- Page 1 GW Installation manual Standard Winch Rack drive HB series HC series GW10 GW10L GW10TGA GW40HB GW40HC GW20 GW30L GW20TGA GW80HB GW80HC GW30 GW40L GW100HB GW125HC GW40 GW150HC GW60 GW80 GW100 GW110S GW150S P.INS.GW.01.EN Version 1 – 2015 / 09 / 06...
-
Page 2: Declaration Of Incorporation
Authorised compiler of the technical documents: Rob Sandberg Director General of De Gier B.V. Wateringen, 14-10-2014 De Gier B.V., Westlandseweg 9, 2291 PG WATERINGEN, THE NETHERLANDS, Tel. +31 (0)174 292089, Fax +31 (0)174 295644, E-mail: sales@degier.nl www.degier.eu Version 1 – 2014 / 06 / 11... -
Page 3: Table Of Contents
+31 174 - 29 20 89 Or by e-mail: sales@degier.nl De Gier Drive Systems De Gier B.V., Westlandseweg 9, 2291 PG WATERINGEN, THE NETHERLANDS, Tel. +31 (0)174 292089, Fax +31 (0)174 295644, E-mail: sales@degier.nl www.degier.eu Version 1 – 2014 / 06 / 11... -
Page 4: Dimensions
INSTALLATION MANUAL Dimensions GW10 GW20 - GW30 GW40 - GW150 De Gier B.V., Westlandseweg 9, 2291 PG WATERINGEN, THE NETHERLANDS, Tel. +31 (0)174 292089, Fax +31 (0)174 295644, E-mail: sales@degier.nl www.degier.eu Version 1 – 2014 / 06 / 11... -
Page 5: Technical Specifications
*1) Depending on version, K = chain coupling, L = Winch, T = Rack drive *2) Ask for the possibilities of both 60 Hz electric motors and dual voltage electric motors De Gier B.V., Westlandseweg 9, 2291 PG WATERINGEN, THE NETHERLANDS, Tel. +31 (0)174 292089, Fax +31 (0)174 295644, E-mail: sales@degier.nl www.degier.eu... -
Page 6: Explanation Of Symbols And Safety Instructions
Fit the red vent plug Electrically live parts PE connection point (earth) Read the documentation De Gier B.V., Westlandseweg 9, 2291 PG WATERINGEN, THE NETHERLANDS, Tel. +31 (0)174 292089, Fax +31 (0)174 295644, E-mail: sales@degier.nl www.degier.eu Version 1 – 2014 / 06 / 11... - Page 7 (for instance, installers recommended by De Gier). Approval by the safety officer for the overall plant or system is always required before work may be carried out. De Gier B.V., Westlandseweg 9, 2291 PG WATERINGEN, THE NETHERLANDS, Tel. +31 (0)174 292089, Fax +31 (0)174 295644, E-mail: sales@degier.nl www.degier.eu...
-
Page 8: Product Name
Hoisting applications: for example, growing tube or chrysanthemum (hoisting) heating. Only permitted with fall-arrest brake protection. De Gier B.V., Westlandseweg 9, 2291 PG WATERINGEN, THE NETHERLANDS, Tel. +31 (0)174 292089, Fax +31 (0)174 295644, E-mail: sales@degier.nl www.degier.eu Version 1 – 2014 / 06 / 11... - Page 9 If you wish to store the motor gearboxes for a lengthy period of time, you can use preservatives to protect the unpainted surfaces, such as threaded holes and mounting surfaces for chain couplings, against corrosion. De Gier B.V., Westlandseweg 9, 2291 PG WATERINGEN, THE NETHERLANDS, Tel. +31 (0)174 292089, Fax +31 (0)174 295644, E-mail: sales@degier.nl www.degier.eu...
-
Page 10: Installation
12B Z16 (3/4” x 7/16”) 3° 12B Z18 (3/4” x 7/16”) 3° De Gier B.V., Westlandseweg 9, 2291 PG WATERINGEN, THE NETHERLANDS, Tel. +31 (0)174 292089, Fax +31 (0)174 295644, E-mail: sales@degier.nl www.degier.eu Version 1 – 2014 / 06 / 11... - Page 11 De Gier can supply chain couplings which can be used to compensate for limited alignment errors. Different types can be combined with each other. De Gier B.V., Westlandseweg 9, 2291 PG WATERINGEN, THE NETHERLANDS, Tel. +31 (0)174 292089, Fax +31 (0)174 295644, E-mail: sales@degier.nl www.degier.eu...
- Page 12 To avoid mistakes in the future, mark the switches to indicate which one limits the start position and which one limits the end position. De Gier B.V., Westlandseweg 9, 2291 PG WATERINGEN, THE NETHERLANDS, Tel. +31 (0)174 292089, Fax +31 (0)174 295644, E-mail: sales@degier.nl www.degier.eu...
