4.2.1

TX CBIT Events

Code Message
0101 INACTIVE WARNING
0102 NOGO ERROR
6125.0226.12.01
The following table lists all possible CBIT events.
Note: In most cases of error, the transmitter will need to be transferred to
the nearest service.
Column
Code Code is the unique number for this kind of event.
Message Message is the designation of this event.
Level Level is a ranking of this event (W = warning; E = error).
Warnings and errors will be logged into CBIT status list.
Errors and NOGO warnings additionally cause NOGO
(LED GO not illuminated, error code 0102).
Config Config states the configurability of each event:
W = event can be configured as warning,
N = event can be configured to cause NOGO.
Notes Notes describes the reasons and if necessary the
reaction of the radio when the event occurs.
Action Action describes what the user can do to eliminate the
cause of the event.
Level Config
W W
E –
Description
Note
Radio was switched to
the inactive mode, e.g.
via the *OFF contact
on the rear panel or by
software command
(see chapter 6.3.1.5)
or locally on the radio
(see chapter 3.4.7.2).
Radio switches to
NOGO state.
The NOGO error is the
general fault in the
radio and corresponds
to the GO LED. At
least one error or one
NOGO warning exists.
4.4
Troubleshooting
Action
Check VOP LED (see
chapter 4.1.2).
Check hardware input
*OFF on connector
X5.7.
Check software settings.
Check NOGO
configuration via service
PC (see chapter 3.3).
Analyze the CBIT status
in detail in order to find
out what is actually the
fault.
