LINEAR FIREPLACE
INSTALLATION, SPECIFICATION AND OPERATION MANUAL
LISTED MASONRY FIREPLACE SYSTEM
MODEL FIREROCK LINEAR
60" AND 72" MODULAR FIREPLACE
UL 127 COMPLIANT
IMPORTANT: Read the entire manual before beginning construction.
Contents of this manual may change without prior notification
IMPORTANT: This manual contains product usage guidelines, in-field application rules, installation steps, and operating and
maintenance instructions for the FireRock Linear pre-engineered masonry fireplace kit. This manual should become the property
of and be reviewed by all current and future users of this product. It is the responsibility of the general contractor and the installer
to ensure that the instructions set forth in this manual are followed exactly. It is also the responsibility of the general contractor to
provide adequate clearance to combustibles (see page 18) from all fireplace surfaces as specified herein.
Before installing this product, please consult with local building and zoning authorities regarding the need for proper permitting.
If the information in this manual (including installation instructions) is not followed exactly, a fire or explosion may result, causing
property damage, personal injury, or loss of life.
Installer: Leave this manual with the appliance.
Consumer: Keep these instructions for future use.
MANUFACTURING:
ADMINISTRATIVE:
3620 Avenue C
1500 1st Ave N #75
Birmingham, AL 35064
Birmingham, AL 35203
PHONE: (205) 639-5000
TOLL-FREE: (888) 876-1025
FAX: (888) 886-3473
Advertisement
Table of Contents
Related Manuals for FireRock FIREROCK LINEAR
Summary of Contents for FireRock FIREROCK LINEAR
- Page 1 IMPORTANT: This manual contains product usage guidelines, in-field application rules, installation steps, and operating and maintenance instructions for the FireRock Linear pre-engineered masonry fireplace kit. This manual should become the property of and be reviewed by all current and future users of this product. It is the responsibility of the general contractor and the installer to ensure that the instructions set forth in this manual are followed exactly.
- Page 2 THIS PAGE INTENTIONALLY LEFT BLANK...
-
Page 3: Table Of Contents
TABLE OF CONTENTS Important Safety Information ..................................Intended Use Statement ....................................Materials and Equipment List ..................................Parts Dimensions ....................................... 8-13 Installation Considerations .................................... 14-15 Warnock Hersey Listing Label ..................................Fireplace Dimensions ....................................... Clearance to Combustibles .................................... Rough Framing Dimensions ................................... Fireplace Installation ...................................... -
Page 4: Important Safety Information
For safety information regarding the operation of this fireplace, see pages 35-37. The FireRock Linear fireplace is a modular system designed to be assembled in field using FireRock Adhesive Mortar. Each component is designed for a specific part of the firebox, smoke chamber, and flue design, and therefore only one means of assembly is possible. -
Page 5: Intended Use Statement
The fireplaces and chimney system are tested and listed by Intertek Testing Service to UL 127 and UL 103. The FireRock fireplace is designed to burn wood, gas, or coal. Use solid wood, processed solid fuel fire logs, natural gas, propane, or coal fuel only. - Page 6 The FireRock Linear fireplace is approved for Indoor and Outdoor use. Maintain stated clearance to combustibles for indoor and outdoor use.
-
Page 7: Materials And Equipment List
40” Base Plate • Level Firebox Side • Plastic shims 22 3/4” Back Wall (Courses 1 & 3) • FireRock Adhesive Mortar 25 1/4” Back Wall (Courses 2) • Insulstick 34 3/4” Back Wall (Courses 2) • Damper (for interior applications) 37 1/4”... -
Page 8: Parts Dimensions
FIREPLACE PARTS BASE PLATE SIDE ELEVATION PLAN ISOMETRIC FRONT ELEVATION FIREPLACE SIZE DIM A DIM B DIM C DIM D 60” 68” 62” 51 1/2” 34” 72” 80” 74” 63 1/2” *THIS PART IS SPLIT INTO TWO PIECES FIREBOX SIDE PLAN SIDE ELEVATION ISOMETRIC... - Page 9 FIREPLACE PARTS (CONTINUED) FIREBOX BACK WALL PLAN SIDE ELEVATION FRONT ELEVATION ISOMETRIC 60” FIREPLACE DIM A DIM B 72” FIREPLACE DIM A DIM B ROW 1 22 3/4” 37 1/4” ROW 1 22 3/4” 49 1/4” ROW 2 25 1/4” 34 3/4”...
