Conducted Immunity Protection
For conducted immunity protection of the option connector it is recommended to connect a capacitor (min 100n,
500v) between Aux common (pin3) and earth.

10. CONNECTION

AC INPUT CONNECTOR (J1) MATING PARTS

Tyco part
Description
number
350766-1 Tyco mate-N-lok 3-way housing UL94V-0
926893-1 Tyco female crimp 14~20AWG
926895-1 Tyco female crimp 18~24AWG

AC INPUT CONNECTOR (J1) PIN DEFINITION

Pin Function
J1-3 Live
J1-2 Earth - chassis
J1-1 Neutral

SIGNAL CONNECTORS (J2,J3) MATING PARTS

Molex part
Description
number
22-01-1102 Molex 5051 series 10-way housing UL94V-0
08-70-0064 Molex 5159 series crimp terminal 22~28AWG

SIGNAL CONNECTORS (J2,J3) PIN DEFINITION

J2, J3 pin Function
1 + sense
2 - sense
3 COM (return for pins 6,7,8,9,10)
4 - remote on/off
5 + remote on/off
6 Aux
7 Current share
8 Trim
9 ENA
10 IOG

POWER TERMINALS

The +ve and –ve output power terminals each have one M6x18 vertical stud.
M6 nuts, flat washers and spring washers are supplied fitted to each terminal.
Maximum recommended torque for the M6 terminals is 10Nm.

11. WEIGHTS

All models without cover
All models with cover

12. TEST RESULTS

Production test results are available online from: - http://testcert.emea.tdk-lambda.com/
The serial number and product code of the unit will need to be entered to retrieve test results from the online
database.
Test results are not packaged with the unit.
CPFE500F Application Note
= 1200g nominal
= 1375g nominal
Document Number : 61066 iss 2 Page 17 of 17
