S7999B System Display
Software Upgrade .............................................................
Specifications ....................................................................
Safety Features .................................................................
Installation Instructions......................................................
Installing the Hardware...................................................... 16
Quick Setup....................................................................... 16
Starting the Display ........................................................... 17
APPLICATION
The S7999B System Display reduces burner/boiler setup time
by letting you create a fuel/air modulation curve (profile) for
ControLinks™ that allows for safe and efficient operation at all
points along the modulation curve. The display uses a wizard-
like process to assist you through the commissioning process.
The S7999B can be used on systems with one or two fuels
and on systems with or without flue gas re-circulation (FGR).
The S7999B can monitor a single (Local) burner/boiler system
or up to 99 burner/boiler systems connected via System
Modbus™ network. Each burner control, fuel/air ratio control,
and expanded annunciator present on each burner system
can be viewed individually to determine its status.
Universal Digital Controllers (UDC) can be used for several
burner/boiler applications, and the S7999B can control the
UDCs during their operation. Applications supported include:
• stack temperature
• water/steam PID load control
• steam/fuel flow monitoring
• thermal shock
• feed pump level control
2
Display Operation .............................................................. 20
3
Commissioning .................................................................. 21
4
Monitoring.......................................................................... 35
4
UDC Controllers ................................................................ 43
Display Setup and Diagnostics .......................................... 47
Advanced Setup ................................................................ 53
R7999 Outputs and Inputs................................................. 64
Troubleshooting ................................................................. 59
PRODUCT DATA

Table of Contents

65-0283-2
