- Page 1 OPERATING MANUAL ba75539e03 03/2018 P o w IQ S ENSOR MIQ/CHV PLUS VALVE MODULE FOR COMPRESSED AIR-OPERATED SENSOR CLEANING HEADS...
- Page 2 MIQ/CHV PLUS © Copyright 2018 Xylem Analytics Germany GmbH Printed in Germany. ba75539d03 03/2018...
-
Page 3: Table Of Contents
General data ....... . . 19 MIQ/CHV PLUS ....... 21 Indexes . - Page 4 List of contents MIQ/CHV PLUS Accessories and options ......23 ba75539e03 03/2018...
-
Page 5: Overview
MIQ/CHV PLUS Overview Overview How to use this component operating manual Structure of the IQ Sensor Net Operating Manual IQ S ENSOR operating manual System Operating Manual (Ring Binder) Operating Operating Operating Manual Manual Manual IQ Sensor MIQ Module Option (e.g. -
Page 6: General Characteristics
Overview MIQ/CHV PLUS General characteristics The MIQ/CHV PLUS valve module provides a switchable compressed air valve for the operation of sensor cleaning heads. The MIQ/CHV PLUS valve module registers on the IQ S system as ENSOR an output (V). It appears in the list of outputs and can be linked with a sensor. - Page 7 When used in the IQ S , the valve module is supplied with voltage by ENSOR the IQ S ENSOR IQ S The MIQ/CHV PLUS can be fully integrated in the IQ S using the ENSOR ENSOR compatibility MIQ standard module housing.
-
Page 8: Safety Instructions
Safety instructions MIQ/CHV PLUS Safety instructions Safety information 2.1.1 Safety information in the operating manual This operating manual provides important information on the safe operation of the product. Read this operating manual thoroughly and make yourself familiar with the product before putting it into operation or working with it. The operating manual must be kept in the vicinity of the product so you can always find the information you need. -
Page 9: Safe Operation
MIQ/CHV PLUS Safety instructions Safe operation 2.2.1 Authorized use The authorized use of the MIQ/CHV PLUS consists of providing a control valve for compressed air-operated sensor cleaning heads in the IQ S . Only ENSOR the operation according to the instructions and technical specifications given in this operating manual is authorized (see chapter 7 T ). -
Page 10: Installation
Installation MIQ/CHV PLUS Installation Scope of delivery The following parts are included in the scope of delivery of the MIQ/CHV PLUS: MIQ/CHV PLUS Accessory set, including: – 2 x screwed cable glands with seals and blind plugs – 2 x ISO blind nuts M4 –... - Page 11 MIQ/CHV PLUS Installation Small, clamping range 4.5 to 10 mm. This cable gland is suitable for all IQ S sensor cables. ENSOR sealing ring 20 x 15 x 1 mm cable gland M16 blind plug Large, clamping range 7 to 13 mm. This cable gland is required for cable sheaths with an outside diameter of more than 10 mm and is screwed into the enclosure via an extension piece.
-
Page 12: Connecting The Valve Control Line
Materials required Wire end sleeves, suitable for the connecting wires, with suitable crimping tool 1 x cable gland with sealing ring (scope of delivery MIQ/CHV PLUS) Tools Cable stripping knife Wire stripper ... - Page 13 MIQ/CHV PLUS Installation Connecting the Open the module. control line to the terminal strip Valve SENSORNET 2 SENSORNET 1 Valve Fig. 3-1 Clamping termination for the valve control line Screw the cable gland (pos. 1 in Fig. 3-1) with the sealing ring (pos. 2) into the left connection opening.
-
Page 14: Connecting The Compressed Air Hoses
Danger of injury from lines that are under pressure. Before opening the compressed air line, ensure that the section of line concerned is free of pressure. The compressed air glands in the housing may only be opened by a service technician authorized by WTW. ba75539d03 03/2018... -
Page 15: Function Check
The compressed air glands in the housing may only be opened by a service technician authorized by WTW. MIQ/CHV PLUS + IQ S ENSOR Put the IQ S system into operation. -
Page 16: Settings
Settings MIQ/CHV PLUS Settings The MIQ/CHV PLUS module has a valve output. The MIQ/CHV PLUS valve module registers on the IQ S system as ENSOR a valve output (V) and appears in the list of outputs. On an IQ S... -
Page 17: Maintenance And Cleaning
MIQ/CHV PLUS Maintenance and cleaning Maintenance and cleaning Maintenance The MIQ/CHV PLUS requires no special maintenance. Cleaning The cleaning of IQ S components is described in the IQ S ENSOR ENSOR system operating manual. ba75539d03 03/2018... -
Page 18: What To Do If
What to do if ... MIQ/CHV PLUS What to do if ... No compressed air Cause Remedy at the output – Compressed air supply inter- – Check the compressed air supply rupted or too weak – Supply voltage not present or... -
Page 19: Technical Data
115.0 Rear view: 11.0 70.0 16.5 137.0 Stack mounting: Fig. 7-1 Dimension drawing of the MIQ/CHV PLUS (dimensions in mm) Mechanical Maximum number of construction modules in a module (plus a terminal component in the IQ S ENSOR stack Materials –... - Page 20 Technical data MIQ/CHV PLUS Weight Approx. 0.5 kg Type of protection IP 66 (not suitable for conduit connection) Ambient Temperature conditions Operation 0 °C ... + 55 °C (32 ... 131 °F) Storage - 25 °C ... + 65 °C (-13 ... 149 °F) Relative humidity ≤...
-
Page 21: Miq/Chv Plus
MIQ/CHV PLUS Technical data MIQ/CHV PLUS Electrical data Nominal voltage Max. 24 VDC via a separate power supply module. IQ S ENSOR For details, see chapter T of the ECHNICAL DATA IQ S system operating manual ENSOR Suitable power supply modules: –... -
Page 22: Indexes
* Check installation and cable lengths, Follow installation instructions * Power unit(s) overloaded, add power unit(s) * Defective components, replace components * Defective components, replace components 8.1.2 Informative messages The MIQ/CHV PLUS output module does not send any informative messages. ba75539d03 03/2018... - Page 23 MIQ/CHV PLUS Accessories and options Accessories and options Description Model Order no. Cleaning head for online sensors with 40 mm 900 107 diameter Tubing set, comprising: CH/Epack 900 111 – 15 m compressed-air hose – 1 quick disconnect coupler, complete –...
- Page 24 Accessories and options MIQ/CHV PLUS ba75539d03 03/2018...
- Page 26 For more information on how Xylem can help you, go to xyleminc.com. ® Service address: Xylem Analytics Germany Sales GmbH & Co. KG Dr.-Karl-Slevogt-Str. 1 82362 Weilheim Germany Tel.: +49 881 183-325 Fax: +49 881 183-414 E-Mail wtw.rma@xyleminc.com Internet: www.WTW.com Xylem Analytics Germany GmbH Dr.-Karl-Slevogt-Str. 1 82362 Weilheim Germany...
