- Page 1 ™ Marimba One Izzy OWNER’S MANUAL combination wood and aluminum rails www.marimbaone.com tel 707 822 9570 fax 707 822 6256 901 O St, Suite D Arcata, CA 95521...
- Page 2 ASSEMBLY INSTRUCTIONS & OWNER'S MANUAL • FOR ASSEMBLY, A large open space with carpet (or a blanket to cover the floor) • YOU WILL NEED: An assistant to help assemble the heavy items 1 ͏ � CAREFULLY UNPACK YOUR CRATE Compare the components to this page.
- Page 3 2 ͏ � ARRANGE FRAME COMPONENTS In a large open space with carpeting (or a blanket), arrange the frame components. Treble End Girders Bass End Joiner-Tube 3 ͏ � girder end SEAT GIRDER ENDS ONTO HOOKS girder knob Have your assistant hold the bass end-frame upright while you hold the girder.
- Page 4 6 ͏ � LOOSEN JOINER-TUBE LEVERS Flip levers to the open position. 7 ͏ � CONNECT GIRDERS Slide the joiner-tube over the girder tubes until the joiner-tube can go no further. girder tube girder tube You should be able to hear (or feel) when the two girder tubes touch inside the joiner-tube.
- Page 5 11 ͏ � INSTALL RAIL #2 Position yourself with the bass end on Lower rail #2 into the Make sure the rail is fully your left and treble end on your right. slots on the frames. engaged onto the flexible pins inside the slots.
- Page 6 15 ͏ � INSTALL NATURAL RESONATOR BANK Bass End With your assistant, carefully Treble End lift the natural resonator bank upright. With each person holding the ends of the resonator bank, lower the bank into the frame, in front of the girders. ...
- Page 7 19 ͏ � INSTALL RAIL #3 NOTE: Bass end of the rail has larger gaps between the jacks than the treble end of the rail.. Lower rail into the #3 slots on the frame ends and into the sway block slot.
- Page 8 21 ͏ � POSITION BARS ON RAILS treble end close-up treble end close-up Move each bar into its correct position, making sure that the cord rail jacks rests in the Jacks between each bar. Wrap the bar cord around the Corner jacks at the treble end.
- Page 9 bar cord tension Over time, as you play your instrument, the cord that suspends the bars may loosen and need to be adjusted. To increase tension in the bar cord, use the cleats behind the springs to hold the slack in the cord. ...
-
Page 10: Height Adjustment
height adjustment CAUTIONS! To prevent damage, always adjust the height of the marimba with all rails, resonators and bars INSTALLED. DO NOT RELEASE LEVERS AT THE SAME TIME. 1 ͏ � RELEASE LEVERS ONE AT A TIME. ... - Page 11 height adjustment warnings • Always adjust the height of the marimba with rails, resonators and bars installed. • Release the levers one end at a time. • Always keep marimba ends at equal heights. • Do not release the end levers at the same time. marimba cleaning USE A SOFT COTTON RAG OR TOWEL DAMPENED WITH WATER ONLY.
-
Page 12: Bar Chart
Remember: your bars are under warranty for the first year and we’ll replace them at no cost (shipping not included). Beyond the first year, contact us for bar replacement pricing. Shipping Address Marimba One 901 “O” St Suite D Arcata CA 95521 Email percussion@marimbaone.com Telephone 707.822.9570...
