- Page 2 NOTICE The use of other than genuine ESCO replacement parts may result in safety hazards, decreased tool performance, and increased maintenance, and may invalidate all warranties. Repairs should be made only by authorized personnel. Consult your nearest ESCO Authorized Service Center.
- Page 3 OPERATION OF THE EQUIPMENT IN ACCORDANCE WITH SPECIFIED USE Depending on the working environment and how the Torque Master I Series Pneumatic Torque Wrench is used, local health and safety regulations may require you wear protective gear (i.e. Ear Protection, Safety Shoes, Hard Hat, Gloves, Coveralls, etc.) In case external forces are exerted on the equipment, non-compliance with these regulations may result in injury.
- Page 4 Do not lubricate tools with flammable or volatile liquids such as kerosene, diesel or jet fuel. Use only ESCO recommended lubricants.
-
Page 6: Operating Procedures
To decrease torque output turn regulator counter-clockwise to lower air flow/pressure. All Torque Master I are shipped calibrated per ESCO Procedures. Check for Desired Torque Setting for your selected model on the supplied torque chart. On the Torque Master I F/R/L, adjust air pressure by using the air regulator knob for desired pressure/torque. - Page 7 Unauthorized manipulation of air motor, valves, & ESCO F/R/L Unit or tampering with either will result in loss of warranty! Also for the life of your ESCO Torque Master I Series Torque Wrench air supply should be clean and free of particles, water and other remains.
- Page 8 Tightening and Loosening of Bolts or Nuts WARNING o Beware of non-fixed freely rotating Reaction Arms or of rotating Impact Sockets o Loose clothes, long hair, cables, etc. are always to be kept away from danger/rotation area. When the machine is put into operation wearing ear protection, safety shoes and safety goggles is mandatory. o Never leave a running Torque Master I Series Torque Wrench unattended and always be ready to switch off the machine if necessary.
- Page 9 Then reset for next settings on F/R/L unit by adjusting Regulating Knob as described earlier. Your personnel can be trained by your ESCO Representative or Distributor on use of this product if so desired. Changing Accessories on the Torque Master I Series Torque Wrench Remove Torque Master I Series from work and back off the regulator knob to decrease the pressure to zero while depressing toggle switch.
