Adcom GTP-506 Service Manual page 7

PARTS LIST
REF NO.
RELAYS
M225,M226
TRANSISTORS
Q209
Q210
Q214,Q215
Q218,Q219
Q310,Q313,Q314
RESISTORS
R235,R236
R237,R238
r239
R240
R241,R242
R243,R244
R245,R246
R247,R248
R249,R250
R251,R252
R253-R256
R257,R258
R261-R264
R265-R268
R269,R270
R271,R271
R273,R274
R275,R276
R277-R279
R281,R282
r295,r296
R297
R298,R299,R322
R323
R365
R366,R367
R368
R451,R452
R455
R801-R816
R817-R832
R833-R848
R849-R864
R865,R866
R867,R868
R869,870
R871,R872
R873,R874
r875,r876
r877
R878
ICs
U202-U204
U206,U207
U307,U333
SWITCH ASSEMBLY
1800
PCB BOARD
1801
LED
D610
DESCRIPTION
RELAY V23105-A5303-A201 SIEMENS
TR KTC3875Y
TR KTA1504Y
TR 2SC2878 (A,B) RL
TR 2SD1012F/G HFE 160-560
TR FET J112
RMG 1/10W 1K 1% 0805
RMG 1/10W 56K 1% 0805
RMG 1/10W 10K 1% 0805
RMG 1/10W 7.5K 1% 0805
RMG 1/10W 15K 5% 0805
RMG 1/10W 2.2K 1% 0805
RMG 1/10W 0R 5% 0805
RMG 1/10W 1M 1% 0805
RMG 1/10W 3.9K 1% 0805
RMG 1/10W 4.7K 1% 0805
RMG 1/10W 7.5K 1% 0805
RMG 1/10W 1K 1% 0805
RMG 1/10W 6.8K 1% 0805
RMG 1/10W 1K 1% 0805
RMG 1/10W 6.8K 1% 0805
RMG 1/10W 100R 1% 0805
RMG 1/10W 220K 1% 0805
RMG 1/10W 10K 5% 0805
RMG 1/10W 0R 5% 0805
RMG 1/10W 10K 5% 0805
RMG 1/10W 470R 5% 0805
RMG 1/10W 10K 5% 0805
RMG 1/10W 100K 5% 0805
RMG 1/10W 10M 5% 0805
RMG 1/10W 10K 5% 0805
RMG 1/10W 100R 1% 0805
RMG 1/10W 10K 5% 0805
RMG 1/10W 2.2K 5% 0805
RCF 1/4W 150R 5% AT
RMG 1/10W 1.2K 1% 0805
RMG 1/10W 3.3K 1% 0805
RMG 1/10W 1.2K 1% 0805
RMG 1/10W 3.3K 1% 0805
RMG 1/10W 1.2K 1% 0805
RMG 1/10W 3.3K 1% 0805
RMG 1/10W 1.2K 1% 0805
RMG 1/10W 3.3K 1% 0805
RMG 1/10W 100R 1% 0805
RMG 1/10W 22K 1% 0805
RMG 1/10W 10K 1% 0805
RMG 1/10W 7.5K 1% 0805
IC 7AA HIGH SPEED OP AMP
IC TC9273F-004 ANALOGUE SWITCH (FLAT-PACK)
IC TC9273F-004 ANALOGUE SWITCH (FLAT-PACK)
SWITCH ASSEMBLY
PCB KEYBOARD/RM1/TUNER/MISC
LED DUAL COLORS
7
GTP-506
PART NO.
4500-0920-0
4853-875Y-3
4851-504Y-3
4860-0770-5
4851-012F-5
4860-8770-0
4720-102A-J
4720-563A-J
4720-103A-J
4720-752A-J
4720-153J-J
4720-222A-J
4720-000J-J
4720-105A-J
4720-392A-J
4720-472A-J
4720-752A-J
4720-102A-J
4720-682A-J
4720-102A-J
4720-682A-J
4720-101A-J
4720-224A-J
4720-103J-J
4720-000J-J
4720-103J-J
4720-471J-J
4720-103J-J
4720-104J-J
4720-106J-J
4720-103J-J
4720-101A-J
4720-103J-J
4720-222J-J
4705-151J-2
4720-122A-J
4720-332A-J
4720-122A-J
4720-332A-J
4720-122A-J
4720-332A-J
4720-122A-J
4720-332A-J
4720-101A-J
4720-223A-J
4720-103A-J
4720-752A-J
3130-7430-0
3131-6790-0
3131-6790-0
PCB-A0190C-SW
1724-670A-0002
3700-2500-RG