- Page 10 FIREPLACE PARTS (CONTINUED) SQUARE THROAT BACK PLAN SIDE ELEVATION FRONT ELEVATION ISOMETRIC FIREPLACE SIZE DIM A DIM B DIM C 60” 68” 72” 80” 43” 37” *THIS PART IS SPLIT INTO TWO PIECES FOR THE 70” MODEL THROAT SIDE (LEFT) BACK ELEVATION SIDE ELEVATION PLAN...
- Page 11 FIREPLACE PARTS (CONTINUED) THROAT SIDE (RIGHT) BACK ELEVATION SIDE ELEVATION PLAN ISOMETRIC SMOKE CHAMBER FRONT/BACK PLAN SIDE ELEVATION FRONT ELEVATION ISOMETRIC 60” FIREPLACE DIM A DIM B DIM C 72” FIREPLACE DIM A DIM B DIM C ROW 1 62” 30 11/16”...
- Page 12 FIREPLACE PARTS (CONTINUED) UNIVERSAL SMOKE CHAMBER SIDE PLAN SIDE ELEVATION FRONT ELEVATION ISOMETRIC CHIMNEY BASE SIDE ELEVATION PLAN FIREPLACE SIZE DIM A 60” 26” 72” 32” *PART SHOWN IS LEFT SIDE. RIGHT SIDE IS MIRRORED TO FIT.
- Page 13 FIREPLACE PARTS (CONTINUED) CHIMNEY BLOCK SIDE ELEVATION PLAN ISOMETRIC...
-
Page 14: Installation Considerations
Avoid placing a fireplace in an area near tall trees or buildings that can reduce air flow pressure and/or produce down drafts. FireRock Products, LLC does not warrant drafting and is not responsible for it. Refer to page 31 for more information on using an outside air kit with a FireRock pre-engineered masonry fireplace kit. B. TERMINATIONS The termination of the chimney above the roof must extend at least 3’... -
Page 15: Installation Considerations
E. LOG LIGHTER A log lighter can be used with your FireRock fireplace as either a flush mount (installed before the firebrick) or top mount. FireRock recommends the log lighter be installed by a professional plumber. See manufacturer’s instructions for directions on how to install. -
Page 16: Warnock Hersey Listing Label
SEE FIRE ROCK’S INSTALLATION AND OPERATING INSTRUCTIONS FOR THIS MODEL *ADDITIONAL FLOORING PROTECTION IS REQUIRED AS DETERMINED BY THE HEIGHT OF THE UNIT. SEE FIREROCK INSTALLATION MANUAL FOR FLOORING PROTECTION SPECS. REFER TO THE INTERTEK DIRECTORY OF BUILDING PRODUCTS (HTTPS://BPDIRECTORY.INTERTEK.COM) FOR DETAILED INFORMATION. -
Page 17: Fireplace Dimensions
FIREPLACE DIMENSIONS DIMENSION 60” 72” OVERALL WIDTH 68” 80” OVERALL DEPTH 28.5” 28.5” FIREBOX HEIGHT 28.875” 28.875” SMOKE CHAMBER HEIGHT 31.5” 31.5” OPENING WIDTH* 62.5” 74.5” OPENING HEIGHT* 25.125” 25.125” WIDTH AT CHIMNEY BASE 50” 62” FIREBOX DEPTH 22.5” 22.5” WIDTH AT REAR 52”... -
Page 18: Clearance To Combustibles
CLEARANCE TO COMBUSTIBLES Opening to Side wall 32” MANTLE Opening to Combustible Trim 12’ 6” TILE/MARBLE ” ” Opening to Combustible Mantle with 8” 16” Depth ” ” FLUSH HEARTH EXTENSION FIGURE 2.1 Noncombustible Flush 32” front, 8” each side Hearth Extension Noncombustible Raised (>12”) MANTLE... -
Page 19: Rough Framing Dimensions
71” 83” The numbers listed are the framing dimensions recommended by FireRock, which add ½” of air space to the required clearances. Always maintain the stated minimum clearance to combustibles for this unit. Failure to maintain stated minimum clearance to combustibles on page 18 may result in a fire or explosion, causing property damage, personal injury, or loss of life. -
