WARNING
E
THIS IS NOT A TOY. MISUSE MAY CAUSE SERIOUS INJURY OR
N DEATH. EYE, FACE AND EAR PROTECTION DESIGNED FOR
PAINTBALL MUST BE WORN BY THE USER AND ANY PERSON
G
WITHIN RANGE. WE RECOMMEND AT LEAST 18 YEARS OLD
TO PURCHASE. PERSONS UNDER 18 MUST HAVE ADULT
L
SUPERVISION WHEN USING THIS PRODUCT. READ THE
I
OWNER'S MANUAL BEFORE USING THIS PRODUCT.
S
WARNING
H
BARREL SLEEVE INSTALLATION
• EXCEPT WHEN YOUR MARKER IS IN USE, ALWAYS MAKE
SURE THAT THE TRIGGER SAFETY IS IN SAFE MODE =
(SEE INSTRUCTIONS ON PAGE 4), AND THE BARREL SLEEVE
IS PROPERLY INSTALLED ON YOUR MARKER AS FOLLOWS.
1) SLIDE BARREL INTO SLEEVE AND LOOP CORD OVER TOP
OF RECEIVER AND POSITION AT BACK OF GRIP AS SHOWN.
2) PINCH
CORD LENGTH
ADJUSTOR
BUTTON AND
HOLD TO BACK OF GRIP
AS YOU PULL CORD THROUGH IT UNTIL ADJUSTOR IS
SNUG AGAINST BACK OF GRIP, THEN RELEASE BUTTON.
3) CHECK TO BE SURE THERE IS ENOUGH CORD
ELASTICITY TO PULL CORD/ADJUSTOR OFF OF GRIP TO
REMOVE BARREL SLEEVE FOR FIRING.
4) AFTER CORD LENGTH
IS ADJUSTED, LOCK
CORD LENGTH BY TYING
A KNOT IN THE CORD
AGAINST THE BACK OF
THE ADJUSTOR AS SHOWN.
CORD
LENGTH
ADJUSTOR
BUTTON
2
TIPPMANN
2955 Adams Center Road, Fort Wayne, IN 46803 USA
P) 260-749-6022 • F) 260-749-6619
www.tippmann.com
CONGRATULATIONS on your purchase of your Tippmann
paintball marker. We believe our X7
most accurate and durable paintball markers available, and
proudly manufactured in the USA. All Tippmann
will give many years of dependable service if cared for properly.
Please take time to read this manual thoroughly and become
familiar with your Tippmann
safety precautions before you attempt to load or fire this marker.
If you have a missing or broken part or need assistance, please
contact Tippmann Consumer Relations at 1-800-533-4831 for
®
fast friendly service.

TABLE OF CONTENTS

Warning/Caution ............................................................................... 2
Warning/Caution Barrel Sleeve Installation ................................... 2
Warning/Liability Statement ............................................................ 4
Safety is your Responsibility / Familiarize Yourself With Safety . 4
Safe Mode = Turning The Safety On (SAFE = white
Fire Mode = Turning The Safety Off (FIRE = red
Getting Started ................................................................................. 6
1. Prepare Marker for Air Supply Cylinder Installation ............. 6
2. Air Supply Cylinder Installation .............................................. 6
3. Hopper and Cyclone TM Feeder ................................................ 6
4. Velocity Adjustment ................................................................. 7
5. Rear Sight Adjustment ............................................................ 7
Schematic: X7 TM Basic Parts List .................................................... 8
Unloading Your Marker .................................................................. 10
Air Supply Cylinder Removal ........................................................ 10
Cleaning & Maintenance ............................................................... 10
Marker / Receiver Disassembly & Assembly ............................... 11
Repairing Air Supply Leaks ........................................................... 17
Storage ............................................................................................ 17
Marker Model Specifications ......................................................... 17
Warranty and Repair Policy .......................................................... 18
Warranty or Repair Procedure ...................................................... 18
Warranty Registration .................................................................... 18
®
TM line of markers to be the
® X7 TM
X7 markers' parts, operation, and
® TM
) ............. 4
