Heath Zenith InTune MP3 Door Chime Quick Start Manual

MP3 Door Chime
Quick Start Guide

To prevent possible SERIOUS INJURY or DEATH:

• NEVER allow small children near batteries.
• If battery is swallowed, immediately notify doctor.
This Quick Start is intended to highlight a typical situation.
These instructions are not intended to be comprehensive.
Please read the PDF version of the complete owner's manual
(located on the door chime drive) for further information.

Parts List

The illustrations may vary from the actual product.
Jumpers
Anchors
Screw 6x1"
(for door chime)
Door Chime
Mounting Plate
Screw 4x3/4"
(for push button)
Double-Sided Tape
Push Button (alternate mounting option
for push button)
USB Cable
Cover
205372-03 1-800-858-8501
www.heath-zenith.com
© 2013 HeathCo LLC

(A) INSTALL THE DOOR CHIME

1
Press tabs to release
3
from mounting plate.

(C) TEST

2
C Batteries
(not provided)
4

(D) ADD TUNES

1. Connect the USB cable from the door
chime to the computer.
2. Click "Open Folder to View Files."
3. Drag the desired tune to the door chime drive.
4. Disconnect the door chime from computer.
5. Remove the USB cable.
Cycle through the tunes using the tune button.
Cycle through the volume levels using the volume
button. NOTE: Suggested tune length is 2-15 seconds.
Maximum tune length is 20 seconds. If tune is longer
than 20 seconds, only the first 20 seconds will play.
Refer to owner's manual for help with editing song length.

(B) INSTALL THE PUSH BUTTON

1
Remove Orange Tab
2
Battery (provided)
3
Volume
Button
Tune Button
