Setting the Interface Parameters
Interface Type
UPP. JAM SENSOR Y
↓
PARALL INTERFACE
↓
SERIAL INTERFACE
1284 BIDIR i/F Bidirectional IEEE 1284 parallel interface.
CX PARALLEL I/F Centronics type parallel interface (monodirectional)
Setting the Select-In Signal
1284 BIDIR. I/F
↑
SELECT-IN HOST
SELECTIN ON
↓
DATA BITS 8
SELECT-IN ON The SELECT-IN signal of the parallel interface is ignored and treated always as
ON.
SELECT-IN HOST
The printer checks the SELECT-IN signal coming from the host.
PARALL INTERFACE
↑
→
1284 BIDIR I/F
CX PARALLEL I/F
↓
SELECT-IN HOST
→ or ←
→ or ←
→ or ←
→ or ←
