Adcom GTP-506 Service Manual page 13

PARTS LIST
REF NO.
R509,R510
R511
R512
R514,R515
R516
R517
R518
R519
R520
R522
R523
R531
R532
R533
R562,R563
R564-R566
R656
R657
R660-R662
R683,R684
R685
R701-R706
R707-R712
R765
R766-R768
R800
R801
R802
R803,R804
R805
R877
R878-R902
R906
R908-R910
R913-R920
R922-R924
R925,R926
R927,R928
R931 *US
ICs
U1001
U101
U102
U103
U105
U106
U107
U109
U110
U114
U116
U201
U501-U503
U504
U602
U603,U604
U606
CRYSTAL
X101
POWER SWITCH ASSEMBLY
1600
SWITCH
1601
DESCRIPTION
RMG 1/10W 1K 5% 0805
RMG 1/10W 4.7K 5% 0805
RMG 1/10W 1.5K 5% 0805
RMG 1/10W 1K 5% 0805
RCF 1/4W 4.7R 5% RL
RMG 1/10W 180K 5% 0805
RMG 1/10W 22K 5% 0805
RMG 1/10W 4.7K 5% 0805
RMG 1/10W 1.5K 5% 0805
RMG 1/10W 4.7K 5% 0805
RMG 1/10W 1.5K 5% 0805
RCF 1/4W 4.7R 5% RL
RMG 1/10W 180K 5% 0805
RMG 1/10W 22K 5% 0805
RMG 1/10W 10K 5% 0805
RMG 1/10W 100K 5% 0805
RMG 1/10W 1M 5% 0805
RMG 1/10W 100K 5% 0805
RMG 1/10W 1K 5% 0805
RMG 1/10W 0R 5% 0805
RMG 1/10W 100K 5% 0805
RCF 1/4W 150R 5% AT
RMG 1/10W 10K 5% 0805
RMG 1/10W 10K 5% 0805
RMG 1/10W 100K 5% 0805
RCF 1/8W 1K 5% ATS
RCF 1/8W 10K 5% ATS
RCF 1/8W 2.2K 5% ATS
RCF 1/8W 3.3K 5% ATS
RCF 1/8W 100K 5% ATS
RCF 1/4W 150R 5% AT
RMG 1/10W 10K 5% 0805
RMG 1/10W 10K 5% 0805
RMG 1/10W 10K 5% 0805
RMG 1/10W 10K 5% 0805
RMG 1/10W 100K 5% 0805
RMG 1/10W 10K 5% 0805
RMG 1/10W 100K 5% 0805
RMF 1/2W 120R 5% AT
IC NJM78L05A 826
IC 7815 FA REGULATOR
IC LM7915CT REGULATOR
IC NJM78L05A 826
IC 7815 FA REGULATOR
IC LM7915CT REGULATOR
IC NJM78L05A 826
IC 7815 FA REGULATOR
IC LM7915CT REGULATOR
IC NJM78M56FA 5.6V REGULATOR
IC LB1642 MOTOR DRIVER SANYO
IC NJM4558M OP AMP
IC KA2184D REMOTE CONTROL PREAMP
IC LM2901N DIP QUAD COMPARATOR SGS
IC UPD78P058 8-BIT MCU OTP
IC 4094 8-BIT SIPO SR 3S
IC EEPROM 24C02 2KBIT 8PIN DIP
X'TAL 5.0MHZ +/-20PPM HC49U
POWER SWITCH ASSEMBLY
POWER SWITCH
13
GTP-506
PART NO.
4720-102J-J
4720-472J-J
4720-152J-J
4720-102J-J
4705-4R7J-5
4720-184J-J
4720-223J-J
4720-472J-J
4720-152J-J
4720-472J-J
4720-152J-J
4705-4R7J-5
4720-184J-J
4720-223J-J
4720-103J-J
4720-104J-J
4720-105J-J
4720-104J-J
4720-102J-J
4720-000J-J
4720-104J-J
4705-151J-2
4720-103J-J
4720-103J-J
4720-104J-J
4701-102J-C
4701-103J-C
4701-222J-C
4701-332J-C
4701-104J-C
4705-151J-2
4720-103J-J
4720-103J-J
4720-103J-J
4720-103J-J
4720-104J-J
4720-103J-J
4720-104J-J
4717-121J-Z-P
3130-0640-0
3130-3030-1
3130-3020-0
3130-0640-0
3130-3030-1
3130-3020-0
3130-0640-0
3130-3030-1
3130-3020-0
3130-8190-0
3130-3410-0
3130-6060-0
3130-8990-0
3130-7160-0
3131-9130-0
3130-3600-0
3131-3920-0
2300-3100-0
PCB-A0191C-PSW
5200-3151-0-01
