Introduction
Thank you for purchasing ESC from RC Concept. Please read
the following informations before use the ESC. These operating
instructions are designed to ensure that you quickly become
familiar with its features and functions and make full use of this
product.
Features
• Timing and Turbo control which improve the motor RPM
and its performances.
• Throttle and Brake control. You can control the punch
and the brakes by point. 5 steps from very weak to very strong
fro easy tuning.
• Low resistance connectors used to improve power and reduce
heat.
• The circuit is managed by intelligent thermal management
kernel algorithm in order to improve driving skill and adjust the
control time of the dead band. The dynamic loss is reduced
effectively when the motor is running at high speed or the
user us changing the motor speed frequently. This allowed the
motor to be more stable when running.
• Cooling design. The case and the internal design of the
ESC has been designed to reduce the heat and give maximum
power at all time.
• External switch for more reliability.
• Profiles with pre-settings for most needs: Off-Road carper
2wd/4wd - Off-Road Dirt 2wd/4wd - Touring 13.5T. Those
program can be tuned with the EC Box or our PC Software
available on our website.
• Safety features: low voltage protection, motor and ESC
overheat protection and signal lost protection.
• Programmable with our RC Concept EC Box.
• Option to turn off the ESC by keeping the trigger full brake for
8seconds. This can be disable if needed.
4

Safety Note

• It is not a toy and suitable for users older than 14 years old.
• Never allow water, moisture, oil or other foreign materials to
get inside the ESC, Motor or on the PC boards. It may damage
the ESC completely.
• Never disassemble the ESC and modify the components on
the PC boards.
• Never solder one part for more than 5 seconds as some
components will get damaged by high temperature.
• Never run the ESC without load at full throttle or it may
damage the bearings and other moving parts.
• Please make sure the location where to fix the ESC has good
airflow ventilating so the heat could dissipate quickly.
• To avoid short circuit, please keep the ESC connectors far away
from other metal parts.
• Never conncet the battery polarity in reverse.
• Please remove the pinion gear before performing calibration
and programming functions with this system.
• Before you switch on the ESC, make sure all the cables are well
solder with the connectors.
• Electronic motor timing will increase the temperature of ESC
and bruchless motor. Use with caution when setting up and
testing your application to avoid overloading and overheating.
• Incorrect Boost and Timing setting may cause permanent
damage to the ESC and motors. Please coose proper ratio and
timing according to motor's instruction.
• To avoid signal interference, please always turn on the
transmitter first and then turn on the ESC. Do the opposite
when powering off.
• Always insulate exposed wiring with heat shrink tubing to
prevent short circuits which can damage the ESC.
• Always disconnect the battery pack from the ESC when not in
use. When the ESC is switched off, there is still small current
and it may cause over discharge of the battery after some time.
• The SC10R can support 4-9 cells NiMH or 2-3 cells LiPo battery.
The SC8R can support 2-6S cells LiPo battery.
NOTE: We will not be responsible for any damage
caused by non-compliance with above instruction.
