STM32L4 Discovery Board for IoT node (B-L475E-IOT01A)
STM32L4 Discovery Board for IoT node (B-L475E-IOT01A)
Hardware Description
The STM32L4 Discovery kit for the IoT node (B-L475E-IOT01A) allows users to
develop applications with direct connection to cloud servers. The STM32L4 Discovery
kit enables a wide diversity of applications by exploiting low-power multilink
communication (BLE, Sub- GHz), multiway sensing (detection, environmental
awareness) and ARM® Cortex®-M4 core-based STM32L4 Series features. Arduino™
Uno V3 and PMOD connectivity provide unlimited expansion capabilities with a large
choice of specialized add-on boards.
Key Product on board
•
Ultra-low-power STM32L4 Series MCUs based on ARM® Cortex® -M4 core with 1
Mbyte of Flash memory and 128 Kbytes of SRAM, in LQFP100 package
•
Bluetooth® V4.1 module (SPBTLE-RF)
•
Sub-GHz (868 or 915 MHz) low-power-programmable RF module (SPSGRF-868 or
SPSGRF-915)
•
Wi-Fi® module Inventek ISM43362-M3G-L44 (802.11 b/g/n compliant)
•
Dynamic NFC tag based on M24SR with its printed NFC antenna
•
2 digital omnidirectional microphones (MP34DT01)
•
Capacitive digital sensor for relative humidity and temperature (HTS221)
•
High-performance 3-axis magnetometer (LIS3MDL), 3D accelerometer and 3D
gyroscope (LSM6DSL), 260-1260 hPa absolute digital output barometer (LPS22HB),
Time-of-Flight and gesture-detection sensor (VL53L0X)
•
USB OTG FS with Micro-AB connector
• Expansion connectors: Arduino™ Uno V3, PMOD
•
Flexible power-supply options: ST LINK USB VBUS or external sources
•
On-board ST-LINK/V2-1 debugger/programmer with USB re-enumeration capability:
mass storage, virtual COM port and debug port
Hardware Overview (4/4)
Latest info available at www.st.com
B-L475E-IOT01A
