Adcom GTP-506 Service Manual page 15

PARTS LIST
REF NO.
C981
C982
C991
DIODES
D901,D902
D980
SHIELD WIRE
FM-ANT
SOCKET/WAFER
J704B
METAL MATERIALS
J902-1
J903
J904
COILS
L901
L903
L904
L941
L942
L971
L972
TRANSFORMER
L905
TUNER
M901
CERAMIC FILTERS
M902
M903
M904
M911
CRYSTAL
M905
TERMINAL/WAFER
M912
P901
TRANSISTORS
Q901
Q902
Q903
Q922,Q923
Q943,Q944
Q945
Q980
Q981
Q982
RESISTORS
R901
R902
R903
R904
R905
R906
R907
R908
R909,R910
DESCRIPTION
CC 50V 0.022µF 10% 0805
CTC 0/30 100pF 5% 0805 1.2X2.5
CC 50V 1000pF 10% 0805 1.2X2.0
DZ 1/2W 5.0-5.2V AT
DIODE 1N4148 ATS
SHIELD WIRE RG174/U UL1354 45MM
SOCKET (PCB/PCB) 16P P2.0 RA
ANTENNA WASHER
ANTENNA WASHER
ANTENNA WASHER
COIL 22µH 10% AL BL7
COIL MPX LPF NMC-4085
COIL MPX LPF NMC-4085
COIL FM DET-1 10.7MHZ NFIF-4081
COIL FM DET-2 10.7MHZ NFIF-4082
COIL MW RF BLOCK NMRF-5077
COIL AM IFT NMIF-4062
BALUN TRANSFORMER 300 TO 75 OHM
TUNER ENV172D3G1 PANASONIC
CF10.7 +-30 SFE10.7MA5-A
CF10.7 +-30 SFE10.7MA5-A
CF10.7 +-30 SFE10.7MA5-A
CF 450 +-1 SFZ450JL3 MURATA
CRYSTAL 7.2MHZ 20PPM
4P TERMINAL FM/AM ANTENNA
WAFER 2P ST. P=2.5 NH (JST)
TR 2SC945P HFE 200-400
TR 2SC1923-0 HFE 70-140
TR DTA114ESA ROHM
TR 2SC1740S (R) HFE180-390
TR 2SD 1468 S
TR DTA114ESA ROHM
TR 2SC1740S
TR 2SA1015-Y HFE120-240
TR N-JEET 2SK-363BL
RMG 1/10W 33K 5% 0805
RMG 1/10W 22R 5% 0805
RMG 1/10W 12K 5% 0805
RMG 1/10W 330R 5% 0805
RMG 1/10W 680R 5% 0805
RMG 1/10W 10K 5% 0805
RMG 1/10W 3.3K 5% 0805
RMG 1/10W 470R 5% 0805
RMG 1/10W 330R 5% 0805
15
GTP-506
PART NO.
150F-223K-J-BD
15CG-101J-J-BD
150F-102K-J-BD
4837-4C20-2
4804-1480-C
8110-0457-1
2101-1601-0
4131-7701-0
4131-7701-0
4131-7701-0
1801-220K-M
5600-3386-S
5600-3386-S
5600-3396-S
5600-3406-S
5600-3280-G
5600-3416-S
1806-2201-0
1300-0726-0
2701-0010-1
2701-0010-1
2701-0010-1
2701-0680-0
2300-0440-0
2113-1667-0
2113-1160-0
485C-945P-5
4851-9230-5
485A-114E-5
4860-1590-5
4860-8120-0
485A-114E-5
4860-1590-5
4851-015Y-5
4853-63BL-5
4720-333J-J
4720-220J-J
4720-123J-J
4720-331J-J
4720-681J-J
4720-103J-J
4720-332J-J
4720-471J-J
4720-331J-J
