- Page 1 Operation Manual Pro CO™ Carbon Monoxide Analyzer...
- Page 2 Every effort was made to ensure the accuracy of the information contained within this manual; however, we retain the right to modify its contents without notice. If you have problems or questions after reading the manual, stop and call for information. NUVAIR Page Pro CO Carbon Monoxide Analyzer Manual...
-
Page 3: Table Of Contents
5.3 Sensor Replacement ……………………………………………....11 6.0 Spares and Accessories …………………………………………………………..13 6.1 Sensor ………………………………………………………………....13 6.2 Calibration Equipment .……………………………………………....13 7.0 Troubleshooting....................13 Appendix ……………………………………………………………………....14 Analyzer Specifications ………………………………………………....14 Warranty …………………….…………………………………………….……... 15 NUVAIR Page Pro CO Carbon Monoxide Analyzer Manual... -
Page 4: Introduction
Carbon Monoxide Analyzer 1.0 Introduction This manual will assist you in the proper set-up, operation and maintenance of the Pro CO Carbon Monoxide Analyzer. Be sure to read the entire manual. Throughout this manual we will use certain words to call your attention to conditions, practices or techniques that may directly affect your safety. -
Page 5: System Description
2.1. Controls Digital Display Calibrate Screw with Lock Nut – Rotating Type Power Switch (Toggle Type) Up - On Center - Off Down - Off NUVAIR Page Pro CO Carbon Monoxide Analyzer Manual... -
Page 6: Display
Sensor via one of two methods: Direct Flow Method Sample Flow Method Flow is Directed to Flow is Delivered from Flow Orifice on Face Low Pressure Source of Flow Adapter Cap via Flexible Tubing Vent Hole NUVAIR Page Pro CO Carbon Monoxide Analyzer Manual... -
Page 7: Calibration
CO calibration gas with a 10 ppm concentration and flow rate of 0.5-1 L/min. The equipment to produce this flow is available from Nuvair. See Spares and Accessories section. To assure the greatest accuracy for other applications, use the calibration gas concentration closest to the expected concentration in the gas being measured. -
Page 8: Operation
• If analyzing a gas flow, the Sample Flow Method is the preferred method. The flow rate must equal 0.5 to 1 L/min at atmospheric pressure. To produce this flow, a Flow Restrictor and Regulator may be required. Contact Nuvair if you need assistance. 4.1. Sample Flow Method (Preferred) Step 1. -
Page 9: Direct Flow Method - Gas Cylinder
Cylinder Valve Step 4. Hold Face of Flow Adapter Cap Up to Gas Flow Step 6. Allow 15 Seconds for Display Reading to Stabilize Step 7. Record Reading while Gas is Flowing NUVAIR Page Pro CO Carbon Monoxide Analyzer Manual... -
Page 10: Maintenance
Remove & Replace Old Step 2. Remove Batteries Back Cover Step 4. Replace Back Cover - Step 6. Turn Do Not Pinch Analyzer On Wires Step 7. Step 5. Perform Reinstall Calibration Screws NUVAIR Page Pro CO Carbon Monoxide Analyzer Manual... -
Page 11: Sensor Replacement
• Eye Contact - Flush eyes with clean, fresh water for at least 15 minutes and get medical help immediately. • Skin Contact - Flush the affected area with clean, fresh water for at least 15 minutes and removed contaminated clothing. If stinging persists get medical attention. NUVAIR Page Pro CO Carbon Monoxide Analyzer Manual... - Page 12 Will Cause Display to Read Negative Step 8. Step 10. Replace Replace Flow Adapter Cap Back Cover - Do Not Pinch Wires Step 11. Turn Analyzer On Step 9. Reinstall Step 12. Perform Screws Calibration NUVAIR Page Pro CO Carbon Monoxide Analyzer Manual...
-
Page 13: Spares And Accessories
Sensor failure Change sensor Display segments missing Display faulty Return to dealer Will not calibrate Sensor faulty Change sensor Reading drifts Rapid temperature change Stabilize temperature & recalibrate NUVAIR Page Pro CO Carbon Monoxide Analyzer Manual... -
Page 14: Appendix
32 to 122°F (0 to 50°C) Storage Temperature: -4 to 140°F (-20 to 60°C) Operating Pressure: Not to Exceed 1 Atmosphere Absolute (0 P.S.I.) Humidity: 10-95% RH Note: All specifications are at ambient / sea level, 25°C NUVAIR Page Pro CO Carbon Monoxide Analyzer Manual... -
Page 15: Warranty
NUVAIR. Pro-Rated Terms: NUVAIR warrants the Pro CO to be free from defects in material and workmanship for a period of twelve (12) months from date of purchase. The warranty covers parts and labor. A warranty registration card, supplied with system documentation, must be filled out and submitted to NUVAIR for the warranty to be registered. - Page 16 Pro CO Carbon Monoxide Analyzer Nuvair™ 2005 All Rights Reserved Phone (805) 815-4044 Fax (805) 815-4196 2949 West 5th Street Oxnard, CA 93030 Email : info@nuvair.com Web : www.nuvair.com Revision 0205...
