QT/QTS Series
2022208700, September 2018
the shipment at the premises where the delivery was made. Do not move the
damaged freight from the premises where the original delivery was made.
Retain all containers and packing for inspection by the carrier.
A claim form can be requested from the carrier: Standard Form for
Presentation of Loss and Damage Claims (form # 3208). Your claim will need
to be substantiated with the following documents:
a.) form #3208
b.) original bill of lading
c.) original paid freight bill
d.) original invoice or certified copy
e.) other particulars obtainable in proof of loss or damage (photos,
damage inspection, etc.)
The proper description and classification of our product in the National
Motor Freight Classification 100-H, contained in item 118100, reads as follows:
Compressors, air, or air ends: with or without air tanks, hose or nozzles,
mounted or not mounted."
We suggest that these instructions be circulated to your shipping and
receiving personnel.
Quincy air compressors must be installed and operated in a secure, level,
upright position in an area that is clean, dry, well lighted, adequately
ventilated, and not less than 12 inches to a wall or other compressor. (Note:
A gas engine will produce carbon monoxide; always provide adequate
ventilation!) Inspection and mainte nance checks are required daily.
Therefore, sufficient space needs to be provided around the compressor for
safe and proper in spection, cleaning, and maintenance.
Ample circu la tion of air must be provided across the compressor cylinders,
heads and cooler (if so equipped). If at all possible, the pulley drive system
(i.e. motor pul ley, compressor sheave, belts and guard) should face a wall to
minimize any danger created by the drive system while the compressor is
operating. Do not allow hot air from additional equipment to blow towards
the compressor.
Quincy compressors should be operated in temperatures under 104°F. In
cold cli mates, the compressor should be installed in a heated building.
Do not operate this compressor in ambient temperatures lower
than 0° F. A crankcase heater is recommended for a compressor
that is to operate in temperatures under 32° F.
Under no circumstances should a compressor be used in an area
that may be exposed to toxic, volatile, or corrosive atmo sphere. Do
not store toxic, volatile, or corrosive agents near the compressor
Noise
Noise is a potential health hazard that must be considered. There are
federal and local laws governing acceptable noise levels. Check with local
officials for specifications.