- Page 13 Driving the motor gearbox using a hex bit Adjusting the limit switch De Gier B.V., Westlandseweg 9, 2291 PG WATERINGEN, THE NETHERLANDS, Tel. +31 (0)174 292089, Fax +31 (0)174 295644, E-mail: sales@degier.nl www.degier.eu Version 1 – 2014 / 06 / 11...
- Page 14 More information about fitting, connecting and adjusting the I-DE can be found in the specific manual for the I-DE. De Gier B.V., Westlandseweg 9, 2291 PG WATERINGEN, THE NETHERLANDS, Tel. +31 (0)174 292089, Fax +31 (0)174 295644, E-mail: sales@degier.nl www.degier.eu...
- Page 15 Bolt M5 x 8 Washer M5 Limit switch mechanism with potentiometer De Gier B.V., Westlandseweg 9, 2291 PG WATERINGEN, THE NETHERLANDS, Tel. +31 (0)174 292089, Fax +31 (0)174 295644, E-mail: sales@degier.nl www.degier.eu Version 1 – 2014 / 06 / 11...
-
Page 16: Electrical Connection And Commissioning
Make sure that the cables are clear of any moving parts. Terminal block for three-phase motor De Gier B.V., Westlandseweg 9, 2291 PG WATERINGEN, THE NETHERLANDS, Tel. +31 (0)174 292089, Fax +31 (0)174 295644, E-mail: sales@degier.nl www.degier.eu Version 1 – 2014 / 06 / 11... - Page 17 Re-fit the black plastic protective cover on the motor gearbox. Wiring diagram for working and emergency switches De Gier B.V., Westlandseweg 9, 2291 PG WATERINGEN, THE NETHERLANDS, Tel. +31 (0)174 292089, Fax +31 (0)174 295644, E-mail: sales@degier.nl www.degier.eu Version 1 – 2014 / 06 / 11...
-
Page 18: Use
Check the wiring of the motor and the limit and emergency switch mechanism • Check the play of the output shaft De Gier B.V., Westlandseweg 9, 2291 PG WATERINGEN, THE NETHERLANDS, Tel. +31 (0)174 292089, Fax +31 (0)174 295644, E-mail: sales@degier.nl www.degier.eu Version 1 – 2014 / 06 / 11... -
Page 19: Dismounting
Replace the vent plug with an M12 sealing plug; Dismount the motor gearbox unit from the system. De Gier B.V., Westlandseweg 9, 2291 PG WATERINGEN, THE NETHERLANDS, Tel. +31 (0)174 292089, Fax +31 (0)174 295644, E-mail: sales@degier.nl www.degier.eu Version 1 – 2014 / 06 / 11... -
Page 20: Troubleshooting
Check that all nuts on the terminal block are properly tightened; • Contact the installer if the fault persists. De Gier B.V., Westlandseweg 9, 2291 PG WATERINGEN, THE NETHERLANDS, Tel. +31 (0)174 292089, Fax +31 (0)174 295644, E-mail: sales@degier.nl www.degier.eu Version 1 – 2014 / 06 / 11... -
Page 21: Spare Parts And Parts Replacement
Blue-line range a 3 year warranty period is applicable. We reserve the right to make modifications. De Gier B.V., Westlandseweg 9, 2291 PG WATERINGEN, THE NETHERLANDS, Tel. +31 (0)174 292089, Fax +31 (0)174 295644, E-mail: sales@degier.nl www.degier.eu Version 1 – 2014 / 06 / 11... -
Page 22: Glossary
The gear unit can only be driven by the motor; the output shaft cannot be moved by the load. De Gier B.V., Westlandseweg 9, 2291 PG WATERINGEN, THE NETHERLANDS, Tel. +31 (0)174 292089, Fax +31 (0)174 295644, E-mail: sales@degier.nl www.degier.eu... -
Page 23: Wiring Diagram For 400 V Three-Phase Supply
INSTALLATION MANUAL Wiring diagram 400V 3~ supply Q1/1 De Gier B.V., Westlandseweg 9, 2291 PG WATERINGEN, THE NETHERLANDS, Tel. +31 (0)174 292089, Fax +31 (0)174 295644, E-mail: sales@degier.nl www.degier.eu Version 1 – 2014 / 06 / 11... -
Page 24: Wiring Diagram For 230 V Single-Phase Supply
INSTALLATION MANUAL Wiring diagram 230V 1~ supply Q1/1 De Gier B.V., Westlandseweg 9, 2291 PG WATERINGEN, THE NETHERLANDS, Tel. +31 (0)174 292089, Fax +31 (0)174 295644, E-mail: sales@degier.nl www.degier.eu Version 1 – 2014 / 06 / 11...
