PLEASE READ THESE INSTRUCTIONS BEFORE COMMENCING ASSEMBLY.
retain this instruction sheet in your files.
replacement parts information.
accordance with these instructions.
maintain all public playground equipment properly.
equipment, which is improperly maintained, can cause serious injury.
Periodical inspections, maintenance, repair and/or replacement of
damaged parts is necessary for safe operation of equipment.
Appropriate publications, available at no charge, from the Consumer
Product Safety Commission, include "A Handbook for Public Playground
Safety".
PACKING LIST
1
CTN
Hardware Box
2
PLT
6
Aztec Plastic Panels
3
Vertical Connecting Poles
2
Horizontal Connecting Poles
2
Aztec Panel Ground Anchors
SportsPlay Equipment, Inc., 5642 Natural Bridge, St. Louis, MO 63120 (314) 389-4140
902-757 Corkscrew Aztec Climber
You can receive your free copy by calling 1-301-504-0708.
2 SKIDS
www.sportsplayinc.com
IMPORTANT
It contains important
All equipment must be installed in
It is important to use and
36
36
72
72
905-847
1
805-532
1
805-534
Weight 1,141#
Page
Rev. 04/9/2010
Please
Playground
HARDWARE BOX
M10 x 60 Hex Bolts
M10 Nylon Insert Lock Nuts
Flat Washers
Bolt Caps
Warning Label
SportsPlay Label
Class 70
1
Advertisement
Related Manuals for Aztec 902-757 Corkscrew
Summary of Contents for Aztec 902-757 Corkscrew
- Page 1 902-757 Corkscrew Aztec Climber Page Rev. 04/9/2010 IMPORTANT PLEASE READ THESE INSTRUCTIONS BEFORE COMMENCING ASSEMBLY. Please retain this instruction sheet in your files. It contains important replacement parts information. All equipment must be installed in accordance with these instructions. It is important to use and maintain all public playground equipment properly.
- Page 2 902-757 Corkscrew Aztec Climber Page Rev. 04/9/2010 GENERAL FOOTING RECOMMENDATIONS: Diameter and depth of footings illustrated are satisfactory in most applications for pipe sizes up to 4” diameter. Varying soil & climatic conditions may require deeper and heavier footings in some areas.
- Page 3 902-757 Corkscrew Aztec Climber Page Rev. 04/9/2010 Complete Footing Layout SportsPlay Equipment, Inc., 5642 Natural Bridge, St. Louis, MO 63120 (314) 389-4140 www.sportsplayinc.com...
- Page 4 902-757 Corkscrew Aztec Climber Page Rev. 04/9/2010 Footing Layout (Close up of the ends) SportsPlay Equipment, Inc., 5642 Natural Bridge, St. Louis, MO 63120 (314) 389-4140 www.sportsplayinc.com...
- Page 5 902-757 Corkscrew Aztec Climber Page Rev. 04/9/2010 SportsPlay Equipment, Inc., 5642 Natural Bridge, St. Louis, MO 63120 (314) 389-4140 www.sportsplayinc.com...
- Page 6 902-757 Corkscrew Aztec Climber Page Rev. 04/9/2010 Use Zone SportsPlay Equipment, Inc., 5642 Natural Bridge, St. Louis, MO 63120 (314) 389-4140 www.sportsplayinc.com...
-
Page 7: General Maintenance Instructions
STEP #2: Attach the Aztec Plastic Panel to the Aztec Panel Ground Anchor by placing the Plastic Panels over the tabs of Ground Anchors. Note: The King Figure must be on the lower left. - Page 8 Repeat Steps 1, 2 and 3 with other Ground Anchor and Plastic Panel. STEP #5: Attach the other side of the Aztec Plastic Panel to the Vertical Connecting Post utilizing the same fastening technique as was used in steps 1 and 2.
- Page 9 902-757 Corkscrew Aztec Climber Page Rev. 04/9/2010 STEP #7: Attach Aztec Plastic Panel to Vertical Connecting Post and in turn to Horizontal Connecting Post. Secure using same technique as before. Note: The Dragon Figure must face upwards as shown below...
- Page 10 902-757 Corkscrew Aztec Climber Page Rev. 04/9/2010 STEP #9: Plumb & level entire unit. Fully snug all fasteners. Push bolt caps in to bolt covers. Pour Concrete with slight dome to ensure proper drainage. Wait 48 hours before removing braces. Install resilient safety surfacing.
