MANAGING PROGRAMS
To get to the Remote Control screen:
1. Click
from the Programming screen.
UNDERSTANDING THE PROGRAM SLOTS
The program currently running on the Stimulator is displayed on the left panel.
On the right side of the screen, the four program slots are displayed.
Currently Active
Remote Control
Program Slot
Program Slot
SAVING A PROGRAM
The currently active program can be saved to one of the four program slots.
To save a program to the Stimulator:
"Edit"
1. Name the program by clicking
at the top of the left panel, typing a program name,
"check mark."
and selecting the
2. Click a program slot on the right of the screen to which you want to save the program. You can select
a blank slot to save a program to, or you can select a slot that already has a program to overwrite it.
3. Click
.
The currently active program will be saved to the selected program slot.
NOTE: the
symbol in the Remote Control panel indicates last activated or saved program.
4. Click
to end programming session.
Boston Scientific
Boston Scientific (Australia) Pty Ltd
Boston Scientific Limited
Neuromodulation Corporation
PO Box 332
Ballybrit Business Park
25155 Rye Canyon Loop
BOTANY
Galway, Ireland
Valencia, CA 91355 USA
NSW 1455
T: +33 (0) 1 39 30 97 00
(866) 789-5899 in US and Canada
Australia
F: +33 (0) 1 39 30 97 99
(661) 949-4000, (661) 949-4022 Fax
Free Phone 1800 676 133
(866) 789-6364 TTY
Free Fax 1800 836 666
www.bostonscientific.com
Email: neuro.info@bsci.com
92290361-01 10 of 10 2018-10
VERCISE DBS
PROGRAMMING
QUICK START GUIDE
92290361-01
Content: 92290376 REV A
CAUTION: Federal law restricts this device to sale, distribution and use by or on the order of a physician.
