Adcom GTP-506 Service Manual page 8

PARTS LIST
REF NO.
HOUSING WIRE
J602A
SWITCH
M502
KEY BOARD ASSEMBLY
*US
*CE
MATEL MATERIAL
1101
PCB BOARD
1102
FIBRE WASHER
1103
CAPACITORS
C601-C604
c605
C606
C607
C608
c609
C613
C614
DIODE
D601
D619
LEDS
D602-D609
D611,D612
D614,D615
D616-D618
WAFERS
J601A
J602
J609
M627
COIL
L602
SWITCHES
M601
M603-M618
M620-M624
M628
M629-M632
LCD DISPLAY
M626
IR SENSOR
M627
TRANSISTORS
Q601-Q611
Q612
Q613-Q617
VOLUME
R245
DESCRIPTION
CONN.ASSY 2P P2.5 L60 AWG26
SWITCH, PUSH 2P2T UNLOCK SPPJ2-EN-PLB
KEY BOARD ASSEMBLY
KEY BOARD ASSEMBLY
HOLDER LED
PCB KEYBOARD/RM1/TUNER/MISC
WSER FIBRA 1103A D3.3
CC 50V 470pF 5% 0805 1.2 X2.0
CE 50V 10µF 20% RL 4x7
CC 50V 0.1µF 20% 0805 1.2X2.0
CTC 0/30 22pF 5% 0805 1.2X2.5
CE 6.3V 47µF 20% RL 4x7
CE 50V 10µF 20% RL 4x7
CC 50V 0.1µF 20% 0805 1.
CC 50V 470pF 5% 0805 1.2
RLS-73 DIODE
DZ 1/2W 5.0-5.2V AT
LED SP 3X5.5 L0.5 RD
LED SP 3X5.5 L0.5 RD
LED SP 3X5.5 L0.5 RD
LED RT 5X2X7MM RED
FLEXIBLE CONN. 35P P1.25 TOP ENTRY
2P ST.WAFER P=2.5 COULOMB
6P ST. WAFER P=2.5 COULOMB
6 PIN HEADER SINGLE ROW 82731-6 AMP
IND FXD LAL03A 220U PM10
SWITCH, TACT SKHHBY 7MM HIGH
SWITCH, TACT SKHHBY 7MM HIGH
SWITCH, TACT SKHHBY 7MM HIGH
SWITCH, TACT SKHHBY 7MM HIGH
TACT SWITCH (RIGHT ANGLE)
VFD BJ740GNK FUTABA (GPT506)
IR SENSOR PIC-26043TM2 KODENSHI
TR KTC3875Y
TR KTA1504Y
TR KTC3875Y
VR (BALANCE)
8
GTP-506
PART NO.
7702-1060-2004
5200-3539-0
PCB-A0190C-KEY
PCB-A0191C-KEY
4132-6601-0
1724-670A-0002
2848-0032-0
150F-471J-J-BD
157F-106M-5-GM
150F-104M-J-BD
15CG-220J-J-BD
157B-476M-5-GM
157F-106M-5-GM
150F-104M-J-BD
150F-471J-J-BD
4840-1080-3
4837-4C20-2
3700-2380-R
3700-2380-R
3700-2380-R
3700-5577-R
2101-1591-0
2102-021S-004
2102-061S-004
2101-2350-0
1801-221K-M
5200-3538-0
5200-3538-0
5200-3538-0
5200-3538-0
5200-4721-0
2460-1910-0
4816-043T-3
4853-875Y-3
4851-504Y-3
4853-875Y-3
4750-9665-0
