTRUCTIONS
