INSTALLATION AND OPERATING MANUAL
ZVG 2 EURO UL
LPGas Nozzle with 'EURO' Connector
Underwriters
Laboratory listed
Meets EN 13760 /
UN R 67 / ISO 19825
ELAFLEX PACIFIC PTY LTD · Unit 29 / 58 Box Road · Taren Point · NSW 2229 · Australia
Tel. +61 2 8058 9258 · info@elaflex.com.au · www.elaflex.com.au
Picture shows
optional Scuffguard
( Nozzle Talker ) EA 866
9 / 2018
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Elaflex ZVG 2 EURO UL
Summary of Contents for Elaflex ZVG 2 EURO UL
- Page 1 Meets EN 13760 / UN R 67 / ISO 19825 ELAFLEX PACIFIC PTY LTD · Unit 29 / 58 Box Road · Taren Point · NSW 2229 · Australia Tel. +61 2 8058 9258 · info@elaflex.com.au · www.elaflex.com.au 9 / 2018...
- Page 2 In case of doubt or question please contact your service contractor or the manufacturer. DESCRIPTION The ZVG 2 EURO UL nozzle is designed for the LPGas vehicle refueling. Unlike the previ- ously used LPGas nozzles with screw-on connectors, it is equipped with a 'EURO' coup- ling and optionally with an orange safe latching mechanism to increase user comfort as per UL 125.
-
Page 3: Installation
Please also refer to the safety codes NFPA 54 + 58 and NPGA 306. INSTALLATION The ZVG 2 EURO UL is delivered ready for use. Nozzles should only be installed and tested by competent personnel. Applicable laws, regulations and Codes of Practice have to be followed. - Page 4 OPERATING INSTRUCTIONS Please follow any additional or deviating operating instructions displayed at the dispenser. Switch off vehicle engine. Take nozzle from dispenser. Ensure that all coupling parts, Push nozzle firmly onto the seals and sealing surfaces of necessary activate the dispen- vehicle fill point.
-
Page 5: Maintenance
If the problem persits notify the station personnel or the service contractor. MAINTENANCE The ZVG 2 EURO UL nozzle is a mechanical device that may become inoperative due to wear, corrosion and ageing of components. Regular inspections and maintenance are essential for a safe operation. -
Page 6: Conditions Of Use
ELAFLEX PACIFIC PTY LTD accepts no liability for direct, indirect, incidental, special, or conse- quential damages resulting from failure to follow any warnings, instructions and procedures in this manual, or any other common sense procedures generally applicable to equipment of this type.
