Related Manuals for ORiNG RDS-3086
Summary of Contents for ORiNG RDS-3086
- Page 2 ORing warrants that all ORing products are free from defects in material and workmanship for a specified warranty period from the invoice date (5 years for most products). ORing will repair or replace products found by ORing to be defective within this warranty period, with shipment expenses apportioned by ORing and the distributor.
-
Page 3: Table Of Contents
RDS-3086/3166G User Manual Table of Content Getting Started ........................4 About the RDS-3086/3166G ................. 4 Software Features ....................4 Hardware Specifications ..................4 Hardware Overview ......................5 Back Panel ......................5 2.1.1 Ports and Connectors ..................5 Front Panel ......................5 2.2.1... - Page 4 RDS-3086/3166G User Manual ............................26 4.2.2 Serial Setting ....................28 4.2.2.1 Serial Configuration .................. 28 4.2.2.2 Port Profile ....................30 4.2.2.3 Service Mode.................... 30 4.2.3 System Tools ....................37 4.2.3.1 Login Setting..................... 37 4.2.3.2 Date & Time ....................37 4.2.3.3 Device Restart ..................38 4.2.3.4 Firmware Upgrade ..................
-
Page 5: Getting Started
Started 1.1 About the RDS-3086/3166G The RDS-3086/3166G is a RS-232/422/485-to-LAN device server with 8 or 16 serial ports and 6 Ethernet ports. Besides standard features such TCP/IP interface and versatile operation mode support (Virtual Com, Serial Tunnel, TCP Server, TCP Client, and UDP), the device can be managed using the Windows untility, DS-Tool, which allows you to configure multiple devices and set up the mappings of Virtual Com. -
Page 6: Hardware Overview
RDS-3086/3166G User Manual ardware Overview 2.1 Back Panel 2.1.1 Ports and Connectors The device provides the following ports on the back panel, including four RJ-45 Ethernet ports, two SFP ports, and sixteen RJ48 serial ports Port Description 4 x 10/100/1000Base-T(X) ports... -
Page 7: Led
RDS-3086/3166G User Manual 1. Link/Act LED for serial ports 4. Console port 2. Link/Act LED for Gigabit ports 5. Power indicator 3. Faulty relay LED 6. Reset button 2.2.1 LED Color Status Description Green Power module is on Port is running at 1000Mbps... -
Page 8: Hardware Installation
RDS-3086/3166G User Manual ardware Installation 3.1 Rack-mount Installation The device comes with two rack-mount kits to allow you to fasten the device to a rack in any environments. Rack-mount Kit Measurement (unit = mm) Follow the following steps to install the device to a rack. -
Page 9: Wiring
RDS-3086/3166G User Manual 3.2 Wiring WARNING Do not disconnect modules or wires unless power has been switched off or the area is known to be non-hazardous. The devices may only be connected to the supply voltage shown on the type plate. - Page 10 RDS-3086/3166G User Manual 1000BASE-T Cat. 5/Cat. 5e 100-ohm UTP UTP 100 m (328ft) RJ-45 With 10/100Base-T(X) cables, pins 1 and 2 are used for transmitting data, and pins 3 and 6 are used for receiving data. 10/100Base-T(X) RJ-45 Port Pin Assignments:...
-
Page 11: Sfp
RDS-3086/3166G User Manual 1000Base-T MDI/MDI-X Pin Assignments: Pin Number MDI port MDI-X port BI_DA+ BI_DB+ BI_DA- BI_DB- BI_DB+ BI_DA+ BI_DC+ BI_DD+ BI_DC- BI_DD- BI_DB- BI_DA- BI_DD+ BI_DC+ BI_DD- BI_DC- Note: “+” and “-” signs represent the polarity of the wires that make up each wire pair. -
Page 12: Console Port Pin Assignment
RDS-3086/3166G User Manual Pin # RS-232 RS-422 RS-485 (4 wire ) RS-485 (2 wire ) TXD - TXD - DATA- TXD + TXD + DATA+ RXD + RXD + RXD - RXD - RS 232 mod act as DTE 3.3.4 Console Port Pin Assignment The device provides a console port in RJ45 connector type for device management. -
Page 13: Management
RDS-3086/3166G User Manual anagement 4.1 DS-Tool The Windows utility DS-Tool is a powerful Windows utility for DS series. It supports device discovery, device configuration, group setup, group firmware update, and monitoring functions. The tool enables you to easily install and configure devices on the network. -
Page 14: Using Ds-Tool
RDS-3086/3166G User Manual Step 2: When installation completes successfully, click OK. Step 3: You can launch the tool right immediately by checking Launch DS-Tool Now or launch it later by checking Launch DS-Tool Later. 4.1.2 Using DS-Tool Explore device servers DS-Tool will broadcast to the network and search all available DS devices in the network automatically. -
Page 15: Configure Device Servers
RDS-3086/3166G User Manual 4.1.3 Configure Device Servers 4.1.3.1 General This page enables you to perform general configuration for the device, includes the device name, SNTP server, and auto IP report. ORing Industrial Networking Corp... -
Page 16: Networking
RDS-3086/3166G User Manual Label Description You can input the device name or related information in this field. By clicking Locate On, you can locate the serial server’s Device Name/Location position. If you want to set the time via a SNTP time server, check the... -
Page 17: Upgrade Firmware
4.1.3.3 Upgrade Firmware You can find up-to-date firmware from ORing’s website. To update firmware for the device, save the firmware file in your host PC, and then specify the file location by clicking on the Browsing button and continue operation by pressing Update. -
Page 18: Configure Serial Port
RDS-3086/3166G User Manual settings. If you want to load all factory default, you need to press Reset button on the device (Hardware restore). Click this button will reboot device and need to broadcast again Reboot Device in order to search the device (warm start). - Page 19 RDS-3086/3166G User Manual Label Description Port alias enables the device server to easily identify the serial Port Alias devices connected to it. Enter an identifying name to be identified by the connected device. Baud rate is the rate at which data is transferred over a serial link.
- Page 20 RDS-3086/3166G User Manual mark bits. Mark: the parity bit is always set to the mark signal condition (logical 1) Space: the last transmitted data bit will always be a logical 0 Choose the number of data bits to transmit. You can configure data bits to be 5, 6, 7, or 8.
-
Page 21: Service Mode
RDS-3086/3166G User Manual delimiters for Serial to Ethernet and / or Ethernet to Serial communications. You can define max. 4 delimiters (00~FF, Hex) for each way. The data will be hold until the delimiters are received or the option. Flush Serial to Ethernet data buffer times out. 0 means disable. - Page 22 RDS-3086/3166G User Manual Label Description Data Port Set the port number for data transmission. When a serial port stops data transmission for a defined period of time (Idle Timeout), the connection will be closed and the port will be freed and try to connect with other hosts.
- Page 23 RDS-3086/3166G User Manual TCP Server Mode In TCP Server mode, the serial port on the device server is assigned a unique port number. The host computer initiates contact with the device server, establishes the connection, and receives data from the serial device. Five simultaneous connections are supported in this mode, enabling multiple hosts to collect data from the same serial device at the same time.
- Page 24 RDS-3086/3166G User Manual connection will be closed and the port will be freed. 0 means the function is disabled which is the factory default value. The number of maximum connections can be support Max Connection simultaneously is 5; default values is 1.
- Page 25 RDS-3086/3166G User Manual The serial device will send a TCP alive-check package in each defined time interval (Alive Check) to remote host to check the TCP Alive Check connection. If the TCP connection is not alive, the connection will be closed and the port will be freed. 0 means the function is disabled which is the factory default value.
-
Page 26: Web Management
RDS-3086/3166G User Manual For Modbus mode settings, please refer to the next section. 4.2 Web Management The device can be managed via a built-in web server which supports Internet Explorer (Internet Explorer 5.0 or above versions) and other Web browsers such as Chrome. Therefore, you can manage and configure the device easily and remotely. -
Page 27: Basic Settings
RDS-3086/3166G User Manual Note: you can use the following default values: IP Address: 192.168.10.1 Subnet Mask: 255.255.255.0 Default Gateway: 192.168.10.254 User Name: admin After logging in, you will see the information of the device as below. On the left hand side of the management interface shows links to various settings. Clicking on the links will bring you to individual configuration pages. - Page 28 RDS-3086/3166G User Manual address is private to your internal network and is not visible to Internet. Label Description Device Name Enter the name of your device Protocol Choose to use static or DHCP protocols. Choose DHCP if your ISP dynamically assigns an IP address on connection. Choose static if the ISP provides you with a static (permanent) IP address and does not assign it dynamically.