Page 20: Fireplace Installation
It is the responsibility of the general contractor to ensure adequate foundations. NOTE: Use of the FireRock base plate is optional for either of the above foundation types (concrete slab or concrete pad) FIGURE 4.2... -
Page 21: Mixing And Applying Mortar
FIREPLACE INSTALLATION STEP 2: MIXING AND APPLYING MORTAR FIREROCK ADHESIVE MORTAR FireRock Adhesive Mortar must be used when building the FireRock fireplace for your FireRock warranty to be valid. Use of other mortar will void your FireRock warranty This mortar is available from your FireRock dealer or distributor. -
Page 22: Firebox Assembly
Apply a layer of mortar to the area and set the base plate 2 PIECE BASE PLATE ON CONCRETE SLAB pieces, mortaring the two pieces together using FireRock Adhesive Mortar (Figure 6.1). Whether using a flush hearth or a raised hearth, a noncombustible hearth must extend at least 32”... - Page 23 LEVELING AND ALIGNING COMPONENTS It is important that each course of the firebox is level and flush with adjoining components. FireRock mortar is not intended to create a mortar joint of any thickness for leveling purposes. Leveling and alignment adjustments should be made by the use of small shims.
-
Page 24: Throat And Damper Assembly
FIREPLACE INSTALLATION STEP 4: THROAT AND DAMPER ASSEMBLY THROAT (FIGURE 7.1) Begin building the throat by placing the radius throat front and square throat back. Remember to completely cover each component with mortar 1/2” - 1” thick where it will lie or butt up against another component. -
Page 25: Smoke Chamber Assembly
FIREPLACE INSTALLATION STEP 5: SMOKE CHAMBER ASSEMBLY SMOKE CHAMBER The front and back of the smoke chamber are also split into two pieces and can only be positioned one way. See Figure 8.3 and Figure 8.4 for specific dimensions for the 60” and 72”... -
Page 26: Insulstick Application
(square throat back, radius throat front, and throat sides), using a trowel (Figure 9). Cover each component completely at a thickness approximately 1/16”-1/8”. Failure to apply Insulstick invalidates your FireRock warranty. INSULSTICK... -
Page 27: Chimney Assembly
FIREPLACE INSTALLATION STEP 7: CHIMNEY ASSEMBLY SOLID BLOCK CHIMNEY FireRock Solid Block Chimney (Figure 10.1) may be installed from this point. Completely cover each chimney block component with 1/2” - 1” of mortar, resulting in a 1/16” - 1/8” joint. “Butter” all joints to give a smooth appearance and ensure a leak-free joint. - Page 28 FIREPLACE INSTALLATION STEP 7: CHIMNEY ASSEMBLY (CONTINUED) OFFSET BLOCKS Each offset block provides a maximum offset of 2 5/8”. Offset direction may be left, right, back, or in a spiral pattern for “twisting” flues (see Figure 10.4) Completely cover each offset block component with 1/2” - 1” of mortar, resulting in a 1/16”...
