Page 6
Sliding curtains SIDE OPENING CENTRE OPENING One motor, One motor, Curtain collects on Curtain collects at two sides, the left or the right side of One overlap arm and one a track, straight arm. One overlap arm.
Page 7
Dimensions curtain rails (fold 150-200%) side opening type L1 – space occupied by curtain (without overlap arm) L1= 20cm + 14cm/per meter (10 runners/per meter of rail) L2 – space occupied by curtain (with overlap arm) L2 = 27cm + 14cm/m...
Page 8
Dimensions curtain rails (fold 150-200%) centre opening type L1 – space occupied by curtain (without overlap arm) L1= 20cm + 7cm/per meter (10 runners/per meter of rail) L2 – space occupied by curtain (with overlap arm) L2 = 27cm + 7cm/per meter...
Page 9
Dimensions curtain rails (wave 150-250%) side opening type L1 – space occupied by curtain (without overlap arm) L1= 20cm + 28cm/per meter (20 runners/per meter of rail) L2 – space occupied by curtain (with overlap arm) L2 = 27cm + 28cm/per meter...
Page 10
Dimensions curtain rails (wave 150-250%) centre opening type L1 – curtains place (without overlap arm) L1= 20cm + 14cm/m (20 runners/m rail) L2 – curtains place (with overlap arm) L2 = 27cm + 14cm/m...
Page 11
Installation CEILING WALL Universal swivel bracket Universal swivel bracket (1,5pcs./m+1pc.), (1,5pcs./m+1pc.) with single or double wall brackets, Allows the single/double track to be installed on a single element.
Page 17
Motor WT – four-wire cable (2 control wire) Motor DCT – three-wire cable wire control 230V (WT), infrared (DCT), radio Somfy RTS (DCT), dry contact by RJ slot (DCT), smart home system (DCT lub WT)
Page 18
Usage limitations Max length of curtain rail in one part 7,10 m. Max length of connected curtain rail 18,0 m. Max weight of curtains 60 kg (for mMotion 60e). Radius (90 degrees) 35 cm. Manual override of curtains available at any moment.
Page 19
Voltage delivery – 1 cm to the centre Ceiling – 32 cm down from upper Wall of the motor (a wire goes through a edge of rail (ceiling) and on the hole in the pulley). vertical end line of the motor.
Page 20
Motor installation – the motor is ) – the Standard Inverse (top mount installed to bottom side of the rail. motor is installed above the track ceiling). (available hiding in the...
Page 23
Dimensions Make sure that your order contains: the lenght, the opening type (side/central opening track), the motor type (35/60/Irismo), the control type, the installation and setting features (classic/inverse), the set of rail junctions or delivery in one part (more than 2,65 meters), additional comments.
Page 26
Bended rails dimensions Dimensioning of bended rails (arc up to 90 degrees) Please, specify 2 dimensions in your order: Bending radius from 30 to 35 cm.
Page 27
Bended rails dimensions Dimensioning of bended rails with larger radius (non-standard) A template in 1:1 scale should be prepared to enable the user to set the probe in correct position. A template should be delivered to the place of establishment of the producer. It is also possible to make a longer rail to adjust on your own in the installation place.
Page 28
Bended rails dimensions In case of bended rail – a distance between the centre of a rail to the nearest obstacle - 10 cm for single and 20 cm for double curtain rail is required.
Page 29
Rails dimensions Curtains should not overlap the window, when they are on both sides. Curtain opening type should take into account a configuration of furniture and furnishing articles in the room.
Page 32
Before installation Electric curtain rails with a length more than 265 cm can be delivered in few parts to assemble on the installation place. Before assembling the product, prepare a clean workplace. If components get dirty, the trouble-free usage can be disturbed. Please, follow the instructions attatched to the product during the installation.
Page 34
Manual assemble 1. Rail cut (only when the rails is shortening). = final width – 14cm Rail width...
Page 35
Manual assemble 2. Place the belt holder. 3. Place the master carrier.
Page 36
Manual assemble 4. Slide the master carrier into the rail and pull it through the rail.
Page 37
Manual assemble 5. Remove the master carrier and belt holder.
Page 38
Manual assemble 6. Unscreew the stoppers on both pulleys.
Page 39
Manual assemble 7. Slide the belt through the pulley.
Page 40
Manual assemble 8. Place the belt holder and snap it.
Page 41
Manual assemble 9. Place the master carrier. 10. Slide the master carrier into the rail and pull it through the rail.
Page 42
Manual assemble 11. Fit the pulley onto the rail.
Page 43
Manual assemble Cut the belt. 20 tooth (100 mm) must be outside the rail and half master carrier must be on the edge of the rail. (only when the rails is shortening)
Page 44
Centre opening – manual assemble THESE INSTRUCTIONS ARE ONLY FOR CENTRE OPENING RAIL TYPE. 12-1. Pull out the opposite pulley.
Page 45
Centre opening – manual assemble THESE INSTRUCTIONS ARE ONLY FOR CENTRE OPENING RAIL TYPE. 12-2. Select location for master carrier. Pleace belt holder and snap it. Place the master carrier and slide it into the rail.
Page 46
Centre opening – manual assemble THESE INSTRUCTIONS ARE ONLY FOR CENTRE OPENING RAIL TYPE. 12-3. Fit the pulley onto the rail.
Page 47
Manual assemble 13. Remove the master carrier and belt holder.
Page 48
Manual assemble 14. Slide the belt through the pulley.
Page 49
Manual assemble 15. Place the belt holder and snap it.
Page 50
Manual assemble 16. Place the master carrier. 17. Slide the master carrier into the rail.
Page 51
Manual assemble 18. Fit the pulley onto the rail.
Page 57
Installation Incorrect installation can cause injury. Strictly follow the instructions for an assembly and a manual drive. In order to reduce the risk of electric shock, this device must be properly grounded.
Page 58
Installation Please make sure that the switches are compatible with the selected motor. The control devices must be installed in a visible place. If the drive or power wire is damaged, then return unit to service department in order to avoid possible risks.
Page 59
Installation 1) Mark the position of the brackets. 2) Drill holes. 3) Attach the bracket to the right place at the ceiling / on the wall. 4) Insert the hook for hanging the curtains on the motor (on the pulley). 5) Fasten the rail in mount.
Page 60
Installation 1) Unlock the motor. 2) Put the motor to the hole in pulley. 3) Lock the motor. 4) Connect the power supply.
Page 61
Disconnect the motor from the power supply during cleaning. Children should be supervised to ensure that they do not play with the curtain rail.
Page 66
Dry contact mMotion Plus DCT is control through dry contact switch, infrared and radio RTS (additional RTS receiver). Pins: dry contact or infrared are in RJ12 socket.
Page 68
Dry contact Dry contact control: • two contacts (open - close) , • three contacts (open, stop and close). If there are only two control contacts, then stop function is executed as simultaneous activation of the open and close contact.
