lopital Marina Instruction Card

Safety recommendations

• Read the Instructions for use carefully (find this at:
www.lopital.com) before use.
• Maximum load 180 kg.
• Make sure that the Marina is on the brake during
client transfers from and to the stretcher.

Electric manual control

Up
Down
Activate
2 seconds
Hydraulic control
Upwards
Downwards
Important!
This instruction card may not be considered a
replacement for the Instructions for use.
Instruction card
Marina Shower stretcher
Side-bar
Hydraulic control

Use

1. Activate the Marina by pressing the 'up' button for
2 seconds.
Note: After use, the Marina will go into a sleep
setting after 60 minutes (Electric Marina).
2. Put the stretcher in the right position and at the
right height.
3. Make sure the brakes are applied to the stretcher!
4. Fold the side-bars down.
5. Use the EasySlide to slide the person from or to
the Marina.
6. Raise the bed base a few centimetres and close
the side-bars.
7. Disengage the brake on the Marina.

Wheel blocking

2
1. Wheel blocking.
2. Unlocking.
Manual control
Wheel blocking Charge battery &
Emergency lowering

Side-bars

2
1
1. Unlock.
2. Tilt.
3. Turn.
When closing, the bar locks automatically.
Make sure that the curly cord from the control
panel does not become jammed when closing
the side-bar (electric Marina).

Charging batteries (Electric Marina)

After using the Marina, connect it to the charger to
maintain the batteries.
Off Sleep setting.
1
Green Chair ready to use.
Blinking orange Emergency stop activated.
Orange Battery is half empty.
Blinking red Battery almost empty.
Red Battery empty.
The Marina will not work during charging.

Emergency lowering (Electric Marina)

If the Marina breaks down, you can lower the
stretcher using the emergency lowering button.
3

Cleaning and maintenance

The Marina must be cleaned after every use,
with water and regular household cleaning
agents. Do not use any abrasive or other ag-
gressive cleaning products. Check the wheels
regularly for hairs, dust and soap residues and
remove when necessary.
The complete maintenance schedule can be
found in the Instructions for use
(find this at: www.lopital.com).
In the event of a breakdown, contact Lopital.
Tel: +31 (0)13 - 5239300, Fax: +31 (0)13 - 5239301
E-mail: service@lopital.nl
Instructions for use
For the full Instructions for use go to
www.lopital.com
