Getting Started
2

Table 1: 80C14 module features

Feature
Number of input channels
Effective wavelength range
Supported standards or data
filtering rates
Typical optical bandwidth at
optical connector
Clock recovery support
Absolute maximum
nondestructive optical input 2
Internal fiber diameter
Optical return loss
Output zero
Independent channel deskew
Offset capability at front of
module
Power meter
1 Some values in the table are typical.
2
The optical input powers below nondestructive levels may exceed saturation and compression limits of the module.
3
Compatible with single-mode fiber of equal or smaller diameter.
1
Description
1
700 nm to 1650 nm
8GFC (8.500 Gb/s)
OC-192/STM-64 (9.953 Gb/s)
10GBase-W (9.953 Gb/s)
10GBase-R (10.31 Gb/s)
40GBase-R4 (10.31 Gb/s)
100GBase-SR10 (10.31 Gb/s)
10GFC (10.52 Gb/s)
ITU-T G.975 FEC (10.664 Gb/s)
ITU-T G.709 (10.709 Gb/s)
10 GbE FEC (11.1 Gb/s)
10GFC FEC (11.3 Gb/s)
Super FEC (12.5 Gb/s)
16GFC (14.025 Gb/s)
14G Infiniband FDR (14.0625 Gb/s)
> 14 GHz
Clock recovery supported with the use of the CR175A
or CR286A Clock Recovery instrument (purchased
separately)
4 mW average power (850 nm)
2 mW average power (1350 nm, 1550 nm)
10 mW peak power for 60 ms.
62.5 mm/125 μm multimode mode
> 14 dB for multimode fiber > 24 dB for single-mode fiber
< 1 μW immediately after dark calibration ±2% (vertical
offset)
Standard
Standard
Standard
