GENERAL SETTINGS

Running Mode
Voltage Cutoff
ESC Temp. Protection
Motor Temp. Protection
Items
explanations
1)"Forward Only with Brake" this mode is
meant for competition use. In this mode
the car can go forward and brake, there is
no reverse.
2)"Forward/Reverse with Brake" this is the
basic all-around mode. In this mode the
car can go forward and reverse and can
also brake. When you move the throttle to
the reverse position while the car is moving
forward, brakes are applied until the car is
fully stopped, reverse cannot engage while
the car is moving. To engage reverse, once
the car has stopped, release the brakes and
move the throttle to the reverse position
again. While braking or in reverse, if the
throttle is moved to the forward position,
the car will immediately accelerate forward.
3)"Forward/Reverse" this mode is meant
for Rock Crawler use. In this mode there is
no brake, the car can go from forward to
reverse immediately without any pause. Do
not use this mode with other car types as
it can overload and/or damage the ESC.
This function helps to prevent battery
over-discharge. The ESC continuously
monitors the battery's voltage. If the voltage
becomes lower than the threshold for 2
seconds, the output power is shut off and
the red LED flashes twice repeatedly. For
racing, set the voltage cutoff at 3.0V
This parameter activates or deactivates the
overheating protection. Output power will
be cut-off if the temperature of the ESC or
the internal temperature of the motor goes
(sensored only) over a factory preset value
for 5 seconds.
For racing, Disable the
protections.
12

THROTTLE CONTROL

Switch Point
1st Stage Punch
2nd Stage Punch
TH Imput Curve
Throttle Dead Band

BRAKE CONTROL

Drag Brake
Brake Strength
Initial Brake
overheat
This will set the point between the 1st Stage
Punch and 2nd Stage Punch
This will set the punch you will get on the
first stage (1% 50% if Switch point set
at 50%). The higher the value is the more
punch and power you will get.
This will set the punch you will get on the
second stage (50% 100% if Switch point
set at 50%). The higher the value is the more
punch and power you will get.
Set Linear / To make it customs, please use
the PC Program available soon.
This parameter adjusts the
sensitivity around the neutral point. A higher
value means that the throttle will have to be
moved further for the car to move forward,
backward or brake. Standart set-up us 80ms
Sets the amount of brake automatically
applied when the throttle is returned to the
neutral position. This simulates the engine
breaking effect of a real car, it can help
improve turn-in and the general feeling of
the car.
This parameter adjusts the maximum
breaking force. A higher value provides
stronger braking, but it can also cause the
wheels to lock causing loss of control of
the car.
This parameter adjusts the
amount of braking power when the brakes
engage. The default value is equal to the
drag brake value. A high value can cause
the wheels to lock immediately when the
brake is used.
13