-
Page 29: Serial Setting
RDS-3086/3166G User Manual IP address of the secondary DNS server. G5/G6 SFP Speed Select a speed for the SFP port. 4.2.2 Serial Setting 4.2.2.1 Serial Configuration This page allows you to configure serial port parameters. Label Description Port Alias Enter the COM port number that modem is connected to Interface Choose an interface for your serial device. - Page 30 RDS-3086/3166G User Manual Stop Bits Choose the number of bits used to indicate the end of a byte. You can configure stop bits to be 1 or 1.5(2). If Stop Bits is 1.5, the stop bit is transferred for 150% of the normal time used to transfer one bit.
-
Page 31: Port Profile
RDS-3086/3166G User Manual Performance Throughput: This mode is optimized for the highest transmission speed. Latency: This mode is optimized for the shortest response time. 4.2.2.2 Port Profile Label Description Indicates the TCP port the device uses to listen to connections, Local TCP Port and that other devices must use to contact the device. - Page 32 RDS-3086/3166G User Manual In Virtual COM mode, the driver establishes a transparent connection between the host and the serial device by mapping the port of the serial server to a local COM port on the host computer. Virtual COM mode also supports up to 5 simultaneous connections, so that multiple hosts can send or receive data by the same serial device at the same time.
- Page 33 RDS-3086/3166G User Manual Label Description Data Encryption Click Enable and the data will be encrypted with SSL. TCP Server Port Set the port number for data transmission. When serial port stops data transmission for a defined period of time (Idle Timeout), the connection will be closed and the port will be freed and try to connect with other hosts.
- Page 34 RDS-3086/3166G User Manual Label Description Destination Host Set the IP address of host and the port number of data port. . When serial port stops data transmission for a defined period of time, the connection will be closed and the port will be freed and Idle Timeout try to connect with other hosts.
- Page 35 RDS-3086/3166G User Manual Label Description Allows the user to set a new TCP port number to listen on rather Listen Port than the default value of the device If there are more than one destination hosts, specify the IP Host Start/End IP address range by inputting a value in Host Start / End IP.
- Page 36 RDS-3086/3166G User Manual Max Try Time The maximum number of request retries performed serially. Request Pause The delay between serial requests in milliseconds Response Wait The serial response timeout in milliseconds Enter a TCP connection timeout in seconds. When no...
- Page 37 RDS-3086/3166G User Manual Label Description TCP Server Port Indicates the port used for the Modbus/TCP communication The total number of remote TCP/IP clients allowed to connect Max Connection to this server. Max Try Time The maximum number of request retries performed serially.
-
Page 38: System Tools
RDS-3086/3166G User Manual only the first host connection is effective for this setting. The serial device will send TCP alive-check packages in each defined time interval to remote host to check the TCP Alive Check connection. If the TCP connection is not alive, the connection will be closed and the port will be freed. -
Page 39: Device Restart
ORing launches new firmware constantly to enhance device performance and functions. To upgrade firmware, download new firmware from ORing’s website to your PC and install it via Web upgrade. Make sure the firmware file matches the model of your device. It will take several minutes to upload and update the firmware. -
Page 40: Save/Restore Configurations
RDS-3086/3166G User Manual During firmware upgrading, do not turn off the power of the device or press the reset button. 4.2.3.5 Save/Restore Configurations This page allows you to save configurations or return settings to previous status. You can download the configuration file from the Web. Note: users using old versions of Internet Explorer may have to click on the warning on top of the browser and choose Download File. -
Page 41: Miscellaneous
RDS-3086/3166G User Manual Restore Mode You can restore configurations to previous status by installing a previous configuration file. To do this, choose Web Restore or Tftp Restore. If you choose Web Restore, you need to choose a file and click Web Restore. If you select Tftp Restore, fill in a Tftp server IP address and the file name before clicking Tftp Restore. - Page 42 RDS-3086/3166G User Manual echnical Specifications ORing Device Server RDS-3166G RDS-3086G Model Physical Ports 10/100/1000Base-T(X) Ports in RJ45 Auto MDI/MDIX 100/1000Base-X with SFP port RS-232 Serial Console Port RS-232 in RJ45 connector with console cable. 115200bps, 8, N, 1 Serial Ports...
- Page 43 RDS-3086/3166G User Manual EN61000-4-8, EN61000-4-11 Shock IEC60068-2-27 Free Fall IEC60068-2-32 Vibration IEC60068-2-6 Safety EN60950-1 Warranty 5 years ORing Industrial Networking Corp...