-
Page 29: Firebrick Installation
FireRock makes no claims as to the performance of firebrick or firebrick mortars except those manufactured by FireRock. It is typical for heat stress cracks to appear in the firebricks after use. The National Fire Protection Association Standard 211 says your fireplace and flue... -
Page 30: Brick Flange
BRICK FLANGE The FireRock Brick Flange (Figure 12.1) is a component that allows a true brick or stone veneer above the roofline (maximum 20 vertical feet of standard brick or equivalent). Most local building codes do not allow masonry to be supported by combustible material. Our brick flange is designed to carry the weight of a brick or stone veneer only where you see it. -
Page 31: Outside Air Kit
OUTSIDE AIR KIT INSTALLATION Outside air kits are an optional accessory that can be added to a FireRock fireplace to supplement combustion air. Outside air kits should be installed and used in accordance with requirements of the standard for fireplaces under national code NFPA 211. Follow manufacturer’s instructions for installation instructions and refer to local building code for proper sizing;... -
Page 32: Typical Gypsum Board Application
TYPICAL GYPSUM BOARD APPLICATION This fireplace is designed to be installed so a 3” ledge is left on top of the radius throat front. This ledge allows space for a framing header to maintain the required 1” clearance and at the same time align flush with the room face of the firebox. Failure to maintain stated minimum clearance to combustibles on page 18 may result in a fire or explosion, causing property damage, personal injury, or loss of life. -
Page 33: Multi-Floor Stacking Diagram
MULTI-FLOOR STACKING DIAGRAM *shown with Conventional units “ ” 1” “ ” 42” CONV UNIT 2-⁵/₈” = 40” (18) (22) COMPONENT NAME Base Plate (11’-0” Firebox Side Firebox Back - Straight Back Block Firebox Back - Level 3 Firebox Back - Level 4 Radius Throat Front (18) 1-¹/₈”... -
Page 34: Metal Chimney Installation
METAL CHIMNEY INSTALLATION Any metal chimney that carries a UL 103 compliance designation may be used with your FireRock fireplace and chimney system. A conversion adapter must be available from the metal chimney manufacturer and all necessary components, including, but not limited to, firestops, wall spacers, and insulating parts, must be utilized as required by the manufacturer. -
Page 35: Operating Instructions
OPERATING INSTRUCTIONS This section of the manual is to help you get maximum efficiency and maximum smoke (particulate) reduction from your FireRock fireplace. If you experience any difficulty or have any questions concerning your fireplace, contact your dealer/distributor or FireRock’s Technical Support Desk (888.876.1025). - Page 36 USING YOUR FIREPLACE FireRock recommends a log grate be used in your fireplace for maximum performance. The use of andirons is acceptable. Use solid wood, processed solid fuel fire logs, natural gas, propane, or coal fuel only. The manufacturer’s recommendation for peak performance is to burn seasoned hardwood (wood that has been cut and dry for 6 –...
- Page 37 Overfiring, abusive burning, or mistreatment of the fireplace unit can cause permanent damage to the unit and will invalidate your FireRock warranty. Building fires using materials other than those detailed on pages 35-36 or loading the fireplace beyond its maximum load constitutes overfiring.
- Page 38 THIS PAGE INTENTIONALLY LEFT BLANK...
-
Page 39: Terms And Conditions
Buyer, FireRock, at its sole discretion and Buyer’s expense, may agree as a service to Buyer to process Buyer’s claim against the carrier for any loss or damage in transit, provided that such claim is received by FireRock within two (2) days of delivery of the Goods to Buyer. - Page 40 5. SECURITY INTEREST: As collateral security for the payment of the purchase price of the Goods, Buyer hereby grants to FireRock a lien on and security interest in and to all of the right, title and interest, to and under the Goods, wherever located, and whether now existing or hereafter arising or acquired from time to time, and in all accessions thereto and replacements or modifications thereof, as well as all proceeds (including insurance proceeds of the foregoing).
- Page 41 HEIRS AND ASSIGNS. 14. TERMINATION: In addition to any remedies that may be provided under this Agreement, FireRock may terminate this Agreement with immediate effect upon written notice to Buyer, if Buyer: (a) fails to pay any amount when due under this Agreement;...
- Page 42 Commercial Arbitration Rules of the AAA. The AAA shall designate a panel of ten (10) potential arbitrators knowledgeable in the subject matter of the Dispute. Each of FireRock and Buyer shall designate, within thirty (30) days of the receipt of the list of potential arbitrators, one of the potential arbitrators to serve, and the two arbitrators so designated shall select a third arbitrator from the eight remaining candidates.
-
Page 43: Terms And Conditions
MASONRY FIREPLACES – EXPRESS LIMITED WARRANTY FireRock warrants to the original Buyer (including, if the original Buyer is a contractor, the original purchaser of a new, or the current owner of an existing, home or other building into which the Goods are installed) that the fireplace purchased from FireRock (the “Fireplace”) will be free from material defects in materials, under normal use, for twenty (20 years). - Page 44 Version 2.0 | 10/2018...
