- Page 1 OPERATING MANUAL ba64114e05 03/2018 P o w IQ S ENSOR MIQ/24V IQ S POWER SUPPLY MODULE (NOMINAL INPUT VOLTAGE 24 V AC/DC) ENSOR...
- Page 2 MIQ/24V © Copyright 2018 Xylem Analytics Germany GmbH Printed in Germany. ba64114d05 03/2018...
-
Page 3: Table Of Contents
General data ....... . . 15 MIQ/24V ........17... -
Page 4: Overview
Overview MIQ/24V Overview How to use this component operating manual Structure of the IQ Sensor Net Operating Manual IQ S ENSOR operating manual System Operating Manual (Ring Binder) Operating Operating Operating Manual Manual Manual IQ Sensor MIQ Module Option (e.g. Fieldbus) Components and Options Fig. -
Page 5: Features Of The Miq/24V
It also provides the same wide variety of installation options (stacked mounting, canopy mounting, tophat rail mounting, etc.). The number of MIQ/24V that are required depends on the number of consumers in the system and their power requirement as well as on the overall loss of power in the IQ S cables. -
Page 6: Safety Instructions
Safety instructions MIQ/24V Safety instructions Safety information 2.1.1 Safety information in the operating manual This operating manual provides important information on the safe operation of the product. Read this operating manual thoroughly and make yourself familiar with the product before putting it into operation or working with it. The operating manual must be kept in the vicinity of the product so you can always find the information you need. -
Page 7: Safe Operation
MIQ/24V Safety instructions Safe operation 2.2.1 Authorized use The authorized use of the MIQ/24V consists of its use as a power supply module in the IQ S . Only the operation according to the instructions and tech- ENSOR nical specifications given in this operating manual is authorized (see chapter 5 ). -
Page 8: Installation
Installation in the IQ S ENSOR The IQ S provides a number of options for integrating the MIQ/24V ENSOR mechanically and electrically in the system (stacked mounting, distributed mounting, etc.). The individual types of installation are described in detail in the chapter of the system operating manual. -
Page 9: Electrical Connections: General Instructions
All electric cables are fed from below via prepared openings in the enclosure of the MIQ/24V. Cable glands with different clamping ranges are included with the MIQ/24V to provide sealing between the cable and enclosure as well as for strain relief. Select the matching cable gland for the respective cable diameter: ... - Page 10 Installation MIQ/24V Large, clamping range 7 to 13 mm. This cable gland is required for cable sheaths with an outside diameter of more than 10 mm and is screwed into the enclosure via an extension piece. sealing ring 20 x 15 x 1 mm...
-
Page 11: Connecting The 24 V Ac/Dc Supply
MIQ/24V does not have an integrated protection against total discharge. Materials required Wire end sleeves, suitable for the power line, with suitable crimping tool 1 x cable gland with sealing ring (included in scope of delivery of MIQ/24V). Tools Cable stripping knife Wire stripper ... - Page 12 Installation MIQ/24V ca. 45 mm wire 1 wire 2 Fig. 3-1 Prepared 24 V AC/DC cable. Connecting the the Open the module. 24 V AC/DC line X11 X10 24 V AC/DC T 1,6 A POWER INPUT SENSORNET 3 SENSORNET 2 SENSORNET 1 Fig.
- Page 13 MIQ/24V Installation Feed the 4 V AC/DC line through the cable gland into the module housing. Connect the wires 1 and 2 to the terminal strip. Make sure that the cable assignment agrees with the specification on the terminal label under the terminal strip.
-
Page 14: Maintenance And Cleaning
Maintenance and cleaning MIQ/24V Maintenance and cleaning Maintenance The MIQ/24V requires no special maintenance. The general maintenance of IQ S components is described in the IQ S system ENSOR ENSOR operating manual. Cleaning The cleaning of IQ S components is described in the IQ S... -
Page 15: Technical Data
MIQ/24V Technical data Technical data General data Dimensions 144.0 52.2 Front view: Side view: 115.0 11.0 70.0 16.5 Rear view: Stack mounting: Fig. 5-1 Dimension drawing of MIQ module (dimensions in mm) Mechanical Maximum number of structure MIQ modules in a mod-... - Page 16 Technical data MIQ/24V Weight Approx. 0.5 kg Type of protection IP 66 (not suitable for conduit connection). Cable glands Suitable for cable 4.5 - 10 mm or sheath diameter 9.0 - 13 mm Ambient Temperature conditions Mounting/installation/ + 5 °C ... + 40 °C (+ 41 ... +104 °F)
-
Page 17: Miq/24V
MIQ/24V Technical data MIQ/24V Electrical data Power supply Nominal voltage: 24 V AC/DC - 15 % / + 20 % Safety Extra Low Voltage (SELV) AC Frequency: 50/60 Hz in accordance with IEC 60038 Connection: 2-pole Line cross-section of connection: Europe: 1.5 ... - Page 18 Technical data MIQ/24V Terminal IQ S con- ENSOR connections nections Additional connectable SENSORNET terminator (terminating resistor) Terminal type Screw-type terminal strip, accessible by raising the Terminal ranges Solid wires: 0.2 ... 4.0 mm AWG 24 ... 12 Flexible wires: 0.2 ... 2.5 mm...
- Page 20 For more information on how Xylem can help you, go to xyleminc.com. ® Service address: Xylem Analytics Germany Sales GmbH & Co. KG Dr.-Karl-Slevogt-Str. 1 82362 Weilheim Germany Tel.: +49 881 183-325 Fax: +49 881 183-414 E-Mail wtw.rma@xyleminc.com Internet: www.WTW.com Xylem Analytics Germany GmbH Dr.-Karl-Slevogt-Str. 1 82362 Weilheim Germany...
