- Page 1 SAVE VTC 700 Heat Recovery Ventilation Unit User Manual 207581-EN_GB 23-08-2011V.A001...
-
Page 2: Table Of Contents
Contents 1 Warnings........................... 1 2 Introduction ..........................2 3 Interface description........................3 3.1 Control panel ........................3 3.2 Display symbols ....................... 4 4 Menu settings ..........................5 4.1 Setting of temperature ...................... 5 4.2 Manual setting of fan speed ....................5 4.3 Manual summer mode ...................... -
Page 3: Warnings
Caution • Do not connect tumble dryers to the ventilation system • Duct connections/duct ends must be covered during storage and installation SAVE VTC 700 User Manual Systemair AB 207581... -
Page 4: Introduction
2 Introduction The SAVE VTC 700 is a heat recovery ventilation unit with a built in counter flow plate heat exchanger. There are two model options, right (R) and left (L) model (figure 1). This manual describes basic information how to operate and perform maintenance on the unit and the system it is connected to. -
Page 5: Interface Description
Confirm button Confirm menu choices or settings by pressing the button Back button Step back in the menu levels by pressing the button SAVE VTC 700 User Manual Systemair AB 207581... -
Page 6: Display Symbols
Confirm the setting with the “confirm button” (chapter 4.1 and chapter 4.3). Service Access to the service menu by pressing the confirmation button Alarm Access to the alarm list by pressing the confirm button SAVE VTC 700 User Manual Systemair AB 207581... -
Page 7: Menu Settings
If water heater battery is installed and activated the manual summer mode is aborted if the outdoor air or supply air temperature is ≤ 5 °C. Fig. 5 Symbol for manual summer mode SAVE VTC 700 User Manual Systemair AB... -
Page 8: Maintenance
5 Maintenance Maintenance of the SAVE VTC 700 should normally be performed 3 - 4 times a year. Apart from general cleaning the following should be observed: 5.1 Warnings Danger • Make sure that the Mains supply to the unit is disconnected before performing any maintenance or electrical work! •... -
Page 9: Changing Outdoor/Extract Air Filters
1 1 1 1 Use the selection knob for each digit and confirm with the “confirm button” after each set digit. Service Go down to Filter period, confirm Change password →Filter period Date/Time SAVE VTC 700 User Manual Systemair AB 207581... - Page 10 Change Time to replace 9 month if necessary to the time of your choice with the “selection knob”, confirm. Step back until you reach the main menu display by pressing the “back button”. SAVE VTC 700 User Manual Systemair AB 207581...
-
Page 11: Checking The Heat Exchanger
This will reduce the efficiency. The fans may be cleaned as illustrated in below procedure. Disconnect the unit from the mains by pulling out the wall plug Open the side panel by removing 4 screws SAVE VTC 700 User Manual Systemair AB 207581... -
Page 12: Cleaning Extract Louvres And Supply Air Diffusers
Leaves and pollution could plug up the air intake grille (figure 10) and reduce the capacity. Check the air intake grille, and clean as necessary. It is recommended to do this at least twice a year. SAVE VTC 700 User Manual... -
Page 13: Check Roof Cowl
(if fitted). It is recommended to do this every 5 years and is normally carried out by authorized companies specialized in this area. Fig. 11 Cleaning the duct system SAVE VTC 700 User Manual Systemair AB... -
Page 14: Trouble Shooting
Contact your installation company or place of purchase. Filter Time for filter change. The alarm is displayed in the control panel. Change filter according to instructions (chapter 5.3 and chapter 5.3.1). SAVE VTC 700 User Manual Systemair AB 207581... - Page 15 SAVE VTC 700 User Manual Systemair AB 207581...
- Page 16 Systemair AB reserves the right to make changes and improvements to the contents of this manual without prior notice. Systemair AB Industrivägen 3 SE-739 30 Skinnskatteberg, Sweden Phone +46 222 440 00 Fax +46 222 440 99 207581...
