Getting Started

Installation

Electrostatic Discharge
4
Table 4: Optional accessories (cont.)
Item
ST/PC UCI adapter
3.5 male to 3.5 female SMA
Slip-on SMA connector
CSA8000 & TDS8000 Series Service Manual
DSA8200 Service Manual
80C14 Series Optical Sampling Module User
Manual (this document)
See the Tektronix Web site for the current list of optional accessories.
CAUTION.
The electrical data outputs on the optical module are subject to
damage from electrostatic discharge (ESD). To prevent damage from electrostatic
discharge, observe the followig guidelines:
Store the module, with the supplied SMA terminations installed, in a static-free
container, such as the shipping container. Whenever you move the optical module
from one instrument to another, use a static-free container to carry the optical
module.
Be sure to only operate the optical module in a static-controlled environment
(grounded conductive table top, wrist strap, floor mat, and ionized air blower).
Always use a grounded wrist strap (provided with your instrument) when
installing, removing, or handling an optical module or making connections.
Discharge to ground any electrostatic charge that may be present on cables before
attaching the cable to the optical module.
Circuitry in the optical module is very susceptible to damage from overdriven
signals. Verify that the optical signal is within acceptable power levels for the
module before connecting the signal to the module.
Part number
119-4513-XX
015-0552-XX
015-0553-XX
071-0438-XX
071-2049-XX
071-2955-XX
80C14 Optical Sampling Module User Manual
