In the Setup Menu, your
D
changes are saved automatically
each time you enter a new value.
Download QuickPlay Pro from
E
http://www.colorkinetics.com/ls/
controllers/quickplaypro/.
Example 3: Setting Alarm Number 5 to Activate Every Day at Sunset
1. Launch Configuration mode.
Access the Alarm menu, then select alarm number 5.
2.
Access the Alarm Days menu, then select Every Day.
3.
At the Alarm Type menu, select Astronomical.
4.
Select Sunset from the Sunrise or Sunset menu.
5.
6. Add an offset value to trigger the show a certain amount of time before or
after sunset:
a.
Enter an Alarm Hour Offset value, then press
b. Enter an Alarm Minute Offset value, then press
Select a Trigger number with which to associate the alarm.
7.
Press to save your changes.
8.

Setup Menu

The Setup Menu contains configurable settings for the following:
Expansion or Serial Ports Devices attached to the two iPlayer 3 serial ports
•
can trigger any of up to 255 shows stored on iPlayer 3. By default, an external
device triggers shows starting with show 1. However, you can use the iPlayer 3
base trigger setting to specify a different starting show number (see "Example
6" on page 18 for details).
iPlayer 3 Date and Time
•
iPlayer 3 latitude and longitude Used in sunrise and sunset calculations.
•
LCD Screen Appearance You can specify an integer from 0 – 10 to set the
•
contrast and brightness, with 10 producing the greatest brightness and
contrast between the characters on the screen and the background.
Volume You can specify an integer (0 – 3) to set the audible volume of the
•
iPlayer 3 internal speaker, which produces a beep with each button press. The
loudest setting is 3.
Setting a DMX address
•
Testing a DMX address
•
Example 4: Setting a DMX Address
QuickPlay Pro provides the most convenient method for addressing the fixtures in
your DMX lighting installation. However, if needed, you can also use the iPlayer 3
onboard setup menu to set DMX addresses.
There are two options for specifying which fixtures to address via iPlayer 3. You
can set all connected fixtures to a single DMX address, or you can specify a DMX
address for each individual fixture:
1. Launch Configuration mode.
2. Access the Setup menu, then select Set Fixture DMX Add.
3. If you want to specify a DMX address for all fixtures, select All Same Address.
If you want to specify a DMX address for each individual fixture:
a. Select By Serial Number, and then press
b. At the S/N Byte 1, S/N Byte 2, S/N Byte 3, and S/N Byte 4 prompts, enter
the serial number of the fixture, using hexadecimal integers 00 – FF (42 00
01 1F, for example). The fixture will blink when you enter each correct byte.
c. Press to confirm the serial number.
.
.
.
iPlayer 3 User Guide 17
