I N S T A L L A T I O N
Small Flat Panel Bracket – Floor Stand
The PAC-170 Floor Stand assembly is compatible with
small flat panels and other products and accessories
offered by Chief.
PARTS
20
Figure 1. Parts
(PAC-170)
10
30
40
CHIEF MANUFACTURING INC.
1-800-582-6480 952-894-6280 FAX 952-894-6918
8401 EAGLE CREEK PARKWAY, STE. 700
SAVAGE, MINNESOTA 55378 USA
I N S T R U C T I O N S
PARTS LIST
Unpack the shipping carton and check for the contents
listed in Table 1 and shown in Figure 1.
Table 1. Parts List
REF
DESCRIPTION
10
FRONT BRACKET, floor stand
(with attached mounting plate)
20
SCREW, button head cap, 5/16-18 x ½"
30
BACK BRACKET, floor stand
40
ALLEN KEY, 3/16"
8807-000049 (Rev. A)
©2005 Chief Manufacturing
www.chiefmfg.com
09/05
QTY
1
4
1
1
